SERIES AV/SMV
SURFACE MOUNT and PLUG-IN

Hi Voltage 600 to 1000 VDC
Hi Reliability
Ultra-Miniature - Low Profile
Isolated DC-DC Converters

.540" ht. .500 ht. up to 1000 VDC output

This series of unregulated high voltage DC-DC converters are produced in an ultra-miniature encapsulated package. 40 different models are available. These single output isolated units will operate over the temperature range of -25º C to +70º C with no heat sink or electrical derating. For military applications an operating temperature range -55º C to +85 º C is available. An optional environmental screening package per MIL-STD-883 is also available.
FEATURES

  • 1.25 watt output at 70º ambient
  • Ultra-miniature size 0.500" height, 5.0 grams weight, 0.125 cubic inches volume
  • 4 input voltage ranges 5, 12, 24 and 28 VDC
  • 100 megohm @ 1500 VDC input/output isolation
  • MIL-STD 883 options available
  • No heat sink or electrical derating required
OPTIONS AVAILABLE
  • Per Mil. Std. 883
  • Expanded operating temp. (-55º C to +85º C)
  • Stabilization Bake (125º C amblent)
  • Temperature Cycle (-55º C to +125º C)
  • Hi Temp, burn
    TYPICAL CHARACTERISTICS:
  • Test conditions: 25º C ambient and input voltage at nominal value unless otherwise specified.
  • LINE REGULATION: OUTPUT IS DIRECTLY PROPORTIONAL TO THE INPUT.
  • Input voltage range: ±10% all models
  • Output voltage tolerance at full load-nom. Input: ±3%
    Please keep loaded to minimum of 10% at all times.
    Note: For tighter output voltage tolerances, please consult factory.
  • Converter frequency: 20 - 40 KHz
  • Output temperature coefficient: 0.02%/ºC for all models
  • Operating temperature: -25º C to +70º C ambient. No heat sink is required.
  • Storage temperature: -55º C to +125º C
  • Isolation: 100 megohms min. @ 1500V D




SERIES AV/SMV - SINGLE OUTPUT

PICO
Plug-in
Part
Number
PICO
Surface
Mount
Part
Number
Input
Volt.
(V DC)
Output
Volt.
(V DC)
Max.
Load
Current
(mA)
Max.
Output
Power
(watts)
Eff. @
Full
Load
Typical
(%)
Input
Current
Full
Load
Typical
(mA)
Output
Volt.
Ripple
@ Full
Load
(Vp-p max)
Full**
Load
Output
Volt.
Tolerance
(%)
Price
(US $)
5AV600
5AV700
5AV800
5AV900
5AV1000
5SMV600
5SMV700
5SMV800
5SMV900
5SMV1000
5
5
5
5
5
600
700
800
900
1000
2.08
1.79
1.56
1.39
1.25
1.25
1.25
1.25
1.25
1.25
70
70
70
70
70
357
357
357
357
357
3.0
3.0
3.0
3.0
3.0
±3
±3
±3
±3
±3
137.39
137.39
137.39
137.39
137.39
12AV600
12AV700
12AV800
12AV900
12AV1000
12SMV600
12SMV700
12SMV800
12SMV900
12SMV1000
12
12
12
12
12
600
700
800
900
1000
2.08
1.79
1.56
1.39
1.25
1.25
1.25
1.25
1.25
1.25
70
70
70
70
70
149
149
149
149
149
3.0
3.0
3.0
3.0
3.0
±3
±3
±3
±3
±3
137.39
137.39
137.39
137.39
137.39
15AV600
15AV700
15AV800
15AV900
15AV1000
15SMV600
15SMV700
15SMV800
15SMV900
15SMV1000
15
15
15
15
15
600
700
800
900
1000
2.08
1.79
1.56
1.39
1.25
1.25
1.25
1.25
1.25
1.25
70
70
70
70
70
120
120
120
120
120
3.0
3.0
3.0
3.0
3.0
±3
±3
±3
±3
±3
137.39
137.39
137.39
137.39
137.39
24AV600
24AV700
24AV800
24AV900
24AV1000
5SMV600
24SMV700
24SMV800
24SMV900
24SMV1000
24
24
24
24
24
600
700
800
900
1000
2.08
1.79
1.56
1.39
1.25
1.25
1.25
1.25
1.25
1.25
70
70
70
70
70
74
74
74
74
74
3.0
3.0
3.0
3.0
3.0
±3
±3
±3
±3
±3
137.39
137.39
137.39
137.39
137.39
28AV600
28AV700
28AV800
28AV900
28AV1000
28SMV600
28SMV700
28SMV800
28SMV900
28SMV1000
28
28
28
28
28
600
700
800
900
1000
2.08
1.79
1.56
1.39
1.25
1.25
1.25
1.25
1.25
1.25
70
70
70
70
70
64
64
64
64
64
3.0
3.0
3.0
3.0
3.0
±3
±3
±3
±3
±3
137.39
137.39
137.39
137.39
137.39
* Measured using 0.01µf, 3000 Volt DC capacitor which is required across the output and maintain at least 10% of load at all times to prevent voltage surge.
**For tighter tolerances consult factory.
Ordering Instructions: No minimum. Net 30 days F.O.B. Pelham, New York

SAFETY NOTE: The high voltage power supplies described in this datasheet generate voltages which can be lethal. They should only be installed and used by personnel who have received the appropriate training and who are fully aware of the hazards that exist.

Series AV/SMV Single Output

AV Single

Larger Size Drawing

Typical Weight: 5 Grams

Larger Size Schematic

SMV Single

Larger Size Drawing

White dot on top indicates + input
24 AV/SMV 600

Larger Size Graph

5 AV/SMV 1000

Larger Size Graph



RECOMMENDED LAND PATTERN DIMENSIONS
SERIES SMV


For immediate engineering assistance or to place an order:
Call Toll Free: 800-431-1064

PICO Electronics, Inc.

143 Sparks Ave. Pelham, NY 10803-1810
Tel: 914-738-1400 or Fax: 914-738-8225
