Low Profile DC-DC Converters render 1

Low Profile DC-DC Converters

Pico Electronics manufactures thousands of DC-DC converter products in a variety of package configurations unmatched in the industry.

Pico’s Low Profile DC-DC Converters features a maximum height of 0.500 inches and includes features such as output regulation, isolation, programmable, and adjustable outputs ranging from 2 VDC to 10,000 VDC and 0.75 to 30 Watts. These modules feature package heights as low as 0.200 inches and can handle input voltages from 3 VDC to 475 VDC.

Filter down to your exact part number or search by series groups.

Explore by Series

Mounting

# of Outputs

Output Type

Nominal Input Voltage (VDC)

Input Voltage Range (VDC)

Single Output Voltage (VDC)

Single Max Output Power (W)

Dual Output Voltage (VDC)

Dual Max Output Power (W)

Triple Output Voltage (VDC)

Triple Max Output Power (W)

Part Number SeriesMounting# of OutputsOutput TypeNominal Input Voltage (VDC)Input Voltage Range (VDC)Single Output Voltage (VDC)Single Max Output Power (W)Dual Output Voltage (VDC)Dual Max Output Power (W)Triple Output Voltage (VDC)Triple Max Output Power (W)Downloads
TLVD5STLVTerminal StripSingleRegulated4836 – 8059 – – – –
DatasheetMechanical Drawing3D Model
TLVD5DTLVTerminal StripDualRegulated4836 – 80 – – ±5±4.5 – –
DatasheetMechanical Drawing3D Model
TLVD5.2STLVTerminal StripSingleRegulated4836 – 805.29 – – – –
DatasheetMechanical Drawing3D Model
TLVD48STLVTerminal StripSingleRegulated4836 – 804810 – – – –
DatasheetMechanical Drawing3D Model
TLVD3.3STLVTerminal StripSingleRegulated4836 – 803.37 – – – –
DatasheetMechanical Drawing3D Model
TLVD28STLVTerminal StripSingleRegulated4836 – 802810 – – – –
DatasheetMechanical Drawing3D Model
TLVD24STLVTerminal StripSingleRegulated4836 – 802410 – – – –
DatasheetMechanical Drawing3D Model
TLVD15STLVTerminal StripSingleRegulated4836 – 801510 – – – –
DatasheetMechanical Drawing3D Model
TLVD15DTLVTerminal StripDualRegulated4836 – 80 – – ±15±5 – –
DatasheetMechanical Drawing3D Model
TLVD12STLVTerminal StripSingleRegulated4836 – 801210 – – – –
DatasheetMechanical Drawing3D Model
TLVD12DTLVTerminal StripDualRegulated4836 – 80 – – ±12±5 – –
DatasheetMechanical Drawing3D Model
TLVC5STLVTerminal StripSingleRegulated4836 – 8057 – – – –
DatasheetMechanical Drawing3D Model
TLVC5DTLVTerminal StripDualRegulated4836 – 80 – – ±5±3.5 – –
DatasheetMechanical Drawing3D Model
TLVC5.2STLVTerminal StripSingleRegulated4836 – 805.27 – – – –
DatasheetMechanical Drawing3D Model
TLVC48STLVTerminal StripSingleRegulated4836 – 80488 – – – –
DatasheetMechanical Drawing3D Model
TLVC3.3STLVTerminal StripSingleRegulated4836 – 803.35 – – – –
DatasheetMechanical Drawing3D Model
TLVC28STLVTerminal StripSingleRegulated4836 – 80288 – – – –
DatasheetMechanical Drawing3D Model
TLVC24STLVTerminal StripSingleRegulated4836 – 80248 – – – –
DatasheetMechanical Drawing3D Model
TLVC15STLVTerminal StripSingleRegulated4836 – 80158 – – – –
DatasheetMechanical Drawing3D Model
TLVC15DTLVTerminal StripDualRegulated4836 – 80 – – ±15±4 – –
DatasheetMechanical Drawing3D Model
TLVC12STLVTerminal StripSingleRegulated4836 – 80128 – – – –
DatasheetMechanical Drawing3D Model
TLVC12DTLVTerminal StripDualRegulated4836 – 80 – – ±12±4 – –
DatasheetMechanical Drawing3D Model
TLVB5STLVTerminal StripSingleRegulated4836 – 8055 – – – –
DatasheetMechanical Drawing3D Model
TLVB5DTLVTerminal StripDualRegulated4836 – 80 – – ±5±2.5 – –
DatasheetMechanical Drawing3D Model
TLVB5.2STLVTerminal StripSingleRegulated4836 – 805.25 – – – –
DatasheetMechanical Drawing3D Model
TLVB48STLVTerminal StripSingleRegulated4836 – 80485 – – – –
DatasheetMechanical Drawing3D Model
TLVB3.3STLVTerminal StripSingleRegulated4836 – 803.34 – – – –
DatasheetMechanical Drawing3D Model
TLVB28STLVTerminal StripSingleRegulated4836 – 80285 – – – –
DatasheetMechanical Drawing3D Model
TLVB24STLVTerminal StripSingleRegulated4836 – 80245 – – – –
DatasheetMechanical Drawing3D Model
TLVB15STLVTerminal StripSingleRegulated4836 – 80155 – – – –
DatasheetMechanical Drawing3D Model
TLVB15DTLVTerminal StripDualRegulated4836 – 80 – – ±15±2.5 – –
DatasheetMechanical Drawing3D Model
TLVB12STLVTerminal StripSingleRegulated4836 – 80125 – – – –
DatasheetMechanical Drawing3D Model
TLVB12DTLVTerminal StripDualRegulated4836 – 80 – – ±12±2.5 – –
DatasheetMechanical Drawing3D Model
THVD5STHVTerminal StripSingleRegulated12570 – 170510 – – – –
DatasheetMechanical Drawing3D Model
THVD5DTHVTerminal StripDualRegulated12570 – 170 – – ±5±5 – –
DatasheetMechanical Drawing3D Model
THVD5.2STHVTerminal StripSingleRegulated12570 – 1705.210 – – – –
DatasheetMechanical Drawing3D Model
THVD48STHVTerminal StripSingleRegulated12570 – 1704815 – – – –
DatasheetMechanical Drawing3D Model
THVD3.3STHVTerminal StripSingleRegulated12570 – 1703.36 – – – –
DatasheetMechanical Drawing3D Model
THVD28STHVTerminal StripSingleRegulated12570 – 1702815 – – – –
DatasheetMechanical Drawing3D Model
THVD24STHVTerminal StripSingleRegulated12570 – 1702415 – – – –
DatasheetMechanical Drawing3D Model
THVD15STHVTerminal StripSingleRegulated12570 – 1701515 – – – –
DatasheetMechanical Drawing3D Model
THVD15DTHVTerminal StripDualRegulated12570 – 170 – – ±15±7.5 – –
DatasheetMechanical Drawing3D Model
THVD12STHVTerminal StripSingleRegulated12570 – 1701215 – – – –
DatasheetMechanical Drawing3D Model
THVD12DTHVTerminal StripDualRegulated12570 – 170 – – ±12±7.5 – –
DatasheetMechanical Drawing3D Model
THVC5STHVTerminal StripSingleRegulated12570 – 17058 – – – –
DatasheetMechanical Drawing3D Model
THVC5DTHVTerminal StripDualRegulated12570 – 170 – – ±5±4 – –
DatasheetMechanical Drawing3D Model
THVC5.2STHVTerminal StripSingleRegulated12570 – 1705.28 – – – –
DatasheetMechanical Drawing3D Model
THVC48STHVTerminal StripSingleRegulated12570 – 1704810 – – – –
DatasheetMechanical Drawing3D Model
THVC3.3STHVTerminal StripSingleRegulated12570 – 1703.35 – – – –
DatasheetMechanical Drawing3D Model
THVC28STHVTerminal StripSingleRegulated12570 – 1702810 – – – –
DatasheetMechanical Drawing3D Model
THVC24STHVTerminal StripSingleRegulated12570 – 1702410 – – – –
DatasheetMechanical Drawing3D Model
THVC15STHVTerminal StripSingleRegulated12570 – 1701510 – – – –
DatasheetMechanical Drawing3D Model
THVC15DTHVTerminal StripDualRegulated12570 – 170 – – ±15±5 – –
DatasheetMechanical Drawing3D Model
THVC12STHVTerminal StripSingleRegulated12570 – 1701210 – – – –
DatasheetMechanical Drawing3D Model
THVC12DTHVTerminal StripDualRegulated12570 – 170 – – ±12±5 – –
DatasheetMechanical Drawing3D Model
THVB5STHVTerminal StripSingleRegulated12570 – 17055 – – – –
DatasheetMechanical Drawing3D Model
THVB5DTHVTerminal StripDualRegulated12570 – 170 – – ±5±2.5 – –
DatasheetMechanical Drawing3D Model
THVB5.2STHVTerminal StripSingleRegulated12570 – 1705.25 – – – –
DatasheetMechanical Drawing3D Model
THVB48STHVTerminal StripSingleRegulated12570 – 170485 – – – –
DatasheetMechanical Drawing3D Model
THVB3.3STHVTerminal StripSingleRegulated12570 – 1703.33.3 – – – –
DatasheetMechanical Drawing3D Model
THVB28STHVTerminal StripSingleRegulated12570 – 170285 – – – –
DatasheetMechanical Drawing3D Model
THVB24STHVTerminal StripSingleRegulated12570 – 170245 – – – –
DatasheetMechanical Drawing3D Model
THVB15STHVTerminal StripSingleRegulated12570 – 170155 – – – –
DatasheetMechanical Drawing3D Model
THVB15DTHVTerminal StripDualRegulated12570 – 170 – – ±15±2.5 – –
DatasheetMechanical Drawing3D Model
THVB12STHVTerminal StripSingleRegulated12570 – 170125 – – – –
DatasheetMechanical Drawing3D Model
THVB12DTHVTerminal StripDualRegulated12570 – 170 – – ±12±2.5 – –
DatasheetMechanical Drawing3D Model
SSC12SSCSurface MountSingleProportional5 – 123 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF9SSORSurface MountSingleRegulated168 – 2492 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF9DSORSurface MountDualRegulated168 – 24 – – 9/91/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF5SSORSurface MountSingleRegulated168 – 2452 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF5DSORSurface MountDualRegulated168 – 24 – – 5/51/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF5.2SSORSurface MountSingleRegulated168 – 245.22 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF3.3SSORSurface MountSingleRegulated168 – 243.31.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF28SSORSurface MountSingleRegulated168 – 24282 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF28DSORSurface MountDualRegulated168 – 24 – – 28/281/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF24SSORSurface MountSingleRegulated168 – 24242 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF24DSORSurface MountDualRegulated168 – 24 – – 24/241/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF15SSORSurface MountSingleRegulated168 – 24152 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF15DSORSurface MountDualRegulated168 – 24 – – 15/151/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF12SSORSurface MountSingleRegulated168 – 24122 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORF12DSORSurface MountDualRegulated168 – 24 – – 12/121/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE9SSORSurface MountSingleRegulated105 – 1591.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE9DSORSurface MountDualRegulated105 – 15 – – 9/90.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE5SSORSurface MountSingleRegulated105 – 1551.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE5DSORSurface MountDualRegulated105 – 15 – – 5/50.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE5.2SSORSurface MountSingleRegulated105 – 155.21.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE3.3SSORSurface MountSingleRegulated105 – 153.31.2 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE28SSORSurface MountSingleRegulated105 – 15281.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE28DSORSurface MountDualRegulated105 – 15 – – 28/280.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE24SSORSurface MountSingleRegulated105 – 15241.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE24DSORSurface MountDualRegulated105 – 15 – – 24/240.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE15SSORSurface MountSingleRegulated105 – 15151.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE15DSORSurface MountDualRegulated105 – 15 – – 15/150.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE12SSORSurface MountSingleRegulated105 – 15121.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORE12DSORSurface MountDualRegulated105 – 15 – – 12/120.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA9SSORSurface MountSingleRegulated2718 – 3692.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA9DSORSurface MountDualRegulated2718 – 36 – – 9/91.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA5SSORSurface MountSingleRegulated2718 – 3652 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA5DSORSurface MountDualRegulated2718 – 36 – – 5/51/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA5.2SSORSurface MountSingleRegulated2718 – 365.22 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA3.3SSORSurface MountSingleRegulated2718 – 363.31.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA28SSORSurface MountSingleRegulated2718 – 36282.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA28DSORSurface MountDualRegulated2718 – 36 – – 28/281.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA24SSORSurface MountSingleRegulated2718 – 36242.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA24DSORSurface MountDualRegulated2718 – 36 – – 24/241.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA15SSORSurface MountSingleRegulated2718 – 36152.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA15DSORSurface MountDualRegulated2718 – 36 – – 15/151.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA12SSORSurface MountSingleRegulated2718 – 36122.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SORA12DSORSurface MountDualRegulated2718 – 36 – – 12/121.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF9SSIRSurface MountSingleRegulated168 – 2498 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF9DSIRSurface MountDualRegulated168 – 24 – – 9/94/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF5SSIRSurface MountSingleRegulated168 – 2458 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF5DSIRSurface MountDualRegulated168 – 24 – – 5/54/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF5.2SSIRSurface MountSingleRegulated168 – 245.28 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF48SSIRSurface MountSingleRegulated168 – 24488 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF48DSIRSurface MountDualRegulated168 – 24 – – 48/484/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF3.3SSIRSurface MountSingleRegulated168 – 243.37 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF28SSIRSurface MountSingleRegulated168 – 24288 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF28DSIRSurface MountDualRegulated168 – 24 – – 28/284/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF24SSIRSurface MountSingleRegulated168 – 24248 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF24DSIRSurface MountDualRegulated168 – 24 – – 24/244/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF15SSIRSurface MountSingleRegulated168 – 24158 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF15DSIRSurface MountDualRegulated168 – 24 – – 15/154/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF12SSIRSurface MountSingleRegulated168 – 24128 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF12DSIRSurface MountDualRegulated168 – 24 – – 12/124/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRF100SSIRSurface MountSingleRegulated168 – 241008 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE9SSIRSurface MountSingleRegulated105 – 1596 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE9DSIRSurface MountDualRegulated105 – 15 – – 9/93/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE5SSIRSurface MountSingleRegulated105 – 1555 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE5DSIRSurface MountDualRegulated105 – 15 – – 5/52.5/2.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE5.2SSIRSurface MountSingleRegulated105 – 155.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE48SSIRSurface MountSingleRegulated105 – 15486 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE48DSIRSurface MountDualRegulated105 – 15 – – 48/483/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE3.3SSIRSurface MountSingleRegulated105 – 153.35 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE28SSIRSurface MountSingleRegulated105 – 15286 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE28DSIRSurface MountDualRegulated105 – 15 – – 28/283/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE24SSIRSurface MountSingleRegulated105 – 15246 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE24DSIRSurface MountDualRegulated105 – 15 – – 24/243/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE15SSIRSurface MountSingleRegulated105 – 15156 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE15DSIRSurface MountDualRegulated105 – 15 – – 15/153/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE12SSIRSurface MountSingleRegulated105 – 15126 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE12DSIRSurface MountDualRegulated105 – 15 – – 12/123/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRE100SSIRSurface MountSingleRegulated105 – 151006 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC9SSIRSurface MountSingleRegulated3918 – 6098 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC9DSIRSurface MountDualRegulated3918 – 60 – – 9/94/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC5SSIRSurface MountSingleRegulated3918 – 6058 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC5DSIRSurface MountDualRegulated3918 – 60 – – 5/54/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC5.2SSIRSurface MountSingleRegulated3918 – 605.28 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC48SSIRSurface MountSingleRegulated3918 – 60488 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC48DSIRSurface MountDualRegulated3918 – 60 – – 48/484/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC3.3SSIRSurface MountSingleRegulated3918 – 603.38 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC28SSIRSurface MountSingleRegulated3918 – 60288 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC28DSIRSurface MountDualRegulated3918 – 60 – – 28/284/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC24SSIRSurface MountSingleRegulated3918 – 60248 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC24DSIRSurface MountDualRegulated3918 – 60 – – 24/244/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC15SSIRSurface MountSingleRegulated3918 – 60158 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC15DSIRSurface MountDualRegulated3918 – 60 – – 15/154/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC12SSIRSurface MountSingleRegulated3918 – 60128 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC12DSIRSurface MountDualRegulated3918 – 60 – – 12/124/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRC100SSIRSurface MountSingleRegulated3918 – 601008 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB9SSIRSurface MountSingleRegulated4836 – 6098 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB9DSIRSurface MountDualRegulated4836 – 60 – – 9/94/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB5SSIRSurface MountSingleRegulated4836 – 6058 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB5DSIRSurface MountDualRegulated4836 – 60 – – 5/54/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB5.2SSIRSurface MountSingleRegulated4836 – 605.28 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB48SSIRSurface MountSingleRegulated4836 – 60488 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB48DSIRSurface MountDualRegulated4836 – 60 – – 48/484/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB3.3SSIRSurface MountSingleRegulated4836 – 603.38 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB28SSIRSurface MountSingleRegulated4836 – 60288 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB28DSIRSurface MountDualRegulated4836 – 60 – – 28/284/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB24SSIRSurface MountSingleRegulated4836 – 60248 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB24DSIRSurface MountDualRegulated4836 – 60 – – 24/244/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB15SSIRSurface MountSingleRegulated4836 – 60158 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB15DSIRSurface MountDualRegulated4836 – 60 – – 15/154/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB12SSIRSurface MountSingleRegulated4836 – 60128 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB12DSIRSurface MountDualRegulated4836 – 60 – – 12/124/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRB100SSIRSurface MountSingleRegulated4836 – 601008 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA9SSIRSurface MountSingleRegulated2718 – 3698 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA9DSIRSurface MountDualRegulated2718 – 36 – – 9/94/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA5SSIRSurface MountSingleRegulated2718 – 3658 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA5DSIRSurface MountDualRegulated2718 – 36 – – 5/54/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA5.2SSIRSurface MountSingleRegulated2718 – 365.28 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA48SSIRSurface MountSingleRegulated2718 – 36488 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA48DSIRSurface MountDualRegulated2718 – 36 – – 48/484/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA3.3SSIRSurface MountSingleRegulated2718 – 363.38 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA28SSIRSurface MountSingleRegulated2718 – 36288 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA28DSIRSurface MountDualRegulated2718 – 36 – – 28/284/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA24SSIRSurface MountSingleRegulated2718 – 36248 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA24DSIRSurface MountDualRegulated2718 – 36 – – 24/244/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA15SSIRSurface MountSingleRegulated2718 – 36158 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA15DSIRSurface MountDualRegulated2718 – 36 – – 15/154/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA12SSIRSurface MountSingleRegulated2718 – 36128 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA12DSIRSurface MountDualRegulated2718 – 36 – – 12/124/4 – –
DatasheetMechanical DrawingLand Pattern3D Model
SIRA100SSIRSurface MountSingleRegulated2718 – 361008 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
PLRF9SPLRThrough HoleSingleRegulated168 – 2495 – – – –
DatasheetMechanical Drawing3D Model
PLRF9DPLRThrough HoleDualRegulated168 – 24 – – 9/92.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRF5SPLRThrough HoleSingleRegulated168 – 2455 – – – –
DatasheetMechanical Drawing3D Model
PLRF5DPLRThrough HoleDualRegulated168 – 24 – – 5/52.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRF5.2SPLRThrough HoleSingleRegulated168 – 245.25 – – – –
DatasheetMechanical Drawing3D Model
PLRF48SPLRThrough HoleSingleRegulated168 – 24485 – – – –
DatasheetMechanical Drawing3D Model
PLRF48DPLRThrough HoleDualRegulated168 – 24 – – 48/482.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRF3.3SPLRThrough HoleSingleRegulated168 – 243.34 – – – –
DatasheetMechanical Drawing3D Model
PLRF28SPLRThrough HoleSingleRegulated168 – 24285 – – – –
DatasheetMechanical Drawing3D Model
PLRF28DPLRThrough HoleDualRegulated168 – 24 – – 28/282.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRF24SPLRThrough HoleSingleRegulated168 – 24245 – – – –
DatasheetMechanical Drawing3D Model
PLRF24DPLRThrough HoleDualRegulated168 – 24 – – 24/242.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRF15SPLRThrough HoleSingleRegulated168 – 24155 – – – –
DatasheetMechanical Drawing3D Model
PLRF15DPLRThrough HoleDualRegulated168 – 24 – – 15/152.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRF12SPLRThrough HoleSingleRegulated168 – 24125 – – – –
DatasheetMechanical Drawing3D Model
PLRF12DPLRThrough HoleDualRegulated168 – 24 – – 12/122.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRF100SPLRThrough HoleSingleRegulated168 – 241005 – – – –
DatasheetMechanical Drawing3D Model
PLRE9SPLRThrough HoleSingleRegulated105 – 1594 – – – –
DatasheetMechanical Drawing3D Model
PLRE9DPLRThrough HoleDualRegulated105 – 15 – – 9/92/2 – –
DatasheetMechanical Drawing3D Model
PLRE5SPLRThrough HoleSingleRegulated105 – 1553 – – – –
DatasheetMechanical Drawing3D Model
PLRE5DPLRThrough HoleDualRegulated105 – 15 – – 5/51.5/1.5 – –
DatasheetMechanical Drawing3D Model
PLRE5.2SPLRThrough HoleSingleRegulated105 – 155.23 – – – –
DatasheetMechanical Drawing3D Model
PLRE48SPLRThrough HoleSingleRegulated105 – 15484 – – – –
DatasheetMechanical Drawing3D Model
PLRE48DPLRThrough HoleDualRegulated105 – 15 – – 48/482/2 – –
DatasheetMechanical Drawing3D Model
PLRE3.3SPLRThrough HoleSingleRegulated105 – 153.33 – – – –
DatasheetMechanical Drawing3D Model
PLRE28SPLRThrough HoleSingleRegulated105 – 15284 – – – –
DatasheetMechanical Drawing3D Model
PLRE28DPLRThrough HoleDualRegulated105 – 15 – – 28/282/2 – –
DatasheetMechanical Drawing3D Model
PLRE24SPLRThrough HoleSingleRegulated105 – 15244 – – – –
DatasheetMechanical Drawing3D Model
PLRE24DPLRThrough HoleDualRegulated105 – 15 – – 24/242/2 – –
DatasheetMechanical Drawing3D Model
PLRE15SPLRThrough HoleSingleRegulated105 – 15154 – – – –
DatasheetMechanical Drawing3D Model
PLRE15DPLRThrough HoleDualRegulated105 – 15 – – 15/152/2 – –
DatasheetMechanical Drawing3D Model
PLRE12SPLRThrough HoleSingleRegulated105 – 15124 – – – –
DatasheetMechanical Drawing3D Model
PLRE12DPLRThrough HoleDualRegulated105 – 15 – – 12/122/2 – –
DatasheetMechanical Drawing3D Model
PLRE100SPLRThrough HoleSingleRegulated105 – 151004 – – – –
DatasheetMechanical Drawing3D Model
PLRC9SPLRThrough HoleSingleRegulated3918 – 6095 – – – –
DatasheetMechanical Drawing3D Model
PLRC9DPLRThrough HoleDualRegulated3918 – 60 – – 9/92.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRC5SPLRThrough HoleSingleRegulated3918 – 6055 – – – –
DatasheetMechanical Drawing3D Model
PLRC5DPLRThrough HoleDualRegulated3918 – 60 – – 5/52.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRC5.2SPLRThrough HoleSingleRegulated3918 – 605.25 – – – –
DatasheetMechanical Drawing3D Model
PLRC48SPLRThrough HoleSingleRegulated3918 – 60485 – – – –
DatasheetMechanical Drawing3D Model
PLRC48DPLRThrough HoleDualRegulated3918 – 60 – – 48/482.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRC3.3SPLRThrough HoleSingleRegulated3918 – 603.34 – – – –
DatasheetMechanical Drawing3D Model
PLRC28SPLRThrough HoleSingleRegulated3918 – 60285 – – – –
DatasheetMechanical Drawing3D Model
PLRC28DPLRThrough HoleDualRegulated3918 – 60 – – 28/282.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRC24SPLRThrough HoleSingleRegulated3918 – 60245 – – – –
DatasheetMechanical Drawing3D Model
PLRC24DPLRThrough HoleDualRegulated3918 – 60 – – 24/242.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRC15SPLRThrough HoleSingleRegulated3918 – 60155 – – – –
DatasheetMechanical Drawing3D Model
PLRC15DPLRThrough HoleDualRegulated3918 – 60 – – 15/152.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRC12SPLRThrough HoleSingleRegulated3918 – 60125 – – – –
DatasheetMechanical Drawing3D Model
PLRC12DPLRThrough HoleDualRegulated3918 – 60 – – 12/122.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRC100SPLRThrough HoleSingleRegulated3918 – 601005 – – – –
DatasheetMechanical Drawing3D Model
PLRB9SPLRThrough HoleSingleRegulated4836 – 6095 – – – –
DatasheetMechanical Drawing3D Model
PLRB9DPLRThrough HoleDualRegulated4836 – 60 – – 9/92.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRB5SPLRThrough HoleSingleRegulated4836 – 6055 – – – –
DatasheetMechanical Drawing3D Model
PLRB5DPLRThrough HoleDualRegulated4836 – 60 – – 5/52.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRB5.2SPLRThrough HoleSingleRegulated4836 – 605.25 – – – –
DatasheetMechanical Drawing3D Model
PLRB48SPLRThrough HoleSingleRegulated4836 – 60485 – – – –
DatasheetMechanical Drawing3D Model
PLRB48DPLRThrough HoleDualRegulated4836 – 60 – – 48/482.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRB3.3SPLRThrough HoleSingleRegulated4836 – 603.34 – – – –
DatasheetMechanical Drawing3D Model
PLRB28SPLRThrough HoleSingleRegulated4836 – 60285 – – – –
DatasheetMechanical Drawing3D Model
PLRB28DPLRThrough HoleDualRegulated4836 – 60 – – 28/282.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRB24SPLRThrough HoleSingleRegulated4836 – 60245 – – – –
DatasheetMechanical Drawing3D Model
PLRB24DPLRThrough HoleDualRegulated4836 – 60 – – 24/242.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRB15SPLRThrough HoleSingleRegulated4836 – 60155 – – – –
DatasheetMechanical Drawing3D Model
PLRB15DPLRThrough HoleDualRegulated4836 – 60 – – 15/152.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRB12SPLRThrough HoleSingleRegulated4836 – 60125 – – – –
DatasheetMechanical Drawing3D Model
PLRB12DPLRThrough HoleDualRegulated4836 – 60 – – 12/122.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRB100SPLRThrough HoleSingleRegulated4836 – 601005 – – – –
DatasheetMechanical Drawing3D Model
PLRA9SPLRThrough HoleSingleRegulated2718 – 3695 – – – –
DatasheetMechanical Drawing3D Model
PLRA9DPLRThrough HoleDualRegulated2718 – 36 – – 9/92.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRA5SPLRThrough HoleSingleRegulated2718 – 3655 – – – –
DatasheetMechanical Drawing3D Model
PLRA5DPLRThrough HoleDualRegulated2718 – 36 – – 5/52.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRA5.2SPLRThrough HoleSingleRegulated2718 – 365.25 – – – –
DatasheetMechanical Drawing3D Model
PLRA48SPLRThrough HoleSingleRegulated2718 – 36485 – – – –
DatasheetMechanical Drawing3D Model
PLRA48DPLRThrough HoleDualRegulated2718 – 36 – – 48/482.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRA3.3SPLRThrough HoleSingleRegulated2718 – 363.34 – – – –
DatasheetMechanical Drawing3D Model
PLRA28SPLRThrough HoleSingleRegulated2718 – 36285 – – – –
DatasheetMechanical Drawing3D Model
PLRA28DPLRThrough HoleDualRegulated2718 – 36 – – 28/282.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRA24SPLRThrough HoleSingleRegulated2718 – 36245 – – – –
DatasheetMechanical Drawing3D Model
PLRA24DPLRThrough HoleDualRegulated2718 – 36 – – 24/242.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRA15SPLRThrough HoleSingleRegulated2718 – 36155 – – – –
DatasheetMechanical Drawing3D Model
PLRA15DPLRThrough HoleDualRegulated2718 – 36 – – 15/152.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRA12SPLRThrough HoleSingleRegulated2718 – 36125 – – – –
DatasheetMechanical Drawing3D Model
PLRA12DPLRThrough HoleDualRegulated2718 – 36 – – 12/122.5/2.5 – –
DatasheetMechanical Drawing3D Model
PLRA100SPLRThrough HoleSingleRegulated2718 – 361005 – – – –
DatasheetMechanical Drawing3D Model
ORF9SORThrough HoleSingleRegulated168 – 2492 – – – –
DatasheetMechanical Drawing3D Model
ORF9DORThrough HoleDualRegulated168 – 24 – – 9/91/1 – –
DatasheetMechanical Drawing3D Model
ORF5SORThrough HoleSingleRegulated168 – 2452 – – – –
DatasheetMechanical Drawing3D Model
ORF5DORThrough HoleDualRegulated168 – 24 – – 5/51/1 – –
DatasheetMechanical Drawing3D Model
ORF5.2SORThrough HoleSingleRegulated168 – 245.22 – – – –
DatasheetMechanical Drawing3D Model
ORF3.3SORThrough HoleSingleRegulated168 – 243.31.5 – – – –
DatasheetMechanical Drawing3D Model
ORF28SORThrough HoleSingleRegulated168 – 24282 – – – –
DatasheetMechanical Drawing3D Model
ORF28DORThrough HoleDualRegulated168 – 24 – – 28/281/1 – –
DatasheetMechanical Drawing3D Model
ORF24SORThrough HoleSingleRegulated168 – 24242 – – – –
DatasheetMechanical Drawing3D Model
ORF24DORThrough HoleDualRegulated168 – 24 – – 24/241/1 – –
DatasheetMechanical Drawing3D Model
ORF15SORThrough HoleSingleRegulated168 – 24152 – – – –
DatasheetMechanical Drawing3D Model
ORF15DORThrough HoleDualRegulated168 – 24 – – 15/151/1 – –
DatasheetMechanical Drawing3D Model
ORF12SORThrough HoleSingleRegulated168 – 24122 – – – –
DatasheetMechanical Drawing3D Model
ORF12DORThrough HoleDualRegulated168 – 24 – – 12/121/1 – –
DatasheetMechanical Drawing3D Model
ORE9SORThrough HoleSingleRegulated105 – 1591.5 – – – –
DatasheetMechanical Drawing3D Model
ORE9DORThrough HoleDualRegulated105 – 15 – – 9/90.75/0.75 – –
DatasheetMechanical Drawing3D Model
ORE5SORThrough HoleSingleRegulated105 – 1551.5 – – – –
DatasheetMechanical Drawing3D Model
ORE5DORThrough HoleDualRegulated105 – 15 – – 5/50.75/0.75 – –
DatasheetMechanical Drawing3D Model
ORE5.2SORThrough HoleSingleRegulated105 – 155.21.5 – – – –
DatasheetMechanical Drawing3D Model
ORE3.3SORThrough HoleSingleRegulated105 – 153.31.2 – – – –
DatasheetMechanical Drawing3D Model
ORE28SORThrough HoleSingleRegulated105 – 15281.5 – – – –
DatasheetMechanical Drawing3D Model
ORE28DORThrough HoleDualRegulated105 – 15 – – 28/280.75/0.75 – –
DatasheetMechanical Drawing3D Model
ORE24SORThrough HoleSingleRegulated105 – 15241.5 – – – –
DatasheetMechanical Drawing3D Model
ORE24DORThrough HoleDualRegulated105 – 15 – – 24/240.75/0.75 – –
DatasheetMechanical Drawing3D Model
ORE15SORThrough HoleSingleRegulated105 – 15151.5 – – – –
DatasheetMechanical Drawing3D Model
ORE15DORThrough HoleDualRegulated105 – 15 – – 15/150.75/0.75 – –
DatasheetMechanical Drawing3D Model
ORE12SORThrough HoleSingleRegulated105 – 15121.5 – – – –
DatasheetMechanical Drawing3D Model
ORE12DORThrough HoleDualRegulated105 – 15 – – 12/120.75/0.75 – –
DatasheetMechanical Drawing3D Model
ORA9SORThrough HoleSingleRegulated2718 – 3692.5 – – – –
DatasheetMechanical Drawing3D Model
ORA9DORThrough HoleDualRegulated2718 – 36 – – 9/91.25/1.25 – –
DatasheetMechanical Drawing3D Model
ORA5SORThrough HoleSingleRegulated2718 – 3652 – – – –
DatasheetMechanical Drawing3D Model
ORA5DORThrough HoleDualRegulated2718 – 36 – – 5/51/1 – –
DatasheetMechanical Drawing3D Model
ORA5.2SORThrough HoleSingleRegulated2718 – 365.22 – – – –
DatasheetMechanical Drawing3D Model
ORA3.3SORThrough HoleSingleRegulated2718 – 363.31.5 – – – –
DatasheetMechanical Drawing3D Model
ORA28SORThrough HoleSingleRegulated2718 – 36282.5 – – – –
DatasheetMechanical Drawing3D Model
ORA28DORThrough HoleDualRegulated2718 – 36 – – 28/281.25/1.25 – –
DatasheetMechanical Drawing3D Model
ORA24SORThrough HoleSingleRegulated2718 – 36242.5 – – – –
DatasheetMechanical Drawing3D Model
ORA24DORThrough HoleDualRegulated2718 – 36 – – 24/241.25/1.25 – –
DatasheetMechanical Drawing3D Model
ORA15SORThrough HoleSingleRegulated2718 – 36152.5 – – – –
DatasheetMechanical Drawing3D Model
ORA15DORThrough HoleDualRegulated2718 – 36 – – 15/151.25/1.25 – –
DatasheetMechanical Drawing3D Model
ORA12SORThrough HoleSingleRegulated2718 – 36122.5 – – – –
DatasheetMechanical Drawing3D Model
ORA12DORThrough HoleDualRegulated2718 – 36 – – 12/121.25/1.25 – –
DatasheetMechanical Drawing3D Model
NRF9SNRThrough HoleSingleRegulated2010 – 30925 – – – –
DatasheetMechanical Drawing3D Model
NRF9DNRThrough HoleDualRegulated2010 – 30 – – ±9±12.5 – –
DatasheetMechanical Drawing3D Model
NRF5SNRThrough HoleSingleRegulated2010 – 30520 – – – –
DatasheetMechanical Drawing3D Model
NRF5DNRThrough HoleDualRegulated2010 – 30 – – ±5±10 – –
DatasheetMechanical Drawing3D Model
NRF5.2SNRThrough HoleSingleRegulated2010 – 305.220 – – – –
DatasheetMechanical Drawing3D Model
NRF3.3SNRThrough HoleSingleRegulated2010 – 303.315 – – – –
DatasheetMechanical Drawing3D Model
NRF28SNRThrough HoleSingleRegulated2010 – 302825 – – – –
DatasheetMechanical Drawing3D Model
NRF24SNRThrough HoleSingleRegulated2010 – 302425 – – – –
DatasheetMechanical Drawing3D Model
NRF15SNRThrough HoleSingleRegulated2010 – 301525 – – – –
DatasheetMechanical Drawing3D Model
NRF15DNRThrough HoleDualRegulated2010 – 30 – – ±15±12.5 – –
DatasheetMechanical Drawing3D Model
NRF12SNRThrough HoleSingleRegulated2010 – 301225 – – – –
DatasheetMechanical Drawing3D Model
NRF12DNRThrough HoleDualRegulated2010 – 30 – – ±12±12.5 – –
DatasheetMechanical Drawing3D Model
NRB9T5NRThrough HoleTripleRegulated5436 – 72 – – – – 9, ±520, ±2.5
DatasheetMechanical Drawing3D Model
NRB9T15NRThrough HoleTripleRegulated5436 – 72 – – – – 9, ±1520, ±2.5
DatasheetMechanical Drawing3D Model
NRB9T12NRThrough HoleTripleRegulated5436 – 72 – – – – 9, ±1220, ±2.5
DatasheetMechanical Drawing3D Model
NRB9SNRThrough HoleSingleRegulated5436 – 72925 – – – –
DatasheetMechanical Drawing3D Model
NRB9DNRThrough HoleDualRegulated5436 – 72 – – ±9±12.5 – –
DatasheetMechanical Drawing3D Model
NRB5T15NRThrough HoleTripleRegulated5436 – 72 – – – – 5, ±1517, ±2.5
DatasheetMechanical Drawing3D Model
NRB5T12NRThrough HoleTripleRegulated5436 – 72 – – – – 5, ±1217, ±2.5
DatasheetMechanical Drawing3D Model
NRB5SNRThrough HoleSingleRegulated5436 – 72522 – – – –
DatasheetMechanical Drawing3D Model
NRB5DNRThrough HoleDualRegulated5436 – 72 – – ±5±11 – –
DatasheetMechanical Drawing3D Model
NRB5.2SNRThrough HoleSingleRegulated5436 – 725.222 – – – –
DatasheetMechanical Drawing3D Model
NRB3.3SNRThrough HoleSingleRegulated5436 – 723.320 – – – –
DatasheetMechanical Drawing3D Model
NRB28T5NRThrough HoleTripleRegulated5436 – 72 – – – – 28, ±525, ±2.5
DatasheetMechanical Drawing3D Model
NRB28T15NRThrough HoleTripleRegulated5436 – 72 – – – – 28, ±1525, ±2.5
DatasheetMechanical Drawing3D Model
NRB28T12NRThrough HoleTripleRegulated5436 – 72 – – – – 28, ±1225, ±2.5
DatasheetMechanical Drawing3D Model
NRB28SNRThrough HoleSingleRegulated5436 – 722830 – – – –
DatasheetMechanical Drawing3D Model
NRB24T5NRThrough HoleTripleRegulated5436 – 72 – – – – 24, ±525, ±2.5
DatasheetMechanical Drawing3D Model
NRB24T15NRThrough HoleTripleRegulated5436 – 72 – – – – 24, ±1525, ±2.5
DatasheetMechanical Drawing3D Model
NRB24T12NRThrough HoleTripleRegulated5436 – 72 – – – – 24, ±1225, ±2.5
DatasheetMechanical Drawing3D Model
NRB24SNRThrough HoleSingleRegulated5436 – 722430 – – – –
DatasheetMechanical Drawing3D Model
NRB15T5NRThrough HoleTripleRegulated5436 – 72 – – – – 15, ±525, ±2.5
DatasheetMechanical Drawing3D Model
NRB15T12NRThrough HoleTripleRegulated5436 – 72 – – – – 15, ±1225, ±2.5
DatasheetMechanical Drawing3D Model
NRB15SNRThrough HoleSingleRegulated5436 – 721530 – – – –
DatasheetMechanical Drawing3D Model
NRB15DNRThrough HoleDualRegulated5436 – 72 – – ±15±12.5 – –
DatasheetMechanical Drawing3D Model
NRB12T5NRThrough HoleTripleRegulated5436 – 72 – – – – 12, ±520, ±2.5
DatasheetMechanical Drawing3D Model
NRB12T15NRThrough HoleTripleRegulated5436 – 72 – – – – 12, ±1520, ±2.5
DatasheetMechanical Drawing3D Model
NRB12SNRThrough HoleSingleRegulated5436 – 721225 – – – –
DatasheetMechanical Drawing3D Model
NRB12DNRThrough HoleDualRegulated5436 – 72 – – ±12±12.5 – –
DatasheetMechanical Drawing3D Model
NRA9T5NRThrough HoleTripleRegulated2718 – 36 – – – – 9, ±520, ±2.5
DatasheetMechanical Drawing3D Model
NRA9T15NRThrough HoleTripleRegulated2718 – 36 – – – – 9, ±1520, ±2.5
DatasheetMechanical Drawing3D Model
NRA9T12NRThrough HoleTripleRegulated2718 – 36 – – – – 9, ±1220, ±2.5
DatasheetMechanical Drawing3D Model
NRA9SNRThrough HoleSingleRegulated2718 – 36925 – – – –
DatasheetMechanical Drawing3D Model
NRA9DNRThrough HoleDualRegulated2718 – 36 – – ±9±12.5 – –
DatasheetMechanical Drawing3D Model
NRA5T15NRThrough HoleTripleRegulated2718 – 36 – – – – 5, ±1515, ±2.5
DatasheetMechanical Drawing3D Model
NRA5T12NRThrough HoleTripleRegulated2718 – 36 – – – – 5, ±1215, ±2.5
DatasheetMechanical Drawing3D Model
NRA5SNRThrough HoleSingleRegulated2718 – 36520 – – – –
DatasheetMechanical Drawing3D Model
NRA5DNRThrough HoleDualRegulated2718 – 36 – – ±5±10 – –
DatasheetMechanical Drawing3D Model
NRA5.2SNRThrough HoleSingleRegulated2718 – 365.220 – – – –
DatasheetMechanical Drawing3D Model
NRA3.3SNRThrough HoleSingleRegulated2718 – 363.315 – – – –
DatasheetMechanical Drawing3D Model
NRA28T5NRThrough HoleTripleRegulated2718 – 36 – – – – 28, ±520, ±2.5
DatasheetMechanical Drawing3D Model
NRA28T15NRThrough HoleTripleRegulated2718 – 36 – – – – 28, ±1520, ±2.5
DatasheetMechanical Drawing3D Model
NRA28T12NRThrough HoleTripleRegulated2718 – 36 – – – – 28, ±1220, ±2.5
DatasheetMechanical Drawing3D Model
NRA28SNRThrough HoleSingleRegulated2718 – 362825 – – – –
DatasheetMechanical Drawing3D Model
NRA24T5NRThrough HoleTripleRegulated2718 – 36 – – – – 24, ±520, ±2.5
DatasheetMechanical Drawing3D Model
NRA24T15NRThrough HoleTripleRegulated2718 – 36 – – – – 24, ±1520, ±2.5
DatasheetMechanical Drawing3D Model
NRA24T12NRThrough HoleTripleRegulated2718 – 36 – – – – 24, ±1220, ±2.5
DatasheetMechanical Drawing3D Model
NRA24SNRThrough HoleSingleRegulated2718 – 362425 – – – –
DatasheetMechanical Drawing3D Model
NRA15T5NRThrough HoleTripleRegulated2718 – 36 – – – – 15, ±520, ±2.5
DatasheetMechanical Drawing3D Model
NRA15T12NRThrough HoleTripleRegulated2718 – 36 – – – – 15, ±1220, ±2.5
DatasheetMechanical Drawing3D Model
NRA15SNRThrough HoleSingleRegulated2718 – 361525 – – – –
DatasheetMechanical Drawing3D Model
NRA15DNRThrough HoleDualRegulated2718 – 36 – – ±15±12.5 – –
DatasheetMechanical Drawing3D Model
NRA12T5NRThrough HoleTripleRegulated2718 – 36 – – – – 12, ±520, ±2.5
DatasheetMechanical Drawing3D Model
NRA12T15NRThrough HoleTripleRegulated2718 – 36 – – – – 12, ±1520, ±2.5
DatasheetMechanical Drawing3D Model
NRA12SNRThrough HoleSingleRegulated2718 – 361225 – – – –
DatasheetMechanical Drawing3D Model
NRA12DNRThrough HoleDualRegulated2718 – 36 – – ±12±12.5 – –
DatasheetMechanical Drawing3D Model
MRF9SMRThrough HoleSingleRegulated168 – 2492 – – – –
DatasheetMechanical Drawing3D Model
MRF9DMRThrough HoleDualRegulated168 – 24 – – 9/91/1 – –
DatasheetMechanical Drawing3D Model
MRF5SMRThrough HoleSingleRegulated168 – 2452 – – – –
DatasheetMechanical Drawing3D Model
MRF5DMRThrough HoleDualRegulated168 – 24 – – 5/51/1 – –
DatasheetMechanical Drawing3D Model
MRF5.2SMRThrough HoleSingleRegulated168 – 245.22 – – – –
DatasheetMechanical Drawing3D Model
MRF3.3SMRThrough HoleSingleRegulated168 – 243.31.75 – – – –
DatasheetMechanical Drawing3D Model
MRF28SMRThrough HoleSingleRegulated168 – 24282 – – – –
DatasheetMechanical Drawing3D Model
MRF28DMRThrough HoleDualRegulated168 – 24 – – 28/281/1 – –
DatasheetMechanical Drawing3D Model
MRF24SMRThrough HoleSingleRegulated168 – 24242 – – – –
DatasheetMechanical Drawing3D Model
MRF24DMRThrough HoleDualRegulated168 – 24 – – 24/241/1 – –
DatasheetMechanical Drawing3D Model
MRF15SMRThrough HoleSingleRegulated168 – 24152 – – – –
DatasheetMechanical Drawing3D Model
MRF15DMRThrough HoleDualRegulated168 – 24 – – 15/151/1 – –
DatasheetMechanical Drawing3D Model
MRF12SMRThrough HoleSingleRegulated168 – 24122 – – – –
DatasheetMechanical Drawing3D Model
MRF12DMRThrough HoleDualRegulated168 – 24 – – 12/121/1 – –
DatasheetMechanical Drawing3D Model
MRE9SMRThrough HoleSingleRegulated105 – 1591.5 – – – –
DatasheetMechanical Drawing3D Model
MRE9DMRThrough HoleDualRegulated105 – 15 – – 9/90.75/0.75 – –
DatasheetMechanical Drawing3D Model
MRE5SMRThrough HoleSingleRegulated105 – 1551.5 – – – –
DatasheetMechanical Drawing3D Model
MRE5DMRThrough HoleDualRegulated105 – 15 – – 5/50.75/0.75 – –
DatasheetMechanical Drawing3D Model
MRE5.2SMRThrough HoleSingleRegulated105 – 155.21.5 – – – –
DatasheetMechanical Drawing3D Model
MRE3.3SMRThrough HoleSingleRegulated105 – 153.31.25 – – – –
DatasheetMechanical Drawing3D Model
MRE28SMRThrough HoleSingleRegulated105 – 15281.5 – – – –
DatasheetMechanical Drawing3D Model
MRE28DMRThrough HoleDualRegulated105 – 15 – – 28/280.75/0.75 – –
DatasheetMechanical Drawing3D Model
MRE24SMRThrough HoleSingleRegulated105 – 15241.5 – – – –
DatasheetMechanical Drawing3D Model
MRE24DMRThrough HoleDualRegulated105 – 15 – – 24/240.75/0.75 – –
DatasheetMechanical Drawing3D Model
MRE15SMRThrough HoleSingleRegulated105 – 15151.5 – – – –
DatasheetMechanical Drawing3D Model
MRE15DMRThrough HoleDualRegulated105 – 15 – – 15/150.75/0.75 – –
DatasheetMechanical Drawing3D Model
MRE12SMRThrough HoleSingleRegulated105 – 15121.5 – – – –
DatasheetMechanical Drawing3D Model
MRE12DMRThrough HoleDualRegulated105 – 15 – – 12/120.75/0.75 – –
DatasheetMechanical Drawing3D Model
MRA9SMRThrough HoleSingleRegulated2718 – 3692.5 – – – –
DatasheetMechanical Drawing3D Model
MRA9DMRThrough HoleDualRegulated2718 – 36 – – 9/91.25/1.25 – –
DatasheetMechanical Drawing3D Model
MRA5SMRThrough HoleSingleRegulated2718 – 3652 – – – –
DatasheetMechanical Drawing3D Model
MRA5DMRThrough HoleDualRegulated2718 – 36 – – 5/51/1 – –
DatasheetMechanical Drawing3D Model
MRA5.2SMRThrough HoleSingleRegulated2718 – 365.22 – – – –
DatasheetMechanical Drawing3D Model
MRA3.3SMRThrough HoleSingleRegulated2718 – 363.31.75 – – – –
DatasheetMechanical Drawing3D Model
MRA28SMRThrough HoleSingleRegulated2718 – 36282.5 – – – –
DatasheetMechanical Drawing3D Model
MRA28DMRThrough HoleDualRegulated2718 – 36 – – 28/281.25/1.25 – –
DatasheetMechanical Drawing3D Model
MRA24SMRThrough HoleSingleRegulated2718 – 36242.5 – – – –
DatasheetMechanical Drawing3D Model
MRA24DMRThrough HoleDualRegulated2718 – 36 – – 24/241.25/1.25 – –
DatasheetMechanical Drawing3D Model
MRA15SMRThrough HoleSingleRegulated2718 – 36152.5 – – – –
DatasheetMechanical Drawing3D Model
MRA15DMRThrough HoleDualRegulated2718 – 36 – – 15/151.25/1.25 – –
DatasheetMechanical Drawing3D Model
MRA12SMRThrough HoleSingleRegulated2718 – 36122.5 – – – –
DatasheetMechanical Drawing3D Model
MRA12DMRThrough HoleDualRegulated2718 – 36 – – 12/121.25/1.25 – –
DatasheetMechanical Drawing3D Model
LVD5SLVThrough HoleSingleRegulated4836 – 8059 – – – –
DatasheetMechanical Drawing3D Model
LVD5DLVThrough HoleDualRegulated4836 – 80 – – ±5±4.5 – –
DatasheetMechanical Drawing3D Model
LVD5.2SLVThrough HoleSingleRegulated4836 – 805.29 – – – –
DatasheetMechanical Drawing3D Model
LVD48SLVThrough HoleSingleRegulated4836 – 804810 – – – –
DatasheetMechanical Drawing3D Model
LVD3.3SLVThrough HoleSingleRegulated4836 – 803.37 – – – –
DatasheetMechanical Drawing3D Model
LVD28SLVThrough HoleSingleRegulated4836 – 802810 – – – –
DatasheetMechanical Drawing3D Model
LVD24SLVThrough HoleSingleRegulated4836 – 802410 – – – –
DatasheetMechanical Drawing3D Model
LVD15SLVThrough HoleSingleRegulated4836 – 801510 – – – –
DatasheetMechanical Drawing3D Model
LVD15DLVThrough HoleDualRegulated4836 – 80 – – ±15±5 – –
DatasheetMechanical Drawing3D Model
LVD12SLVThrough HoleSingleRegulated4836 – 801210 – – – –
DatasheetMechanical Drawing3D Model
LVD12DLVThrough HoleDualRegulated4836 – 80 – – ±12±5 – –
DatasheetMechanical Drawing3D Model
LVC5SLVThrough HoleSingleRegulated4836 – 8057 – – – –
DatasheetMechanical Drawing3D Model
LVC5DLVThrough HoleDualRegulated4836 – 80 – – ±5±3.5 – –
DatasheetMechanical Drawing3D Model
LVC5.2SLVThrough HoleSingleRegulated4836 – 805.27 – – – –
DatasheetMechanical Drawing3D Model
LVC48SLVThrough HoleSingleRegulated4836 – 80488 – – – –
DatasheetMechanical Drawing3D Model
LVC3.3SLVThrough HoleSingleRegulated4836 – 803.35 – – – –
DatasheetMechanical Drawing3D Model
LVC28SLVThrough HoleSingleRegulated4836 – 80288 – – – –
DatasheetMechanical Drawing3D Model
LVC24SLVThrough HoleSingleRegulated4836 – 80248 – – – –
DatasheetMechanical Drawing3D Model
LVC15SLVThrough HoleSingleRegulated4836 – 80158 – – – –
DatasheetMechanical Drawing3D Model
LVC15DLVThrough HoleDualRegulated4836 – 80 – – ±15±4 – –
DatasheetMechanical Drawing3D Model
LVC12SLVThrough HoleSingleRegulated4836 – 80128 – – – –
DatasheetMechanical Drawing3D Model
LVC12DLVThrough HoleDualRegulated4836 – 80 – – ±12±4 – –
DatasheetMechanical Drawing3D Model
LVB5SLVThrough HoleSingleRegulated4836 – 8055 – – – –
DatasheetMechanical Drawing3D Model
LVB5DLVThrough HoleDualRegulated4836 – 80 – – ±5±2.5 – –
DatasheetMechanical Drawing3D Model
LVB5.2SLVThrough HoleSingleRegulated4836 – 805.25 – – – –
DatasheetMechanical Drawing3D Model
LVB48SLVThrough HoleSingleRegulated4836 – 80485 – – – –
DatasheetMechanical Drawing3D Model
LVB3.3SLVThrough HoleSingleRegulated4836 – 803.34 – – – –
DatasheetMechanical Drawing3D Model
LVB28SLVThrough HoleSingleRegulated4836 – 80285 – – – –
DatasheetMechanical Drawing3D Model
LVB24SLVThrough HoleSingleRegulated4836 – 80245 – – – –
DatasheetMechanical Drawing3D Model
LVB15SLVThrough HoleSingleRegulated4836 – 80155 – – – –
DatasheetMechanical Drawing3D Model
LVB15DLVThrough HoleDualRegulated4836 – 80 – – ±15±2.5 – –
DatasheetMechanical Drawing3D Model
LVB12SLVThrough HoleSingleRegulated4836 – 80125 – – – –
DatasheetMechanical Drawing3D Model
LVB12DLVThrough HoleDualRegulated4836 – 80 – – ±12±2.5 – –
DatasheetMechanical Drawing3D Model
LVA5SLVThrough HoleSingleRegulated4836 – 8053 – – – –
DatasheetMechanical Drawing3D Model
LVA5DLVThrough HoleDualRegulated4836 – 80 – – ±5±1.5 – –
DatasheetMechanical Drawing3D Model
LVA5.2SLVThrough HoleSingleRegulated4836 – 805.23 – – – –
DatasheetMechanical Drawing3D Model
LVA48SLVThrough HoleSingleRegulated4836 – 80483 – – – –
DatasheetMechanical Drawing3D Model
LVA3.3SLVThrough HoleSingleRegulated4836 – 803.32 – – – –
DatasheetMechanical Drawing3D Model
LVA28SLVThrough HoleSingleRegulated4836 – 80283 – – – –
DatasheetMechanical Drawing3D Model
LVA24SLVThrough HoleSingleRegulated4836 – 80243 – – – –
DatasheetMechanical Drawing3D Model
LVA15SLVThrough HoleSingleRegulated4836 – 80153 – – – –
DatasheetMechanical Drawing3D Model
LVA15DLVThrough HoleDualRegulated4836 – 80 – – ±15±1.5 – –
DatasheetMechanical Drawing3D Model
LVA12SLVThrough HoleSingleRegulated4836 – 80123 – – – –
DatasheetMechanical Drawing3D Model
LVA12DLVThrough HoleDualRegulated4836 – 80 – – ±12±1.5 – –
DatasheetMechanical Drawing3D Model
LRF9SLRThrough HoleSingleRegulated168 – 2495 – – – –
DatasheetMechanical Drawing3D Model
LRF9DLRThrough HoleDualRegulated168 – 24 – – 9/92.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRF5SLRThrough HoleSingleRegulated168 – 2455 – – – –
DatasheetMechanical Drawing3D Model
LRF5DLRThrough HoleDualRegulated168 – 24 – – 5/52.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRF5.2SLRThrough HoleSingleRegulated168 – 245.25 – – – –
DatasheetMechanical Drawing3D Model
LRF48SLRThrough HoleSingleRegulated168 – 24485 – – – –
DatasheetMechanical Drawing3D Model
LRF48DLRThrough HoleDualRegulated168 – 24 – – 48/482.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRF3.3SLRThrough HoleSingleRegulated168 – 243.34 – – – –
DatasheetMechanical Drawing3D Model
LRF2SLRThrough HoleSingleRegulated168 – 2423 – – – –
DatasheetMechanical Drawing3D Model
LRF28SLRThrough HoleSingleRegulated168 – 24285 – – – –
DatasheetMechanical Drawing3D Model
LRF28DLRThrough HoleDualRegulated168 – 24 – – 28/282.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRF24SLRThrough HoleSingleRegulated168 – 24245 – – – –
DatasheetMechanical Drawing3D Model
LRF24DLRThrough HoleDualRegulated168 – 24 – – 24/242.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRF15SLRThrough HoleSingleRegulated168 – 24155 – – – –
DatasheetMechanical Drawing3D Model
LRF15DLRThrough HoleDualRegulated168 – 24 – – 15/152.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRF12SLRThrough HoleSingleRegulated168 – 24125 – – – –
DatasheetMechanical Drawing3D Model
LRF12DLRThrough HoleDualRegulated168 – 24 – – 12/122.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRF100SLRThrough HoleSingleRegulated168 – 241005 – – – –
DatasheetMechanical Drawing3D Model
LRE9SLRThrough HoleSingleRegulated105 – 1594 – – – –
DatasheetMechanical Drawing3D Model
LRE9DLRThrough HoleDualRegulated105 – 15 – – 9/92/2 – –
DatasheetMechanical Drawing3D Model
LRE5SLRThrough HoleSingleRegulated105 – 1553 – – – –
DatasheetMechanical Drawing3D Model
LRE5DLRThrough HoleDualRegulated105 – 15 – – 5/51.5/1.5 – –
DatasheetMechanical Drawing3D Model
LRE5.2SLRThrough HoleSingleRegulated105 – 155.23 – – – –
DatasheetMechanical Drawing3D Model
LRE48SLRThrough HoleSingleRegulated105 – 15484 – – – –
DatasheetMechanical Drawing3D Model
LRE48DLRThrough HoleDualRegulated105 – 15 – – 48/482/2 – –
DatasheetMechanical Drawing3D Model
LRE3.3SLRThrough HoleSingleRegulated105 – 153.33 – – – –
DatasheetMechanical Drawing3D Model
LRE2SLRThrough HoleSingleRegulated105 – 1522 – – – –
DatasheetMechanical Drawing3D Model
LRE28SLRThrough HoleSingleRegulated105 – 15284 – – – –
DatasheetMechanical Drawing3D Model
LRE28DLRThrough HoleDualRegulated105 – 15 – – 28/282/2 – –
DatasheetMechanical Drawing3D Model
LRE24SLRThrough HoleSingleRegulated105 – 15244 – – – –
DatasheetMechanical Drawing3D Model
LRE24DLRThrough HoleDualRegulated105 – 15 – – 24/242/2 – –
DatasheetMechanical Drawing3D Model
LRE15SLRThrough HoleSingleRegulated105 – 15154 – – – –
DatasheetMechanical Drawing3D Model
LRE15DLRThrough HoleDualRegulated105 – 15 – – 15/152/2 – –
DatasheetMechanical Drawing3D Model
LRE12SLRThrough HoleSingleRegulated105 – 15124 – – – –
DatasheetMechanical Drawing3D Model
LRE12DLRThrough HoleDualRegulated105 – 15 – – 12/122/2 – –
DatasheetMechanical Drawing3D Model
LRE100SLRThrough HoleSingleRegulated105 – 151004 – – – –
DatasheetMechanical Drawing3D Model
LRC9SLRThrough HoleSingleRegulated3918 – 6095 – – – –
DatasheetMechanical Drawing3D Model
LRC9DLRThrough HoleDualRegulated3918 – 60 – – 9/92.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRC5SLRThrough HoleSingleRegulated3918 – 6055 – – – –
DatasheetMechanical Drawing3D Model
LRC5DLRThrough HoleDualRegulated3918 – 60 – – 5/52.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRC5.2SLRThrough HoleSingleRegulated3918 – 605.25 – – – –
DatasheetMechanical Drawing3D Model
LRC48SLRThrough HoleSingleRegulated3918 – 60485 – – – –
DatasheetMechanical Drawing3D Model
LRC48DLRThrough HoleDualRegulated3918 – 60 – – 48/482.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRC3.3SLRThrough HoleSingleRegulated3918 – 603.34 – – – –
DatasheetMechanical Drawing3D Model
LRC2SLRThrough HoleSingleRegulated3918 – 6023 – – – –
DatasheetMechanical Drawing3D Model
LRC28SLRThrough HoleSingleRegulated3918 – 60285 – – – –
DatasheetMechanical Drawing3D Model
LRC28DLRThrough HoleDualRegulated3918 – 60 – – 28/282.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRC24SLRThrough HoleSingleRegulated3918 – 60245 – – – –
DatasheetMechanical Drawing3D Model
LRC24DLRThrough HoleDualRegulated3918 – 60 – – 24/242.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRC15SLRThrough HoleSingleRegulated3918 – 60155 – – – –
DatasheetMechanical Drawing3D Model
LRC15DLRThrough HoleDualRegulated3918 – 60 – – 15/152.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRC12SLRThrough HoleSingleRegulated3918 – 60125 – – – –
DatasheetMechanical Drawing3D Model
LRC12DLRThrough HoleDualRegulated3918 – 60 – – 12/122.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRC100SLRThrough HoleSingleRegulated3918 – 601005 – – – –
DatasheetMechanical Drawing3D Model
LRB9SLRThrough HoleSingleRegulated4836 – 6095 – – – –
DatasheetMechanical Drawing3D Model
LRB9DLRThrough HoleDualRegulated4836 – 60 – – 9/92.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRB5SLRThrough HoleSingleRegulated4836 – 6055 – – – –
DatasheetMechanical Drawing3D Model
LRB5DLRThrough HoleDualRegulated4836 – 60 – – 5/52.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRB5.2SLRThrough HoleSingleRegulated4836 – 605.25 – – – –
DatasheetMechanical Drawing3D Model
LRB48SLRThrough HoleSingleRegulated4836 – 60485 – – – –
DatasheetMechanical Drawing3D Model
LRB48DLRThrough HoleDualRegulated4836 – 60 – – 48/482.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRB3.3SLRThrough HoleSingleRegulated4836 – 603.34 – – – –
DatasheetMechanical Drawing3D Model
LRB2SLRThrough HoleSingleRegulated4836 – 6023 – – – –
DatasheetMechanical Drawing3D Model
LRB28SLRThrough HoleSingleRegulated4836 – 60285 – – – –
DatasheetMechanical Drawing3D Model
LRB28DLRThrough HoleDualRegulated4836 – 60 – – 28/282.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRB24SLRThrough HoleSingleRegulated4836 – 60245 – – – –
DatasheetMechanical Drawing3D Model
LRB24DLRThrough HoleDualRegulated4836 – 60 – – 24/242.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRB15SLRThrough HoleSingleRegulated4836 – 60155 – – – –
DatasheetMechanical Drawing3D Model
LRB15DLRThrough HoleDualRegulated4836 – 60 – – 15/152.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRB12SLRThrough HoleSingleRegulated4836 – 60125 – – – –
DatasheetMechanical Drawing3D Model
LRB12DLRThrough HoleDualRegulated4836 – 60 – – 12/122.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRB100SLRThrough HoleSingleRegulated4836 – 601005 – – – –
DatasheetMechanical Drawing3D Model
LRA9SLRThrough HoleSingleRegulated2718 – 3695 – – – –
DatasheetMechanical Drawing3D Model
LRA9DLRThrough HoleDualRegulated2718 – 36 – – 9/92.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRA5SLRThrough HoleSingleRegulated2718 – 3655 – – – –
DatasheetMechanical Drawing3D Model
LRA5DLRThrough HoleDualRegulated2718 – 36 – – 5/52.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRA5.2SLRThrough HoleSingleRegulated2718 – 365.25 – – – –
DatasheetMechanical Drawing3D Model
LRA48SLRThrough HoleSingleRegulated2718 – 36485 – – – –
DatasheetMechanical Drawing3D Model
LRA48DLRThrough HoleDualRegulated2718 – 36 – – 48/482.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRA3.3SLRThrough HoleSingleRegulated2718 – 363.34 – – – –
DatasheetMechanical Drawing3D Model
LRA2SLRThrough HoleSingleRegulated2718 – 3623 – – – –
DatasheetMechanical Drawing3D Model
LRA28SLRThrough HoleSingleRegulated2718 – 36285 – – – –
DatasheetMechanical Drawing3D Model
LRA28DLRThrough HoleDualRegulated2718 – 36 – – 28/282.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRA24SLRThrough HoleSingleRegulated2718 – 36245 – – – –
DatasheetMechanical Drawing3D Model
LRA24DLRThrough HoleDualRegulated2718 – 36 – – 24/242.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRA15SLRThrough HoleSingleRegulated2718 – 36155 – – – –
DatasheetMechanical Drawing3D Model
LRA15DLRThrough HoleDualRegulated2718 – 36 – – 15/152.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRA12SLRThrough HoleSingleRegulated2718 – 36125 – – – –
DatasheetMechanical Drawing3D Model
LRA12DLRThrough HoleDualRegulated2718 – 36 – – 12/122.5/2.5 – –
DatasheetMechanical Drawing3D Model
LRA100SLRThrough HoleSingleRegulated2718 – 361005 – – – –
DatasheetMechanical Drawing3D Model
KRC9SKRThrough HoleSingleRegulated3918 – 60920 – – – –
DatasheetMechanical Drawing3D Model
KRC9DKRThrough HoleDualRegulated3918 – 60 – – 9/910/10 – –
DatasheetMechanical Drawing3D Model
KRC5SKRThrough HoleSingleRegulated3918 – 60520 – – – –
DatasheetMechanical Drawing3D Model
KRC5DKRThrough HoleDualRegulated3918 – 60 – – 5/510/10 – –
DatasheetMechanical Drawing3D Model
KRC5.2SKRThrough HoleSingleRegulated3918 – 605.220 – – – –
DatasheetMechanical Drawing3D Model
KRC48SKRThrough HoleSingleRegulated3918 – 604820 – – – –
DatasheetMechanical Drawing3D Model
KRC48DKRThrough HoleDualRegulated3918 – 60 – – 48/4810/10 – –
DatasheetMechanical Drawing3D Model
KRC3.3SKRThrough HoleSingleRegulated3918 – 603.320 – – – –
DatasheetMechanical Drawing3D Model
KRC28SKRThrough HoleSingleRegulated3918 – 602820 – – – –
DatasheetMechanical Drawing3D Model
KRC28DKRThrough HoleDualRegulated3918 – 60 – – 28/2810/10 – –
DatasheetMechanical Drawing3D Model
KRC24SKRThrough HoleSingleRegulated3918 – 602420 – – – –
DatasheetMechanical Drawing3D Model
KRC24DKRThrough HoleDualRegulated3918 – 60 – – 24/2410/10 – –
DatasheetMechanical Drawing3D Model
KRC15SKRThrough HoleSingleRegulated3918 – 601520 – – – –
DatasheetMechanical Drawing3D Model
KRC15DKRThrough HoleDualRegulated3918 – 60 – – 15/1510/10 – –
DatasheetMechanical Drawing3D Model
KRC12SKRThrough HoleSingleRegulated3918 – 601220 – – – –
DatasheetMechanical Drawing3D Model
KRC12DKRThrough HoleDualRegulated3918 – 60 – – 12/1210/10 – –
DatasheetMechanical Drawing3D Model
KRC100SKRThrough HoleSingleRegulated3918 – 6010020 – – – –
DatasheetMechanical Drawing3D Model
KRB9SKRThrough HoleSingleRegulated4836 – 60920 – – – –
DatasheetMechanical Drawing3D Model
KRB9DKRThrough HoleDualRegulated4836 – 60 – – 9/910/10 – –
DatasheetMechanical Drawing3D Model
KRB5SKRThrough HoleSingleRegulated4836 – 60520 – – – –
DatasheetMechanical Drawing3D Model
KRB5DKRThrough HoleDualRegulated4836 – 60 – – 5/510/10 – –
DatasheetMechanical Drawing3D Model
KRB5.2SKRThrough HoleSingleRegulated4836 – 605.220 – – – –
DatasheetMechanical Drawing3D Model
KRB48SKRThrough HoleSingleRegulated4836 – 604820 – – – –
DatasheetMechanical Drawing3D Model
KRB48DKRThrough HoleDualRegulated4836 – 60 – – 48/4810/10 – –
DatasheetMechanical Drawing3D Model
KRB3.3SKRThrough HoleSingleRegulated4836 – 603.320 – – – –
DatasheetMechanical Drawing3D Model
KRB28SKRThrough HoleSingleRegulated4836 – 602820 – – – –
DatasheetMechanical Drawing3D Model
KRB28DKRThrough HoleDualRegulated4836 – 60 – – 28/2810/10 – –
DatasheetMechanical Drawing3D Model
KRB24SKRThrough HoleSingleRegulated4836 – 602420 – – – –
DatasheetMechanical Drawing3D Model
KRB24DKRThrough HoleDualRegulated4836 – 60 – – 24/2410/10 – –
DatasheetMechanical Drawing3D Model
KRB15SKRThrough HoleSingleRegulated4836 – 601520 – – – –
DatasheetMechanical Drawing3D Model
KRB15DKRThrough HoleDualRegulated4836 – 60 – – 15/1510/10 – –
DatasheetMechanical Drawing3D Model
KRB12SKRThrough HoleSingleRegulated4836 – 601220 – – – –
DatasheetMechanical Drawing3D Model
KRB12DKRThrough HoleDualRegulated4836 – 60 – – 12/1210/10 – –
DatasheetMechanical Drawing3D Model
KRB100SKRThrough HoleSingleRegulated4836 – 6010020 – – – –
DatasheetMechanical Drawing3D Model
KRA9SKRThrough HoleSingleRegulated2718 – 36920 – – – –
DatasheetMechanical Drawing3D Model
KRA9DKRThrough HoleDualRegulated2718 – 36 – – 9/910/10 – –
DatasheetMechanical Drawing3D Model
KRA5SKRThrough HoleSingleRegulated2718 – 36520 – – – –
DatasheetMechanical Drawing3D Model
KRA5DKRThrough HoleDualRegulated2718 – 36 – – 5/510/10 – –
DatasheetMechanical Drawing3D Model
KRA5.2SKRThrough HoleSingleRegulated2718 – 365.220 – – – –
DatasheetMechanical Drawing3D Model
KRA48SKRThrough HoleSingleRegulated2718 – 364820 – – – –
DatasheetMechanical Drawing3D Model
KRA48DKRThrough HoleDualRegulated2718 – 36 – – 48/4810/10 – –
DatasheetMechanical Drawing3D Model
KRA3.3SKRThrough HoleSingleRegulated2718 – 363.320 – – – –
DatasheetMechanical Drawing3D Model
KRA28SKRThrough HoleSingleRegulated2718 – 362820 – – – –
DatasheetMechanical Drawing3D Model
KRA28DKRThrough HoleDualRegulated2718 – 36 – – 28/2810/10 – –
DatasheetMechanical Drawing3D Model
KRA24SKRThrough HoleSingleRegulated2718 – 362420 – – – –
DatasheetMechanical Drawing3D Model
KRA24DKRThrough HoleDualRegulated2718 – 36 – – 24/2410/10 – –
DatasheetMechanical Drawing3D Model
KRA15SKRThrough HoleSingleRegulated2718 – 361520 – – – –
DatasheetMechanical Drawing3D Model
KRA15DKRThrough HoleDualRegulated2718 – 36 – – 15/1510/10 – –
DatasheetMechanical Drawing3D Model
KRA12SKRThrough HoleSingleRegulated2718 – 361220 – – – –
DatasheetMechanical Drawing3D Model
KRA12DKRThrough HoleDualRegulated2718 – 36 – – 12/1210/10 – –
DatasheetMechanical Drawing3D Model
KRA100SKRThrough HoleSingleRegulated2718 – 3610020 – – – –
DatasheetMechanical Drawing3D Model
JRC9SJRThrough HoleSingleRegulated3918 – 60915 – – – –
DatasheetMechanical Drawing3D Model
JRC9DJRThrough HoleDualRegulated3918 – 60 – – 9/97.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRC5SJRThrough HoleSingleRegulated3918 – 60515 – – – –
DatasheetMechanical Drawing3D Model
JRC5DJRThrough HoleDualRegulated3918 – 60 – – 5/57.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRC5.2SJRThrough HoleSingleRegulated3918 – 605.215 – – – –
DatasheetMechanical Drawing3D Model
JRC48SJRThrough HoleSingleRegulated3918 – 604815 – – – –
DatasheetMechanical Drawing3D Model
JRC48DJRThrough HoleDualRegulated3918 – 60 – – 48/487.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRC3.3SJRThrough HoleSingleRegulated3918 – 603.315 – – – –
DatasheetMechanical Drawing3D Model
JRC28SJRThrough HoleSingleRegulated3918 – 602815 – – – –
DatasheetMechanical Drawing3D Model
JRC28DJRThrough HoleDualRegulated3918 – 60 – – 28/287.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRC24SJRThrough HoleSingleRegulated3918 – 602415 – – – –
DatasheetMechanical Drawing3D Model
JRC24DJRThrough HoleDualRegulated3918 – 60 – – 24/247.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRC15SJRThrough HoleSingleRegulated3918 – 601515 – – – –
DatasheetMechanical Drawing3D Model
JRC15DJRThrough HoleDualRegulated3918 – 60 – – 15/157.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRC12SJRThrough HoleSingleRegulated3918 – 601215 – – – –
DatasheetMechanical Drawing3D Model
JRC12DJRThrough HoleDualRegulated3918 – 60 – – 12/127.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRC100SJRThrough HoleSingleRegulated3918 – 6010015 – – – –
DatasheetMechanical Drawing3D Model
JRB9SJRThrough HoleSingleRegulated4836 – 60915 – – – –
DatasheetMechanical Drawing3D Model
JRB9DJRThrough HoleDualRegulated4836 – 60 – – 9/97.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRB5SJRThrough HoleSingleRegulated4836 – 60515 – – – –
DatasheetMechanical Drawing3D Model
JRB5DJRThrough HoleDualRegulated4836 – 60 – – 5/57.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRB5.2SJRThrough HoleSingleRegulated4836 – 605.215 – – – –
DatasheetMechanical Drawing3D Model
JRB48SJRThrough HoleSingleRegulated4836 – 604815 – – – –
DatasheetMechanical Drawing3D Model
JRB48DJRThrough HoleDualRegulated4836 – 60 – – 48/487.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRB3.3SJRThrough HoleSingleRegulated4836 – 603.315 – – – –
DatasheetMechanical Drawing3D Model
JRB28SJRThrough HoleSingleRegulated4836 – 602815 – – – –
DatasheetMechanical Drawing3D Model
JRB28DJRThrough HoleDualRegulated4836 – 60 – – 28/287.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRB24SJRThrough HoleSingleRegulated4836 – 602415 – – – –
DatasheetMechanical Drawing3D Model
JRB24DJRThrough HoleDualRegulated4836 – 60 – – 24/247.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRB15SJRThrough HoleSingleRegulated4836 – 601515 – – – –
DatasheetMechanical Drawing3D Model
JRB15DJRThrough HoleDualRegulated4836 – 60 – – 15/157.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRB12SJRThrough HoleSingleRegulated4836 – 601215 – – – –
DatasheetMechanical Drawing3D Model
JRB12DJRThrough HoleDualRegulated4836 – 60 – – 12/127.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRB100SJRThrough HoleSingleRegulated4836 – 6010015 – – – –
DatasheetMechanical Drawing3D Model
JRA9SJRThrough HoleSingleRegulated2718 – 36915 – – – –
DatasheetMechanical Drawing3D Model
JRA9DJRThrough HoleDualRegulated2718 – 36 – – 9/97.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRA5SJRThrough HoleSingleRegulated2718 – 36515 – – – –
DatasheetMechanical Drawing3D Model
JRA5DJRThrough HoleDualRegulated2718 – 36 – – 5/57.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRA5.2SJRThrough HoleSingleRegulated2718 – 365.215 – – – –
DatasheetMechanical Drawing3D Model
JRA48SJRThrough HoleSingleRegulated2718 – 364815 – – – –
DatasheetMechanical Drawing3D Model
JRA48DJRThrough HoleDualRegulated2718 – 36 – – 48/487.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRA3.3SJRThrough HoleSingleRegulated2718 – 363.315 – – – –
DatasheetMechanical Drawing3D Model
JRA28SJRThrough HoleSingleRegulated2718 – 362815 – – – –
DatasheetMechanical Drawing3D Model
JRA28DJRThrough HoleDualRegulated2718 – 36 – – 28/287.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRA24SJRThrough HoleSingleRegulated2718 – 362415 – – – –
DatasheetMechanical Drawing3D Model
JRA24DJRThrough HoleDualRegulated2718 – 36 – – 24/247.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRA15SJRThrough HoleSingleRegulated2718 – 361515 – – – –
DatasheetMechanical Drawing3D Model
JRA15DJRThrough HoleDualRegulated2718 – 36 – – 15/157.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRA12SJRThrough HoleSingleRegulated2718 – 361215 – – – –
DatasheetMechanical Drawing3D Model
JRA12DJRThrough HoleDualRegulated2718 – 36 – – 12/127.5/7.5 – –
DatasheetMechanical Drawing3D Model
JRA100SJRThrough HoleSingleRegulated2718 – 3610015 – – – –
DatasheetMechanical Drawing3D Model
IRF9SIRThrough HoleSingleRegulated168 – 24910 – – – –
DatasheetMechanical Drawing3D Model
IRF9DIRThrough HoleDualRegulated168 – 24 – – 9/95/5 – –
DatasheetMechanical Drawing3D Model
IRF5SIRThrough HoleSingleRegulated168 – 24510 – – – –
DatasheetMechanical Drawing3D Model
IRF5DIRThrough HoleDualRegulated168 – 24 – – 5/55/5 – –
DatasheetMechanical Drawing3D Model
IRF5.2SIRThrough HoleSingleRegulated168 – 245.210 – – – –
DatasheetMechanical Drawing3D Model
IRF48SIRThrough HoleSingleRegulated168 – 244810 – – – –
DatasheetMechanical Drawing3D Model
IRF48DIRThrough HoleDualRegulated168 – 24 – – 48/485/5 – –
DatasheetMechanical Drawing3D Model
IRF3.3SIRThrough HoleSingleRegulated168 – 243.38 – – – –
DatasheetMechanical Drawing3D Model
IRF2SIRThrough HoleSingleRegulated168 – 2425 – – – –
DatasheetMechanical Drawing3D Model
IRF28SIRThrough HoleSingleRegulated168 – 242810 – – – –
DatasheetMechanical Drawing3D Model
IRF28DIRThrough HoleDualRegulated168 – 24 – – 28/285/5 – –
DatasheetMechanical Drawing3D Model
IRF24SIRThrough HoleSingleRegulated168 – 242410 – – – –
DatasheetMechanical Drawing3D Model
IRF24DIRThrough HoleDualRegulated168 – 24 – – 24/245/5 – –
DatasheetMechanical Drawing3D Model
IRF15SIRThrough HoleSingleRegulated168 – 241510 – – – –
DatasheetMechanical Drawing3D Model
IRF15DIRThrough HoleDualRegulated168 – 24 – – 15/155/5 – –
DatasheetMechanical Drawing3D Model
IRF12SIRThrough HoleSingleRegulated168 – 241210 – – – –
DatasheetMechanical Drawing3D Model
IRF12DIRThrough HoleDualRegulated168 – 24 – – 12/125/5 – –
DatasheetMechanical Drawing3D Model
IRF100SIRThrough HoleSingleRegulated168 – 2410010 – – – –
DatasheetMechanical Drawing3D Model
IRE9SIRThrough HoleSingleRegulated105 – 1598 – – – –
DatasheetMechanical Drawing3D Model
IRE9DIRThrough HoleDualRegulated105 – 15 – – 9/94/4 – –
DatasheetMechanical Drawing3D Model
IRE5SIRThrough HoleSingleRegulated105 – 1556 – – – –
DatasheetMechanical Drawing3D Model
IRE5DIRThrough HoleDualRegulated105 – 15 – – 5/53/3 – –
DatasheetMechanical Drawing3D Model
IRE5.2SIRThrough HoleSingleRegulated105 – 155.26 – – – –
DatasheetMechanical Drawing3D Model
IRE48SIRThrough HoleSingleRegulated105 – 15488 – – – –
DatasheetMechanical Drawing3D Model
IRE48DIRThrough HoleDualRegulated105 – 15 – – 48/484/4 – –
DatasheetMechanical Drawing3D Model
IRE3.3SIRThrough HoleSingleRegulated105 – 153.35 – – – –
DatasheetMechanical Drawing3D Model
IRE2SIRThrough HoleSingleRegulated105 – 1524 – – – –
DatasheetMechanical Drawing3D Model
IRE28SIRThrough HoleSingleRegulated105 – 15288 – – – –
DatasheetMechanical Drawing3D Model
IRE28DIRThrough HoleDualRegulated105 – 15 – – 28/284/4 – –
DatasheetMechanical Drawing3D Model
IRE24SIRThrough HoleSingleRegulated105 – 15248 – – – –
DatasheetMechanical Drawing3D Model
IRE24DIRThrough HoleDualRegulated105 – 15 – – 24/244/4 – –
DatasheetMechanical Drawing3D Model
IRE15SIRThrough HoleSingleRegulated105 – 15158 – – – –
DatasheetMechanical Drawing3D Model
IRE15DIRThrough HoleDualRegulated105 – 15 – – 15/154/4 – –
DatasheetMechanical Drawing3D Model
IRE12SIRThrough HoleSingleRegulated105 – 15128 – – – –
DatasheetMechanical Drawing3D Model
IRE12DIRThrough HoleDualRegulated105 – 15 – – 12/124/4 – –
DatasheetMechanical Drawing3D Model
IRE100SIRThrough HoleSingleRegulated105 – 151006 – – – –
DatasheetMechanical Drawing3D Model
IRC9SIRThrough HoleSingleRegulated3918 – 60910 – – – –
DatasheetMechanical Drawing3D Model
IRC9DIRThrough HoleDualRegulated3918 – 60 – – 9/95/5 – –
DatasheetMechanical Drawing3D Model
IRC5SIRThrough HoleSingleRegulated3918 – 60510 – – – –
DatasheetMechanical Drawing3D Model
IRC5DIRThrough HoleDualRegulated3918 – 60 – – 5/55/5 – –
DatasheetMechanical Drawing3D Model
IRC5.2SIRThrough HoleSingleRegulated3918 – 605.210 – – – –
DatasheetMechanical Drawing3D Model
IRC48SIRThrough HoleSingleRegulated3918 – 604810 – – – –
DatasheetMechanical Drawing3D Model
IRC48DIRThrough HoleDualRegulated3918 – 60 – – 48/485/5 – –
DatasheetMechanical Drawing3D Model
IRC3.3SIRThrough HoleSingleRegulated3918 – 603.39 – – – –
DatasheetMechanical Drawing3D Model
IRC2SIRThrough HoleSingleRegulated3918 – 6026 – – – –
DatasheetMechanical Drawing3D Model
IRC28SIRThrough HoleSingleRegulated3918 – 602810 – – – –
DatasheetMechanical Drawing3D Model
IRC28DIRThrough HoleDualRegulated3918 – 60 – – 28/285/5 – –
DatasheetMechanical Drawing3D Model
IRC24SIRThrough HoleSingleRegulated3918 – 602410 – – – –
DatasheetMechanical Drawing3D Model
IRC24DIRThrough HoleDualRegulated3918 – 60 – – 24/245/5 – –
DatasheetMechanical Drawing3D Model
IRC15SIRThrough HoleSingleRegulated3918 – 601510 – – – –
DatasheetMechanical Drawing3D Model
IRC15DIRThrough HoleDualRegulated3918 – 60 – – 15/155/5 – –
DatasheetMechanical Drawing3D Model
IRC12SIRThrough HoleSingleRegulated3918 – 601210 – – – –
DatasheetMechanical Drawing3D Model
IRC12DIRThrough HoleDualRegulated3918 – 60 – – 12/125/5 – –
DatasheetMechanical Drawing3D Model
IRC100SIRThrough HoleSingleRegulated3918 – 6010010 – – – –
DatasheetMechanical Drawing3D Model
IRB9SIRThrough HoleSingleRegulated4836 – 60910 – – – –
DatasheetMechanical Drawing3D Model
IRB9DIRThrough HoleDualRegulated4836 – 60 – – 9/95/5 – –
DatasheetMechanical Drawing3D Model
IRB5SIRThrough HoleSingleRegulated4836 – 60510 – – – –
DatasheetMechanical Drawing3D Model
IRB5DIRThrough HoleDualRegulated4836 – 60 – – 5/55/5 – –
DatasheetMechanical Drawing3D Model
IRB5.2SIRThrough HoleSingleRegulated4836 – 605.210 – – – –
DatasheetMechanical Drawing3D Model
IRB48SIRThrough HoleSingleRegulated4836 – 604810 – – – –
DatasheetMechanical Drawing3D Model
IRB48DIRThrough HoleDualRegulated4836 – 60 – – 48/485/5 – –
DatasheetMechanical Drawing3D Model
IRB3.3SIRThrough HoleSingleRegulated4836 – 603.39 – – – –
DatasheetMechanical Drawing3D Model
IRB2SIRThrough HoleSingleRegulated4836 – 6026 – – – –
DatasheetMechanical Drawing3D Model
IRB28SIRThrough HoleSingleRegulated4836 – 602810 – – – –
DatasheetMechanical Drawing3D Model
IRB28DIRThrough HoleDualRegulated4836 – 60 – – 28/285/5 – –
DatasheetMechanical Drawing3D Model
IRB24SIRThrough HoleSingleRegulated4836 – 602410 – – – –
DatasheetMechanical Drawing3D Model
IRB24DIRThrough HoleDualRegulated4836 – 60 – – 24/245/5 – –
DatasheetMechanical Drawing3D Model
IRB15SIRThrough HoleSingleRegulated4836 – 601510 – – – –
DatasheetMechanical Drawing3D Model
IRB15DIRThrough HoleDualRegulated4836 – 60 – – 15/155/5 – –
DatasheetMechanical Drawing3D Model
IRB12SIRThrough HoleSingleRegulated4836 – 601210 – – – –
DatasheetMechanical Drawing3D Model
IRB12DIRThrough HoleDualRegulated4836 – 60 – – 12/125/5 – –
DatasheetMechanical Drawing3D Model
IRB100SIRThrough HoleSingleRegulated4836 – 6010010 – – – –
DatasheetMechanical Drawing3D Model
IRA9SIRThrough HoleSingleRegulated2718 – 36910 – – – –
DatasheetMechanical Drawing3D Model
IRA9DIRThrough HoleDualRegulated2718 – 36 – – 9/95/5 – –
DatasheetMechanical Drawing3D Model
IRA5SIRThrough HoleSingleRegulated2718 – 36510 – – – –
DatasheetMechanical Drawing3D Model
IRA5DIRThrough HoleDualRegulated2718 – 36 – – 5/55/5 – –
DatasheetMechanical Drawing3D Model
IRA5.2SIRThrough HoleSingleRegulated2718 – 365.210 – – – –
DatasheetMechanical Drawing3D Model
IRA48SIRThrough HoleSingleRegulated2718 – 364810 – – – –
DatasheetMechanical Drawing3D Model
IRA48DIRThrough HoleDualRegulated2718 – 36 – – 48/485/5 – –
DatasheetMechanical Drawing3D Model
IRA3.3SIRThrough HoleSingleRegulated2718 – 363.39 – – – –
DatasheetMechanical Drawing3D Model
IRA2SIRThrough HoleSingleRegulated2718 – 3626 – – – –
DatasheetMechanical Drawing3D Model
IRA28SIRThrough HoleSingleRegulated2718 – 362810 – – – –
DatasheetMechanical Drawing3D Model
IRA28DIRThrough HoleDualRegulated2718 – 36 – – 28/285/5 – –
DatasheetMechanical Drawing3D Model
IRA24SIRThrough HoleSingleRegulated2718 – 362410 – – – –
DatasheetMechanical Drawing3D Model
IRA24DIRThrough HoleDualRegulated2718 – 36 – – 24/245/5 – –
DatasheetMechanical Drawing3D Model
IRA15SIRThrough HoleSingleRegulated2718 – 361510 – – – –
DatasheetMechanical Drawing3D Model
IRA15DIRThrough HoleDualRegulated2718 – 36 – – 15/155/5 – –
DatasheetMechanical Drawing3D Model
IRA12SIRThrough HoleSingleRegulated2718 – 361210 – – – –
DatasheetMechanical Drawing3D Model
IRA12DIRThrough HoleDualRegulated2718 – 36 – – 12/125/5 – –
DatasheetMechanical Drawing3D Model
IRA100SIRThrough HoleSingleRegulated2718 – 3610010 – – – –
DatasheetMechanical Drawing3D Model
HVP6PHVPThrough HoleSingleRegulated Programmable1211 – 1660005 – – – –
DatasheetMechanical Drawing3D Model
HVP6NHVPThrough HoleSingleRegulated Programmable1211 – 16-60005 – – – –
DatasheetMechanical Drawing3D Model
HVP5PHVPThrough HoleSingleRegulated Programmable1211 – 1650005 – – – –
DatasheetMechanical Drawing3D Model
HVP5NHVPThrough HoleSingleRegulated Programmable1211 – 16-50005 – – – –
DatasheetMechanical Drawing3D Model
HVP4PHVPThrough HoleSingleRegulated Programmable1211 – 1640005 – – – –
DatasheetMechanical Drawing3D Model
HVP4NHVPThrough HoleSingleRegulated Programmable1211 – 16-40005 – – – –
DatasheetMechanical Drawing3D Model
HVP3PHVPThrough HoleSingleRegulated Programmable1211 – 1630005 – – – –
DatasheetMechanical Drawing3D Model
HVP3NHVPThrough HoleSingleRegulated Programmable1211 – 16-30005 – – – –
DatasheetMechanical Drawing3D Model
HVP2PHVPThrough HoleSingleRegulated Programmable1211 – 1620005 – – – –
DatasheetMechanical Drawing3D Model
HVP2NHVPThrough HoleSingleRegulated Programmable1211 – 16-20005 – – – –
DatasheetMechanical Drawing3D Model
HVP1PHVPThrough HoleSingleRegulated Programmable1211 – 1610005 – – – –
DatasheetMechanical Drawing3D Model
HVP1NHVPThrough HoleSingleRegulated Programmable1211 – 16-10005 – – – –
DatasheetMechanical Drawing3D Model
HVP0.5PHVPThrough HoleSingleRegulated Programmable1211 – 165005 – – – –
DatasheetMechanical Drawing3D Model
HVP0.5NHVPThrough HoleSingleRegulated Programmable1211 – 16-5005 – – – –
DatasheetMechanical Drawing3D Model
HVP0.25PHVPThrough HoleSingleRegulated Programmable1211 – 162505 – – – –
DatasheetMechanical Drawing3D Model
HVP0.25NHVPThrough HoleSingleRegulated Programmable1211 – 16-2505 – – – –
DatasheetMechanical Drawing3D Model
HVP0.1PHVPThrough HoleSingleRegulated Programmable1211 – 161005 – – – –
DatasheetMechanical Drawing3D Model
HVP0.1NHVPThrough HoleSingleRegulated Programmable1211 – 16-1005 – – – –
DatasheetMechanical Drawing3D Model
HVD5SHVThrough HoleSingleRegulated12570 – 170510 – – – –
DatasheetMechanical Drawing3D Model
HVD5DHVThrough HoleDualRegulated12570 – 170 – – ±5±5 – –
DatasheetMechanical Drawing3D Model
HVD5.2SHVThrough HoleSingleRegulated12570 – 1705.210 – – – –
DatasheetMechanical Drawing3D Model
HVD48SHVThrough HoleSingleRegulated12570 – 1704815 – – – –
DatasheetMechanical Drawing3D Model
HVD3.3SHVThrough HoleSingleRegulated12570 – 1703.36 – – – –
DatasheetMechanical Drawing3D Model
HVD28SHVThrough HoleSingleRegulated12570 – 1702815 – – – –
DatasheetMechanical Drawing3D Model
HVD24SHVThrough HoleSingleRegulated12570 – 1702415 – – – –
DatasheetMechanical Drawing3D Model
HVD15SHVThrough HoleSingleRegulated12570 – 1701515 – – – –
DatasheetMechanical Drawing3D Model
HVD15DHVThrough HoleDualRegulated12570 – 170 – – ±15±7.5 – –
DatasheetMechanical Drawing3D Model
HVD12SHVThrough HoleSingleRegulated12570 – 1701215 – – – –
DatasheetMechanical Drawing3D Model
HVD12DHVThrough HoleDualRegulated12570 – 170 – – ±12±7.5 – –
DatasheetMechanical Drawing3D Model
HVC5SHVThrough HoleSingleRegulated12570 – 17058 – – – –
DatasheetMechanical Drawing3D Model
HVC5DHVThrough HoleDualRegulated12570 – 170 – – ±5±4 – –
DatasheetMechanical Drawing3D Model
HVC5.2SHVThrough HoleSingleRegulated12570 – 1705.28 – – – –
DatasheetMechanical Drawing3D Model
HVC48SHVThrough HoleSingleRegulated12570 – 1704810 – – – –
DatasheetMechanical Drawing3D Model
HVC3.3SHVThrough HoleSingleRegulated12570 – 1703.35 – – – –
DatasheetMechanical Drawing3D Model
HVC28SHVThrough HoleSingleRegulated12570 – 1702810 – – – –
DatasheetMechanical Drawing3D Model
HVC24SHVThrough HoleSingleRegulated12570 – 1702410 – – – –
DatasheetMechanical Drawing3D Model
HVC15SHVThrough HoleSingleRegulated12570 – 1701510 – – – –
DatasheetMechanical Drawing3D Model
HVC15DHVThrough HoleDualRegulated12570 – 170 – – ±15±5 – –
DatasheetMechanical Drawing3D Model
HVC12SHVThrough HoleSingleRegulated12570 – 1701210 – – – –
DatasheetMechanical Drawing3D Model
HVC12DHVThrough HoleDualRegulated12570 – 170 – – ±12±5 – –
DatasheetMechanical Drawing3D Model
HVB5SHVThrough HoleSingleRegulated12570 – 17055 – – – –
DatasheetMechanical Drawing3D Model
HVB5DHVThrough HoleDualRegulated12570 – 170 – – ±5±2.5 – –
DatasheetMechanical Drawing3D Model
HVB5.2SHVThrough HoleSingleRegulated12570 – 1705.25 – – – –
DatasheetMechanical Drawing3D Model
HVB48SHVThrough HoleSingleRegulated12570 – 170485 – – – –
DatasheetMechanical Drawing3D Model
HVB3.3SHVThrough HoleSingleRegulated12570 – 1703.33.3 – – – –
DatasheetMechanical Drawing3D Model
HVB28SHVThrough HoleSingleRegulated12570 – 170285 – – – –
DatasheetMechanical Drawing3D Model
HVB24SHVThrough HoleSingleRegulated12570 – 170245 – – – –
DatasheetMechanical Drawing3D Model
HVB15SHVThrough HoleSingleRegulated12570 – 170155 – – – –
DatasheetMechanical Drawing3D Model
HVB15DHVThrough HoleDualRegulated12570 – 170 – – ±15±2.5 – –
DatasheetMechanical Drawing3D Model
HVB12SHVThrough HoleSingleRegulated12570 – 170125 – – – –
DatasheetMechanical Drawing3D Model
HVB12DHVThrough HoleDualRegulated12570 – 170 – – ±12±2.5 – –
DatasheetMechanical Drawing3D Model
HVA5SHVThrough HoleSingleRegulated12570 – 17053 – – – –
DatasheetMechanical Drawing3D Model
HVA5DHVThrough HoleDualRegulated12570 – 170 – – ±5±1.5 – –
DatasheetMechanical Drawing3D Model
HVA5.2SHVThrough HoleSingleRegulated12570 – 1705.23 – – – –
DatasheetMechanical Drawing3D Model
HVA3.3SHVThrough HoleSingleRegulated12570 – 1703.32 – – – –
DatasheetMechanical Drawing3D Model
HVA28SHVThrough HoleSingleRegulated12570 – 170283 – – – –
DatasheetMechanical Drawing3D Model
HVA24SHVThrough HoleSingleRegulated12570 – 170243 – – – –
DatasheetMechanical Drawing3D Model
HVA15SHVThrough HoleSingleRegulated12570 – 170153 – – – –
DatasheetMechanical Drawing3D Model
HVA15DHVThrough HoleDualRegulated12570 – 170 – – ±15±1.5 – –
DatasheetMechanical Drawing3D Model
HVA12SHVThrough HoleSingleRegulated12570 – 170123 – – – –
DatasheetMechanical Drawing3D Model
HVA12DHVThrough HoleDualRegulated12570 – 170 – – ±12±1.5 – –
DatasheetMechanical Drawing3D Model
HILR5SHILRThrough HoleSingleRegulated300125 – 47555 – – – –
DatasheetMechanical Drawing3D Model
HILR5DHILRThrough HoleDualRegulated300125 – 475 – – 5/52.5/2.5 – –
DatasheetMechanical Drawing3D Model
HILR48SHILRThrough HoleSingleRegulated300125 – 475485 – – – –
DatasheetMechanical Drawing3D Model
HILR48DHILRThrough HoleDualRegulated300125 – 475 – – 48/482.5/2.5 – –
DatasheetMechanical Drawing3D Model
HILR3.3SHILRThrough HoleSingleRegulated300125 – 4753.34 – – – –
DatasheetMechanical Drawing3D Model
HILR3.3DHILRThrough HoleDualRegulated300125 – 475 – – 3.3/3.32/2 – –
DatasheetMechanical Drawing3D Model
HILR28SHILRThrough HoleSingleRegulated300125 – 475285 – – – –
DatasheetMechanical Drawing3D Model
HILR28DHILRThrough HoleDualRegulated300125 – 475 – – 28/282.5/2.5 – –
DatasheetMechanical Drawing3D Model
HILR24SHILRThrough HoleSingleRegulated300125 – 475245 – – – –
DatasheetMechanical Drawing3D Model
HILR24DHILRThrough HoleDualRegulated300125 – 475 – – 24/242.5/2.5 – –
DatasheetMechanical Drawing3D Model
HILR15SHILRThrough HoleSingleRegulated300125 – 475155 – – – –
DatasheetMechanical Drawing3D Model
HILR15DHILRThrough HoleDualRegulated300125 – 475 – – 15/152.5/2.5 – –
DatasheetMechanical Drawing3D Model
HILR12SHILRThrough HoleSingleRegulated300125 – 475125 – – – –
DatasheetMechanical Drawing3D Model
HILR12DHILRThrough HoleDualRegulated300125 – 475 – – 12/122.5/2.5 – –
DatasheetMechanical Drawing3D Model
HILR100SHILRThrough HoleSingleRegulated300125 – 4751005 – – – –
DatasheetMechanical Drawing3D Model
9VV9-PVV (100-10kV)Through HoleSingleProportional9 – +90006 – – – –
DatasheetMechanical Drawing3D Model
9VV9-NVV (100-10kV)Through HoleSingleProportional9 – -90006 – – – –
DatasheetMechanical Drawing3D Model
9VV9VV (100-10kV)Through HoleSingleProportional9 – 90006 – – – –
DatasheetMechanical Drawing3D Model
9VV8-PVV (100-10kV)Through HoleSingleProportional9 – +80006 – – – –
DatasheetMechanical Drawing3D Model
9VV8-NVV (100-10kV)Through HoleSingleProportional9 – -80006 – – – –
DatasheetMechanical Drawing3D Model
9VV8VV (100-10kV)Through HoleSingleProportional9 – 80006 – – – –
DatasheetMechanical Drawing3D Model
9VV7-PVV (100-10kV)Through HoleSingleProportional9 – +70006 – – – –
DatasheetMechanical Drawing3D Model
9VV7-NVV (100-10kV)Through HoleSingleProportional9 – -70006 – – – –
DatasheetMechanical Drawing3D Model
9VV7VV (100-10kV)Through HoleSingleProportional9 – 70006 – – – –
DatasheetMechanical Drawing3D Model
9VV6-PVV (100-10kV)Through HoleSingleProportional9 – +60006 – – – –
DatasheetMechanical Drawing3D Model
9VV6-NVV (100-10kV)Through HoleSingleProportional9 – -60006 – – – –
DatasheetMechanical Drawing3D Model
9VV6VV (100-10kV)Through HoleSingleProportional9 – 60006 – – – –
DatasheetMechanical Drawing3D Model
9VV5VV (100-10kV)Through HoleSingleProportional9 – 50006 – – – –
DatasheetMechanical Drawing3D Model
9VV4VV (100-10kV)Through HoleSingleProportional9 – 40007 – – – –
DatasheetMechanical Drawing3D Model
9VV3VV (100-10kV)Through HoleSingleProportional9 – 30007 – – – –
DatasheetMechanical Drawing3D Model
9VV2VV (100-10kV)Through HoleSingleProportional9 – 20007 – – – –
DatasheetMechanical Drawing3D Model
9VV10-PVV (100-10kV)Through HoleSingleProportional9 – +100006 – – – –
DatasheetMechanical Drawing3D Model
9VV10-NVV (100-10kV)Through HoleSingleProportional9 – -100006 – – – –
DatasheetMechanical Drawing3D Model
9VV10VV (100-10kV)Through HoleSingleProportional9 – 100006 – – – –
DatasheetMechanical Drawing3D Model
9VV1VV (100-10kV)Through HoleSingleProportional9 – 10007 – – – –
DatasheetMechanical Drawing3D Model
9VV0.9VV (100-10kV)Through HoleSingleProportional9 – 9007 – – – –
DatasheetMechanical Drawing3D Model
9VV0.8VV (100-10kV)Through HoleSingleProportional9 – 8007 – – – –
DatasheetMechanical Drawing3D Model
9VV0.7VV (100-10kV)Through HoleSingleProportional9 – 7007 – – – –
DatasheetMechanical Drawing3D Model
9VV0.6VV (100-10kV)Through HoleSingleProportional9 – 6007 – – – –
DatasheetMechanical Drawing3D Model
9VV0.5VV (100-10kV)Through HoleSingleProportional9 – 5007 – – – –
DatasheetMechanical Drawing3D Model
9VV0.4VV (100-10kV)Through HoleSingleProportional9 – 4007 – – – –
DatasheetMechanical Drawing3D Model
9VV0.3VV (100-10kV)Through HoleSingleProportional9 – 3007 – – – –
DatasheetMechanical Drawing3D Model
9VV0.2VV (100-10kV)Through HoleSingleProportional9 – 2007 – – – –
DatasheetMechanical Drawing3D Model
9VV0.1VV (100-10kV)Through HoleSingleProportional9 – 1007 – – – –
DatasheetMechanical Drawing3D Model
9SDT9SSDTSurface MountSingleProportional9 – 90.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SDT9DDTThrough HoleDualProportional9 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
9SDT5SSDTSurface MountSingleProportional9 – 50.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SDT5DDTThrough HoleDualProportional9 – – – ±5±0.375 – –
DatasheetMechanical Drawing3D Model
9SDT5.2SSDTSurface MountSingleProportional9 – 5.20.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SDT3.3SSDTSurface MountSingleProportional9 – 3.30.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SDT15SSDTSurface MountSingleProportional9 – 150.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SDT15DDTThrough HoleDualProportional9 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
9SDT12SSDTSurface MountSingleProportional9 – 120.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SDT12DDTThrough HoleDualProportional9 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
9SAT9SSATSurface MountSingleProportional9 – 90.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SAT9DSATSurface MountDualProportional9 – – – ±9±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
9SAT5SSATSurface MountSingleProportional9 – 50.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SAT5DSATSurface MountDualProportional9 – – – ±5±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
9SAT5.2SSATSurface MountSingleProportional9 – 5.20.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SAT3.3SSATSurface MountSingleProportional9 – 3.30.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SAT15SSATSurface MountSingleProportional9 – 150.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SAT15DSATSurface MountDualProportional9 – – – ±15±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
9SAT12SSATSurface MountSingleProportional9 – 120.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
9SAT12DSATSurface MountDualProportional9 – – – ±12±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
9DT9SDTThrough HoleSingleProportional9 – 90.75 – – – –
DatasheetMechanical Drawing3D Model
9DT9DDTThrough HoleDualProportional9 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
9DT5SDTThrough HoleSingleProportional9 – 50.75 – – – –
DatasheetMechanical Drawing3D Model
9DT5DDTThrough HoleDualProportional9 – – – ±5±0.375 – –
DatasheetMechanical Drawing3D Model
9DT5.2SDTThrough HoleSingleProportional9 – 5.20.75 – – – –
DatasheetMechanical Drawing3D Model
9DT3.3SDTThrough HoleSingleProportional9 – 3.30.75 – – – –
DatasheetMechanical Drawing3D Model
9DT15SDTThrough HoleSingleProportional9 – 150.75 – – – –
DatasheetMechanical Drawing3D Model
9DT15DDTThrough HoleDualProportional9 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
9DT12SDTThrough HoleSingleProportional9 – 120.75 – – – –
DatasheetMechanical Drawing3D Model
9DT12DDTThrough HoleDualProportional9 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
9AT9SATThrough HoleSingleProportional9 – 90.75 – – – –
DatasheetMechanical Drawing3D Model
9AT9DATThrough HoleDualProportional9 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
9AT5SATThrough HoleSingleProportional9 – 50.75 – – – –
DatasheetMechanical Drawing3D Model
9AT5DATThrough HoleDualProportional9 – – – ±5±0.375 – –
DatasheetMechanical Drawing3D Model
9AT5.2SATThrough HoleSingleProportional9 – 5.20.75 – – – –
DatasheetMechanical Drawing3D Model
9AT3.3SATThrough HoleSingleProportional9 – 3.30.75 – – – –
DatasheetMechanical Drawing3D Model
9AT15SATThrough HoleSingleProportional9 – 150.75 – – – –
DatasheetMechanical Drawing3D Model
9AT15DATThrough HoleDualProportional9 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
9AT12SATThrough HoleSingleProportional9 – 120.75 – – – –
DatasheetMechanical Drawing3D Model
9AT12DATThrough HoleDualProportional9 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
5XSGR9SXSGRSurface MountSingleRegulated54.5 – 5.592.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5XSGR9DXSGRSurface MountDualRegulated54.5 – 5.5 – – 9/91.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
5XSGR5SXSGRSurface MountSingleRegulated54.5 – 5.552 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5XSGR5DXSGRSurface MountDualRegulated54.5 – 5.5 – – 5/51/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
5XSGR3.3SXSGRSurface MountSingleRegulated54.5 – 5.53.31.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5XSGR2SXSGRSurface MountSingleRegulated54.5 – 5.521.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5XSGR15SXSGRSurface MountSingleRegulated54.5 – 5.5153 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5XSGR15DXSGRSurface MountDualRegulated54.5 – 5.5 – – 15/151.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5XSGR12SXSGRSurface MountSingleRegulated54.5 – 5.5123 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5XSGR12DXSGRSurface MountDualRegulated54.5 – 5.5 – – 12/121.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5XGR9SXGRThrough HoleSingleRegulated54.5 – 5.592.5 – – – –
DatasheetMechanical Drawing3D Model
5XGR9DXGRThrough HoleDualRegulated54.5 – 5.5 – – 9/91.25/1.25 – –
DatasheetMechanical Drawing3D Model
5XGR5SXGRThrough HoleSingleRegulated54.5 – 5.552 – – – –
DatasheetMechanical Drawing3D Model
5XGR5DXGRThrough HoleDualRegulated54.5 – 5.5 – – 5/51/1 – –
DatasheetMechanical Drawing3D Model
5XGR3.3SXGRThrough HoleSingleRegulated54.5 – 5.53.31.75 – – – –
DatasheetMechanical Drawing3D Model
5XGR2SXGRThrough HoleSingleRegulated54.5 – 5.521.25 – – – –
DatasheetMechanical Drawing3D Model
5XGR15SXGRThrough HoleSingleRegulated54.5 – 5.5153 – – – –
DatasheetMechanical Drawing3D Model
5XGR15DXGRThrough HoleDualRegulated54.5 – 5.5 – – 15/151.5/1.5 – –
DatasheetMechanical Drawing3D Model
5XGR12SXGRThrough HoleSingleRegulated54.5 – 5.5123 – – – –
DatasheetMechanical Drawing3D Model
5XGR12DXGRThrough HoleDualRegulated54.5 – 5.5 – – 12/121.5/1.5 – –
DatasheetMechanical Drawing3D Model
5VV9-PVV (100-10kV)Through HoleSingleProportional5 – +90005 – – – –
DatasheetMechanical Drawing3D Model
5VV9-NVV (100-10kV)Through HoleSingleProportional5 – -90005 – – – –
DatasheetMechanical Drawing3D Model
5VV9VV (100-10kV)Through HoleSingleProportional5 – 90005 – – – –
DatasheetMechanical Drawing3D Model
5VV8-PVV (100-10kV)Through HoleSingleProportional5 – +80005 – – – –
DatasheetMechanical Drawing3D Model
5VV8-NVV (100-10kV)Through HoleSingleProportional5 – -80005 – – – –
DatasheetMechanical Drawing3D Model
5VV8VV (100-10kV)Through HoleSingleProportional5 – 80005 – – – –
DatasheetMechanical Drawing3D Model
5VV7-PVV (100-10kV)Through HoleSingleProportional5 – +70005 – – – –
DatasheetMechanical Drawing3D Model
5VV7-NVV (100-10kV)Through HoleSingleProportional5 – -70005 – – – –
DatasheetMechanical Drawing3D Model
5VV7VV (100-10kV)Through HoleSingleProportional5 – 70005 – – – –
DatasheetMechanical Drawing3D Model
5VV6-PVV (100-10kV)Through HoleSingleProportional5 – +60005 – – – –
DatasheetMechanical Drawing3D Model
5VV6-NVV (100-10kV)Through HoleSingleProportional5 – -60005 – – – –
DatasheetMechanical Drawing3D Model
5VV6VV (100-10kV)Through HoleSingleProportional5 – 60005 – – – –
DatasheetMechanical Drawing3D Model
5VV500SVV (100-500V)Through HoleSingleProportional5 – 5004 – – – –
DatasheetMechanical Drawing3D Model
5VV5VV (100-10kV)Through HoleSingleProportional5 – 50005.5 – – – –
DatasheetMechanical Drawing3D Model
5VV400SVV (100-500V)Through HoleSingleProportional5 – 4004 – – – –
DatasheetMechanical Drawing3D Model
5VV4VV (100-10kV)Through HoleSingleProportional5 – 40005.5 – – – –
DatasheetMechanical Drawing3D Model
5VV300SVV (100-500V)Through HoleSingleProportional5 – 3004 – – – –
DatasheetMechanical Drawing3D Model
5VV3VV (100-10kV)Through HoleSingleProportional5 – 30006 – – – –
DatasheetMechanical Drawing3D Model
5VV200SVV (100-500V)Through HoleSingleProportional5 – 2004 – – – –
DatasheetMechanical Drawing3D Model
5VV2VV (100-10kV)Through HoleSingleProportional5 – 20006 – – – –
DatasheetMechanical Drawing3D Model
5VV100SVV (100-500V)Through HoleSingleProportional5 – 1004 – – – –
DatasheetMechanical Drawing3D Model
5VV10-PVV (100-10kV)Through HoleSingleProportional5 – +100005 – – – –
DatasheetMechanical Drawing3D Model
5VV10-NVV (100-10kV)Through HoleSingleProportional5 – -100005 – – – –
DatasheetMechanical Drawing3D Model
5VV10VV (100-10kV)Through HoleSingleProportional5 – 100005 – – – –
DatasheetMechanical Drawing3D Model
5VV1VV (100-10kV)Through HoleSingleProportional5 – 10006 – – – –
DatasheetMechanical Drawing3D Model
5VV0.9VV (100-10kV)Through HoleSingleProportional5 – 9006 – – – –
DatasheetMechanical Drawing3D Model
5VV0.8VV (100-10kV)Through HoleSingleProportional5 – 8006 – – – –
DatasheetMechanical Drawing3D Model
5VV0.7VV (100-10kV)Through HoleSingleProportional5 – 7006 – – – –
DatasheetMechanical Drawing3D Model
5VV0.6VV (100-10kV)Through HoleSingleProportional5 – 6006 – – – –
DatasheetMechanical Drawing3D Model
5VV0.5VV (100-10kV)Through HoleSingleProportional5 – 5006 – – – –
DatasheetMechanical Drawing3D Model
5VV0.4VV (100-10kV)Through HoleSingleProportional5 – 4006 – – – –
DatasheetMechanical Drawing3D Model
5VV0.3VV (100-10kV)Through HoleSingleProportional5 – 3006 – – – –
DatasheetMechanical Drawing3D Model
5VV0.2VV (100-10kV)Through HoleSingleProportional5 – 2006 – – – –
DatasheetMechanical Drawing3D Model
5VV0.1VV (100-10kV)Through HoleSingleProportional5 – 1006 – – – –
DatasheetMechanical Drawing3D Model
5SVV500SSVVSurface MountSingleProportional5 – 5004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SVV400SSVVSurface MountSingleProportional5 – 4004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SVV300SSVVSurface MountSingleProportional5 – 3004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SVV200SSVVSurface MountSingleProportional5 – 2004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SVV100SSVVSurface MountSingleProportional5 – 1004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV900SMVSurface MountSingleProportional5 – 9001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV800SMVSurface MountSingleProportional5 – 8001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV700SMVSurface MountSingleProportional5 – 7001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV600SMVSurface MountSingleProportional5 – 6001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV500SMVSurface MountSingleProportional5 – 5001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV450SMVSurface MountSingleProportional5 – 4501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV400SMVSurface MountSingleProportional5 – 4001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV350SMVSurface MountSingleProportional5 – 3501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV300SMVSurface MountSingleProportional5 – 3001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV250DSMVSurface MountDualProportional5 – – – ±250±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV250SMVSurface MountSingleProportional5 – 2501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV200DSMVSurface MountDualProportional5 – – – ±200±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV200SMVSurface MountSingleProportional5 – 2001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV150DSMVSurface MountDualProportional5 – – – ±150±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV150SMVSurface MountSingleProportional5 – 1501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV100DSMVSurface MountDualProportional5 – – – ±100±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV1000SMVSurface MountSingleProportional5 – 10001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SMV100SMVSurface MountSingleProportional5 – 1001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM9SSMSurface MountSingleProportional5 – 91.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM9DSMSurface MountDualProportional5 – – – ±9±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM5SSMSurface MountSingleProportional5 – 51 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM5DSMSurface MountDualProportional5 – – – ±5±0.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM5.2SSMSurface MountSingleProportional5 – 5.21 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM48SSMSurface MountSingleProportional5 – 481.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM48DSMSurface MountDualProportional5 – – – ±48±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM3.3SSMSurface MountSingleProportional5 – 3.31 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM28SSMSurface MountSingleProportional5 – 281.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM28DSMSurface MountDualProportional5 – – – ±28±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM250SSMSurface MountSingleProportional5 – 2501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM24SSMSurface MountSingleProportional5 – 241.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM24DSMSurface MountDualProportional5 – – – ±24±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM200SSMSurface MountSingleProportional5 – 2001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM15SSMSurface MountSingleProportional5 – 151.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM15DSMSurface MountDualProportional5 – – – ±15±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM150SSMSurface MountSingleProportional5 – 1501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM12SSMSurface MountSingleProportional5 – 121.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM12DSMSurface MountDualProportional5 – – – ±12±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SM100SSMSurface MountSingleProportional5 – 1001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SFR5SSFRSurface MountSingleRegulated54.5 – 5.550.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SFR5DSFRSurface MountDualRegulated54.5 – 5.5 – – 5/50.25/0.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SFR15SSFRSurface MountSingleRegulated54.5 – 5.5151 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SFR15DSFRSurface MountDualRegulated54.5 – 5.5 – – 15/150.35/0.35 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SFR12SSFRSurface MountSingleRegulated54.5 – 5.5121 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SFR12DSFRSurface MountDualRegulated54.5 – 5.5 – – 12/120.35/0.35 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE9SSESurface MountSingleProportional5 – 94.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE9DSESurface MountDualProportional5 – – – 9/92.25/2.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE5SSESurface MountSingleProportional5 – 54 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE5DSESurface MountDualProportional5 – – – 5/52/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE5.2SSESurface MountSingleProportional5 – 5.24 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE48SSESurface MountSingleProportional5 – 484.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE48DSESurface MountDualProportional5 – – – 48/482.25/2.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE3.3SSESurface MountSingleProportional5 – 3.33.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE28SSESurface MountSingleProportional5 – 284.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE28DSESurface MountDualProportional5 – – – 28/282.25/2.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE24SSESurface MountSingleProportional5 – 244.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE24DSESurface MountDualProportional5 – – – 24/242.25/2.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE15SSESurface MountSingleProportional5 – 154.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE15DSESurface MountDualProportional5 – – – 15/152.25/2.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE12SSESurface MountSingleProportional5 – 124.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SE12DSESurface MountDualProportional5 – – – 12/122.25/2.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SDT9SSDTSurface MountSingleProportional5 – 90.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SDT9DDTThrough HoleDualProportional5 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
5SDT5SSDTSurface MountSingleProportional5 – 50.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SDT5DDTThrough HoleDualProportional5 – – – ±5±0.375 – –
DatasheetMechanical Drawing3D Model
5SDT5.2SSDTSurface MountSingleProportional5 – 5.20.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SDT3.3SSDTSurface MountSingleProportional5 – 3.30.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SDT15SSDTSurface MountSingleProportional5 – 150.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SDT15DDTThrough HoleDualProportional5 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
5SDT12SSDTSurface MountSingleProportional5 – 120.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SDT12DDTThrough HoleDualProportional5 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
5SC9SSCSurface MountSingleProportional5 – 93 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC9DSCSurface MountDualProportional5 – – – 9/91.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC5SSCSurface MountSingleProportional5 – 52.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC5DSCSurface MountDualProportional5 – – – 5/51.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC5.2SSCSurface MountSingleProportional5 – 5.22.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC48SSCSurface MountSingleProportional5 – 483 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC48DSCSurface MountDualProportional5 – – – 48/481.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC3.3SSCSurface MountSingleProportional5 – 3.32.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC28SSCSurface MountSingleProportional5 – 283 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC28DSCSurface MountDualProportional5 – – – 28/281.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC24SSCSurface MountSingleProportional5 – 243 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC24DSCSurface MountDualProportional5 – – – 24/241.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC15SSCSurface MountSingleProportional5 – 153 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC15DSCSurface MountDualProportional5 – – – 15/151.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SC12DSCSurface MountDualProportional5 – – – 12/121.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB9SSBSurface MountSingleProportional5 – 91.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB9DSBSurface MountDualProportional5 – – – 9/90.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB5SSBSurface MountSingleProportional5 – 51.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB5DSBSurface MountDualProportional5 – – – 5/50.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB5.2SSBSurface MountSingleProportional5 – 5.21.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB48SSBSurface MountSingleProportional5 – 481.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB48DSBSurface MountDualProportional5 – – – 48/480.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB3.3SSBSurface MountSingleProportional5 – 3.31.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB28SSBSurface MountSingleProportional5 – 281.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB28DSBSurface MountDualProportional5 – – – 28/280.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB24SSBSurface MountSingleProportional5 – 241.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB24DSBSurface MountDualProportional5 – – – 24/240.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB15SSBSurface MountSingleProportional5 – 151.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB15DSBSurface MountDualProportional5 – – – 15/150.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB12SSBSurface MountSingleProportional5 – 121.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SB12DSBSurface MountDualProportional5 – – – 12/120.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAT9SSATSurface MountSingleProportional5 – 90.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAT9DSATSurface MountDualProportional5 – – – ±9±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAT5SSATSurface MountSingleProportional5 – 50.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAT5DSATSurface MountDualProportional5 – – – ±5±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAT5.2SSATSurface MountSingleProportional5 – 5.20.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAT3.3SSATSurface MountSingleProportional5 – 3.30.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAT15SSATSurface MountSingleProportional5 – 150.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAT15DSATSurface MountDualProportional5 – – – ±15±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAT12SSATSurface MountSingleProportional5 – 120.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAT12DSATSurface MountDualProportional5 – – – ±12±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAR500SMSAR-SMSurface MountSingleRegulated Programmable7.55 – 105003±250±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAR500SARThrough HoleSingleRegulated Programmable7.55 – 105003±250±1.5 – –
DatasheetMechanical Drawing3D Model
5SAR250SMSAR-SMSurface MountSingleRegulated Programmable7.55 – 102503±125±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAR250SARThrough HoleSingleRegulated Programmable7.55 – 102503±125±1.5 – –
DatasheetMechanical Drawing3D Model
5SAR1500SMSAR-SMSurface MountSingleRegulated Programmable7.55 – 1015003±750±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAR1500SARThrough HoleSingleRegulated Programmable7.55 – 1015003±750±1.5 – –
DatasheetMechanical Drawing3D Model
5SAR100SMSAR-SMSurface MountSingleRegulated Programmable7.55 – 101003±50±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAR1000SMSAR-SMSurface MountSingleRegulated Programmable7.55 – 1010003±500±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
5SAR1000SARThrough HoleSingleRegulated Programmable7.55 – 1010003±500±1.5 – –
DatasheetMechanical Drawing3D Model
5SAR100SARThrough HoleSingleRegulated Programmable7.55 – 101003±50±1.5 – –
DatasheetMechanical Drawing3D Model
5SA900SMSA-SMSurface MountSingleProportional5 – 9003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA900SAThrough HoleSingleProportional5 – 9003 – – – –
DatasheetMechanical Drawing3D Model
5SA800SMSA-SMSurface MountSingleProportional5 – 8003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA800SAThrough HoleSingleProportional5 – 8003 – – – –
DatasheetMechanical Drawing3D Model
5SA700SMSA-SMSurface MountSingleProportional5 – 7003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA700SAThrough HoleSingleProportional5 – 7003 – – – –
DatasheetMechanical Drawing3D Model
5SA600SMSA-SMSurface MountSingleProportional5 – 6003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA600SAThrough HoleSingleProportional5 – 6003 – – – –
DatasheetMechanical Drawing3D Model
5SA500SMSA-SMSurface MountSingleProportional5 – 5003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA500SAThrough HoleSingleProportional5 – 5003 – – – –
DatasheetMechanical Drawing3D Model
5SA450SMSA-SMSurface MountSingleProportional5 – 4503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA450SAThrough HoleSingleProportional5 – 4503 – – – –
DatasheetMechanical Drawing3D Model
5SA400SMSA-SMSurface MountSingleProportional5 – 4003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA400SAThrough HoleSingleProportional5 – 4003 – – – –
DatasheetMechanical Drawing3D Model
5SA350SMSA-SMSurface MountSingleProportional5 – 3503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA350SAThrough HoleSingleProportional5 – 3503 – – – –
DatasheetMechanical Drawing3D Model
5SA300SMSA-SMSurface MountSingleProportional5 – 3003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA300SAThrough HoleSingleProportional5 – 3003 – – – –
DatasheetMechanical Drawing3D Model
5SA250SMSA-SMSurface MountSingleProportional5 – 2503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA250SAThrough HoleSingleProportional5 – 2503 – – – –
DatasheetMechanical Drawing3D Model
5SA200SMSA-SMSurface MountSingleProportional5 – 2003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA200SAThrough HoleSingleProportional5 – 2003 – – – –
DatasheetMechanical Drawing3D Model
5SA150SMSA-SMSurface MountSingleProportional5 – 1503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA150SAThrough HoleSingleProportional5 – 1503 – – – –
DatasheetMechanical Drawing3D Model
5SA100SMSA-SMSurface MountSingleProportional5 – 1003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA1000SMSA-SMSurface MountSingleProportional5 – 10003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
5SA1000SAThrough HoleSingleProportional5 – 10003 – – – –
DatasheetMechanical Drawing3D Model
5SA100SAThrough HoleSingleProportional5 – 1003 – – – –
DatasheetMechanical Drawing3D Model
5MV500MVThrough HoleSingleProportional5 – 5001.25 – – – –
DatasheetMechanical Drawing3D Model
5MV450MVThrough HoleSingleProportional5 – 4501.25 – – – –
DatasheetMechanical Drawing3D Model
5MV400MVThrough HoleSingleProportional5 – 4001.25 – – – –
DatasheetMechanical Drawing3D Model
5MV350MVThrough HoleSingleProportional5 – 3501.25 – – – –
DatasheetMechanical Drawing3D Model
5MV300MVThrough HoleSingleProportional5 – 3001.25 – – – –
DatasheetMechanical Drawing3D Model
5MV250MVThrough HoleSingleProportional5 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
5MV200MVThrough HoleSingleProportional5 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
5MV150MVThrough HoleSingleProportional5 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
5MV100MVThrough HoleSingleProportional5 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
5M9SMThrough HoleSingleProportional5 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
5M9DMThrough HoleDualProportional5 – – – 9/90.625/0.625 – –
DatasheetMechanical Drawing3D Model
5M5SMThrough HoleSingleProportional5 – 51 – – – –
DatasheetMechanical Drawing3D Model
5M5DMThrough HoleDualProportional5 – – – 5/50.5/0.5 – –
DatasheetMechanical Drawing3D Model
5M5.2SMThrough HoleSingleProportional5 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
5M48SMThrough HoleSingleProportional5 – 481.25 – – – –
DatasheetMechanical Drawing3D Model
5M48DMThrough HoleDualProportional5 – – – 48/480.625/0.625 – –
DatasheetMechanical Drawing3D Model
5M3.3SMThrough HoleSingleProportional5 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
5M28SMThrough HoleSingleProportional5 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
5M28DMThrough HoleDualProportional5 – – – 28/280.625/0.625 – –
DatasheetMechanical Drawing3D Model
5M24SMThrough HoleSingleProportional5 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
5M24DMThrough HoleDualProportional5 – – – 24/240.625/0.625 – –
DatasheetMechanical Drawing3D Model
5M15SMThrough HoleSingleProportional5 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
5M15DMThrough HoleDualProportional5 – – – 15/150.625/0.625 – –
DatasheetMechanical Drawing3D Model
5M12SMThrough HoleSingleProportional5 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
5M12DMThrough HoleDualProportional5 – – – 12/120.625/0.625 – –
DatasheetMechanical Drawing3D Model
5FR5SFRThrough HoleSingleRegulated54.5 – 5.550.75 – – – –
DatasheetMechanical Drawing3D Model
5FR5DFRThrough HoleDualRegulated54.5 – 5.5 – – 5/50.25/0.25 – –
DatasheetMechanical Drawing3D Model
5FR15SFRThrough HoleSingleRegulated54.5 – 5.5151 – – – –
DatasheetMechanical Drawing3D Model
5FR15DFRThrough HoleDualRegulated54.5 – 5.5 – – 15/150.35/0.35 – –
DatasheetMechanical Drawing3D Model
5FR12SFRThrough HoleSingleRegulated54.5 – 5.5121 – – – –
DatasheetMechanical Drawing3D Model
5FR12DFRThrough HoleDualRegulated54.5 – 5.5 – – 12/120.35/0.35 – –
DatasheetMechanical Drawing3D Model
5E9SEThrough HoleSingleProportional5 – 94.5 – – – –
DatasheetMechanical Drawing3D Model
5E9DEThrough HoleDualProportional5 – – – 9/92.25/2.25 – –
DatasheetMechanical Drawing3D Model
5E5SEThrough HoleSingleProportional5 – 54 – – – –
DatasheetMechanical Drawing3D Model
5E5DEThrough HoleDualProportional5 – – – 5/52/2 – –
DatasheetMechanical Drawing3D Model
5E5.2SEThrough HoleSingleProportional5 – 5.24 – – – –
DatasheetMechanical Drawing3D Model
5E48SEThrough HoleSingleProportional5 – 484.5 – – – –
DatasheetMechanical Drawing3D Model
5E48DEThrough HoleDualProportional5 – – – 48/482.25/2.25 – –
DatasheetMechanical Drawing3D Model
5E3.3SEThrough HoleSingleProportional5 – 3.33.5 – – – –
DatasheetMechanical Drawing3D Model
5E28SEThrough HoleSingleProportional5 – 284.5 – – – –
DatasheetMechanical Drawing3D Model
5E28DEThrough HoleDualProportional5 – – – 28/282.25/2.25 – –
DatasheetMechanical Drawing3D Model
5E24SEThrough HoleSingleProportional5 – 244.5 – – – –
DatasheetMechanical Drawing3D Model
5E24DEThrough HoleDualProportional5 – – – 24/242.25/2.25 – –
DatasheetMechanical Drawing3D Model
5E15SEThrough HoleSingleProportional5 – 154.5 – – – –
DatasheetMechanical Drawing3D Model
5E15DEThrough HoleDualProportional5 – – – 15/152.25/2.25 – –
DatasheetMechanical Drawing3D Model
5E12SEThrough HoleSingleProportional5 – 124.5 – – – –
DatasheetMechanical Drawing3D Model
5E12DEThrough HoleDualProportional5 – – – 12/122.25/2.25 – –
DatasheetMechanical Drawing3D Model
5DT9SDTThrough HoleSingleProportional5 – 90.75 – – – –
DatasheetMechanical Drawing3D Model
5DT9DDTThrough HoleDualProportional5 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
5DT5SDTThrough HoleSingleProportional5 – 50.75 – – – –
DatasheetMechanical Drawing3D Model
5DT5DDTThrough HoleDualProportional5 – – – ±5±0.375 – –
DatasheetMechanical Drawing3D Model
5DT5.2SDTThrough HoleSingleProportional5 – 5.20.75 – – – –
DatasheetMechanical Drawing3D Model
5DT3.3SDTThrough HoleSingleProportional5 – 3.30.75 – – – –
DatasheetMechanical Drawing3D Model
5DT15SDTThrough HoleSingleProportional5 – 150.75 – – – –
DatasheetMechanical Drawing3D Model
5DT15DDTThrough HoleDualProportional5 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
5DT12SDTThrough HoleSingleProportional5 – 120.75 – – – –
DatasheetMechanical Drawing3D Model
5DT12DDTThrough HoleDualProportional5 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
5C9SCThrough HoleSingleProportional5 – 93 – – – –
DatasheetMechanical Drawing3D Model
5C9DCThrough HoleDualProportional5 – – – 9/91.5/1.5 – –
DatasheetMechanical Drawing3D Model
5C5SCThrough HoleSingleProportional5 – 52.5 – – – –
DatasheetMechanical Drawing3D Model
5C5DCThrough HoleDualProportional5 – – – 5/51.25/1.25 – –
DatasheetMechanical Drawing3D Model
5C5.2SCThrough HoleSingleProportional5 – 5.22.5 – – – –
DatasheetMechanical Drawing3D Model
5C48SCThrough HoleSingleProportional5 – 483 – – – –
DatasheetMechanical Drawing3D Model
5C48DCThrough HoleDualProportional5 – – – 48/481.5/1.5 – –
DatasheetMechanical Drawing3D Model
5C3.3SCThrough HoleSingleProportional5 – 3.32.5 – – – –
DatasheetMechanical Drawing3D Model
5C28SCThrough HoleSingleProportional5 – 283 – – – –
DatasheetMechanical Drawing3D Model
5C28DCThrough HoleDualProportional5 – – – 28/281.5/1.5 – –
DatasheetMechanical Drawing3D Model
5C24SCThrough HoleSingleProportional5 – 243 – – – –
DatasheetMechanical Drawing3D Model
5C24DCThrough HoleDualProportional5 – – – 24/241.5/1.5 – –
DatasheetMechanical Drawing3D Model
5C15SCThrough HoleSingleProportional5 – 153 – – – –
DatasheetMechanical Drawing3D Model
5C15DCThrough HoleDualProportional5 – – – 15/151.5/1.5 – –
DatasheetMechanical Drawing3D Model
5C12SCThrough HoleSingleProportional5 – 123 – – – –
DatasheetMechanical Drawing3D Model
5C12DCThrough HoleDualProportional5 – – – 12/121.5/1.5 – –
DatasheetMechanical Drawing3D Model
5B9SBThrough HoleSingleProportional5 – 91.5 – – – –
DatasheetMechanical Drawing3D Model
5B9DBThrough HoleDualProportional5 – – – 9/90.75/0.75 – –
DatasheetMechanical Drawing3D Model
5B5SBThrough HoleSingleProportional5 – 51.5 – – – –
DatasheetMechanical Drawing3D Model
5B5DBThrough HoleDualProportional5 – – – 5/50.75/0.75 – –
DatasheetMechanical Drawing3D Model
5B5.2SBThrough HoleSingleProportional5 – 5.21.5 – – – –
DatasheetMechanical Drawing3D Model
5B48SBThrough HoleSingleProportional5 – 481.5 – – – –
DatasheetMechanical Drawing3D Model
5B48DBThrough HoleDualProportional5 – – – 48/480.75/0.75 – –
DatasheetMechanical Drawing3D Model
5B3.3SBThrough HoleSingleProportional5 – 3.31.5 – – – –
DatasheetMechanical Drawing3D Model
5B28SBThrough HoleSingleProportional5 – 281.5 – – – –
DatasheetMechanical Drawing3D Model
5B28DBThrough HoleDualProportional5 – – – 28/280.75/0.75 – –
DatasheetMechanical Drawing3D Model
5B24SBThrough HoleSingleProportional5 – 241.5 – – – –
DatasheetMechanical Drawing3D Model
5B24DBThrough HoleDualProportional5 – – – 24/240.75/0.75 – –
DatasheetMechanical Drawing3D Model
5B15SBThrough HoleSingleProportional5 – 151.5 – – – –
DatasheetMechanical Drawing3D Model
5B15DBThrough HoleDualProportional5 – – – 15/150.75/0.75 – –
DatasheetMechanical Drawing3D Model
5B12SBThrough HoleSingleProportional5 – 121.5 – – – –
DatasheetMechanical Drawing3D Model
5B12DBThrough HoleDualProportional5 – – – 12/120.75/0.75 – –
DatasheetMechanical Drawing3D Model
5AVR900AVRThrough HoleSingleRegulated54.5 – 5.59001 – – – –
DatasheetMechanical Drawing3D Model
5AVR800AVRThrough HoleSingleRegulated54.5 – 5.58001 – – – –
DatasheetMechanical Drawing3D Model
5AVR700AVRThrough HoleSingleRegulated54.5 – 5.57001 – – – –
DatasheetMechanical Drawing3D Model
5AVR600AVRThrough HoleSingleRegulated54.5 – 5.56001 – – – –
DatasheetMechanical Drawing3D Model
5AVR500AVRThrough HoleSingleRegulated54.5 – 5.55001 – – – –
DatasheetMechanical Drawing3D Model
5AVR400AVRThrough HoleSingleRegulated54.5 – 5.54001 – – – –
DatasheetMechanical Drawing3D Model
5AVR300AVRThrough HoleSingleRegulated54.5 – 5.53001 – – – –
DatasheetMechanical Drawing3D Model
5AVR200AVRThrough HoleSingleRegulated54.5 – 5.52001 – – – –
DatasheetMechanical Drawing3D Model
5AVR1000AVRThrough HoleSingleRegulated54.5 – 5.510001 – – – –
DatasheetMechanical Drawing3D Model
5AVR100AVRThrough HoleSingleRegulated54.5 – 5.51001 – – – –
DatasheetMechanical Drawing3D Model
5AVP9KAV (1500-10kV)Through HoleSingleProportional5 – +90001.25 – – – –
DatasheetMechanical Drawing3D Model
5AVP8KAV (1500-10kV)Through HoleSingleProportional5 – +80001.25 – – – –
DatasheetMechanical Drawing3D Model
5AVP7KAV (1500-10kV)Through HoleSingleProportional5 – +70001.25 – – – –
DatasheetMechanical Drawing3D Model
5AVP6KAV (1500-10kV)Through HoleSingleProportional5 – +60001.25 – – – –
DatasheetMechanical Drawing3D Model
5AVP10KAV (1500-10kV)Through HoleSingleProportional5 – +100001.25 – – – –
DatasheetMechanical Drawing3D Model
5AVN9KAV (1500-10kV)Through HoleSingleProportional5 – -90001.25 – – – –
DatasheetMechanical Drawing3D Model
5AVN8KAV (1500-10kV)Through HoleSingleProportional5 – -80001.25 – – – –
DatasheetMechanical Drawing3D Model
5AVN7KAV (1500-10kV)Through HoleSingleProportional5 – -70001.25 – – – –
DatasheetMechanical Drawing3D Model
5AVN6KAV (1500-10kV)Through HoleSingleProportional5 – -60001.25 – – – –
DatasheetMechanical Drawing3D Model
5AVN10KAV (1500-10kV)Through HoleSingleProportional5 – -100001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV900AV (100-1kV)Through HoleSingleProportional5 – 9001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV800AV (100-1kV)Through HoleSingleProportional5 – 8001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV700AV (100-1kV)Through HoleSingleProportional5 – 7001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV600AV (100-1kV)Through HoleSingleProportional5 – 6001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV5000-PAV (1500-10kV)Through HoleSingleProportional5 – +50001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV5000-NAV (1500-10kV)Through HoleSingleProportional5 – -50001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV5000AV (1500-10kV)Through HoleSingleProportional5 – 50001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV500AV (100-1kV)Through HoleSingleProportional5 – 5001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV4500-PAV (1500-10kV)Through HoleSingleProportional5 – +45001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV4500-NAV (1500-10kV)Through HoleSingleProportional5 – -45001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV4500AV (1500-10kV)Through HoleSingleProportional5 – 45001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV450AV (100-1kV)Through HoleSingleProportional5 – 4501.25 – – – –
DatasheetMechanical Drawing3D Model
5AV4000-PAV (1500-10kV)Through HoleSingleProportional5 – +40001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV4000-NAV (1500-10kV)Through HoleSingleProportional5 – -40001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV4000AV (1500-10kV)Through HoleSingleProportional5 – 40001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV400AV (100-1kV)Through HoleSingleProportional5 – 4001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV3500-PAV (1500-10kV)Through HoleSingleProportional5 – +35001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV3500-NAV (1500-10kV)Through HoleSingleProportional5 – -35001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV3500AV (1500-10kV)Through HoleSingleProportional5 – 35001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV350AV (100-1kV)Through HoleSingleProportional5 – 3501.25 – – – –
DatasheetMechanical Drawing3D Model
5AV3000-PAV (1500-10kV)Through HoleSingleProportional5 – +30001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV3000-NAV (1500-10kV)Through HoleSingleProportional5 – -30001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV3000AV (1500-10kV)Through HoleSingleProportional5 – 30001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV300AV (100-1kV)Through HoleSingleProportional5 – 3001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV250DAV (100-1kV)Through HoleDualProportional5 – – – ±250±0.625 – –
DatasheetMechanical Drawing3D Model
5AV2500-PAV (1500-10kV)Through HoleSingleProportional5 – +25001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV2500-NAV (1500-10kV)Through HoleSingleProportional5 – -25001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV2500AV (1500-10kV)Through HoleSingleProportional5 – 25001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV250AV (100-1kV)Through HoleSingleProportional5 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
5AV200DAV (100-1kV)Through HoleDualProportional5 – – – ±200±0.625 – –
DatasheetMechanical Drawing3D Model
5AV2000-PAV (1500-10kV)Through HoleSingleProportional5 – +20001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV2000-NAV (1500-10kV)Through HoleSingleProportional5 – -20001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV2000AV (1500-10kV)Through HoleSingleProportional5 – 20001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV200AV (100-1kV)Through HoleSingleProportional5 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV150DAV (100-1kV)Through HoleDualProportional5 – – – ±150±0.625 – –
DatasheetMechanical Drawing3D Model
5AV1500-PAV (1500-10kV)Through HoleSingleProportional5 – +15001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV1500-NAV (1500-10kV)Through HoleSingleProportional5 – -15001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV1500AV (1500-10kV)Through HoleSingleProportional5 – 15001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV150AV (100-1kV)Through HoleSingleProportional5 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
5AV100DAV (100-1kV)Through HoleDualProportional5 – – – ±100±0.625 – –
DatasheetMechanical Drawing3D Model
5AV1000AV (100-1kV)Through HoleSingleProportional5 – 10001.25 – – – –
DatasheetMechanical Drawing3D Model
5AV100AV (100-1kV)Through HoleSingleProportional5 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
5AT9SATThrough HoleSingleProportional5 – 90.75 – – – –
DatasheetMechanical Drawing3D Model
5AT9DATThrough HoleDualProportional5 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
5AT5SATThrough HoleSingleProportional5 – 50.75 – – – –
DatasheetMechanical Drawing3D Model
5AT5DATThrough HoleDualProportional5 – – – ±5±0.375 – –
DatasheetMechanical Drawing3D Model
5AT5.2SATThrough HoleSingleProportional5 – 5.20.75 – – – –
DatasheetMechanical Drawing3D Model
5AT3.3SATThrough HoleSingleProportional5 – 3.30.75 – – – –
DatasheetMechanical Drawing3D Model
5AT15SATThrough HoleSingleProportional5 – 150.75 – – – –
DatasheetMechanical Drawing3D Model
5AT15DATThrough HoleDualProportional5 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
5AT12SATThrough HoleSingleProportional5 – 120.75 – – – –
DatasheetMechanical Drawing3D Model
5AT12DATThrough HoleDualProportional5 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
5A9SAThrough HoleSingleProportional5 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
5A9DAThrough HoleDualProportional5 – – – ±9±0.625 – –
DatasheetMechanical Drawing3D Model
5A5SAThrough HoleSingleProportional5 – 51 – – – –
DatasheetMechanical Drawing3D Model
5A5DAThrough HoleDualProportional5 – – – ±5±0.5 – –
DatasheetMechanical Drawing3D Model
5A5.2SAThrough HoleSingleProportional5 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
5A48SAThrough HoleSingleProportional5 – 481.25 – – – –
DatasheetMechanical Drawing3D Model
5A48DAThrough HoleDualProportional5 – – – ±48±0.625 – –
DatasheetMechanical Drawing3D Model
5A3.3SAThrough HoleSingleProportional5 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
5A28SAThrough HoleSingleProportional5 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
5A28DAThrough HoleDualProportional5 – – – ±28±0.625 – –
DatasheetMechanical Drawing3D Model
5A250SAThrough HoleSingleProportional5 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
5A24SAThrough HoleSingleProportional5 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
5A24DAThrough HoleDualProportional5 – – – ±24±0.625 – –
DatasheetMechanical Drawing3D Model
5A200SAThrough HoleSingleProportional5 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
5A15SAThrough HoleSingleProportional5 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
5A15DAThrough HoleDualProportional5 – – – ±15±0.625 – –
DatasheetMechanical Drawing3D Model
5A150SAThrough HoleSingleProportional5 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
5A12SAThrough HoleSingleProportional5 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
5A12DAThrough HoleDualProportional5 – – – ±12±0.625 – –
DatasheetMechanical Drawing3D Model
5A100SAThrough HoleSingleProportional5 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
48VV9-PVV (100-10kV)Through HoleSingleProportional48 – +90006 – – – –
DatasheetMechanical Drawing3D Model
48VV9-NVV (100-10kV)Through HoleSingleProportional48 – -90006 – – – –
DatasheetMechanical Drawing3D Model
48VV9VV (100-10kV)Through HoleSingleProportional48 – 90006 – – – –
DatasheetMechanical Drawing3D Model
48VV8-PVV (100-10kV)Through HoleSingleProportional48 – +80006 – – – –
DatasheetMechanical Drawing3D Model
48VV8-NVV (100-10kV)Through HoleSingleProportional48 – -80006 – – – –
DatasheetMechanical Drawing3D Model
48VV8VV (100-10kV)Through HoleSingleProportional48 – 80006 – – – –
DatasheetMechanical Drawing3D Model
48VV7-PVV (100-10kV)Through HoleSingleProportional48 – +70006 – – – –
DatasheetMechanical Drawing3D Model
48VV7-NVV (100-10kV)Through HoleSingleProportional48 – -70006 – – – –
DatasheetMechanical Drawing3D Model
48VV7VV (100-10kV)Through HoleSingleProportional48 – 70006 – – – –
DatasheetMechanical Drawing3D Model
48VV6-PVV (100-10kV)Through HoleSingleProportional48 – +60006 – – – –
DatasheetMechanical Drawing3D Model
48VV6-NVV (100-10kV)Through HoleSingleProportional48 – -60006 – – – –
DatasheetMechanical Drawing3D Model
48VV6VV (100-10kV)Through HoleSingleProportional48 – 60006 – – – –
DatasheetMechanical Drawing3D Model
48VV500SVV (100-500V)Through HoleSingleProportional48 – 5004 – – – –
DatasheetMechanical Drawing3D Model
48VV5VV (100-10kV)Through HoleSingleProportional48 – 50006 – – – –
DatasheetMechanical Drawing3D Model
48VV400SVV (100-500V)Through HoleSingleProportional48 – 4004 – – – –
DatasheetMechanical Drawing3D Model
48VV4VV (100-10kV)Through HoleSingleProportional48 – 40008 – – – –
DatasheetMechanical Drawing3D Model
48VV300SVV (100-500V)Through HoleSingleProportional48 – 3004 – – – –
DatasheetMechanical Drawing3D Model
48VV3VV (100-10kV)Through HoleSingleProportional48 – 30008 – – – –
DatasheetMechanical Drawing3D Model
48VV200SVV (100-500V)Through HoleSingleProportional48 – 2004 – – – –
DatasheetMechanical Drawing3D Model
48VV2VV (100-10kV)Through HoleSingleProportional48 – 20008 – – – –
DatasheetMechanical Drawing3D Model
48VV100SVV (100-500V)Through HoleSingleProportional48 – 1004 – – – –
DatasheetMechanical Drawing3D Model
48VV10-PVV (100-10kV)Through HoleSingleProportional48 – +100006 – – – –
DatasheetMechanical Drawing3D Model
48VV10-NVV (100-10kV)Through HoleSingleProportional48 – -100006 – – – –
DatasheetMechanical Drawing3D Model
48VV10VV (100-10kV)Through HoleSingleProportional48 – 100006 – – – –
DatasheetMechanical Drawing3D Model
48VV1VV (100-10kV)Through HoleSingleProportional48 – 10008 – – – –
DatasheetMechanical Drawing3D Model
48VV0.9VV (100-10kV)Through HoleSingleProportional48 – 9008 – – – –
DatasheetMechanical Drawing3D Model
48VV0.8VV (100-10kV)Through HoleSingleProportional48 – 8008 – – – –
DatasheetMechanical Drawing3D Model
48VV0.7VV (100-10kV)Through HoleSingleProportional48 – 7008 – – – –
DatasheetMechanical Drawing3D Model
48VV0.6VV (100-10kV)Through HoleSingleProportional48 – 6008 – – – –
DatasheetMechanical Drawing3D Model
48VV0.5VV (100-10kV)Through HoleSingleProportional48 – 5008 – – – –
DatasheetMechanical Drawing3D Model
48VV0.4VV (100-10kV)Through HoleSingleProportional48 – 4008 – – – –
DatasheetMechanical Drawing3D Model
48VV0.3VV (100-10kV)Through HoleSingleProportional48 – 3008 – – – –
DatasheetMechanical Drawing3D Model
48VV0.2VV (100-10kV)Through HoleSingleProportional48 – 2008 – – – –
DatasheetMechanical Drawing3D Model
48VV0.1VV (100-10kV)Through HoleSingleProportional48 – 1008 – – – –
DatasheetMechanical Drawing3D Model
48SVV500SSVVSurface MountSingleProportional48 – 5004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SVV400SSVVSurface MountSingleProportional48 – 4004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SVV300SSVVSurface MountSingleProportional48 – 3004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SVV200SSVVSurface MountSingleProportional48 – 2004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SVV100SSVVSurface MountSingleProportional48 – 1004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM9SSMSurface MountSingleProportional48 – 91.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM9DSMSurface MountDualProportional48 – – – ±9±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM5SSMSurface MountSingleProportional48 – 51 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM5DSMSurface MountDualProportional48 – – – ±5±0.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM5.2SSMSurface MountSingleProportional48 – 5.21 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM3.3SSMSurface MountSingleProportional48 – 3.31 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM28SSMSurface MountSingleProportional48 – 281.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM28DSMSurface MountDualProportional48 – – – ±28±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM24SSMSurface MountSingleProportional48 – 241.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM24DSMSurface MountDualProportional48 – – – ±24±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM15SSMSurface MountSingleProportional48 – 151.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM15DSMSurface MountDualProportional48 – – – ±15±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM12SSMSurface MountSingleProportional48 – 121.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SM12DSMSurface MountDualProportional48 – – – ±12±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE9SSESurface MountSingleProportional48 – 96 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE9DSESurface MountDualProportional48 – – – 9/93/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE5SSESurface MountSingleProportional48 – 54 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE5DSESurface MountDualProportional48 – – – 5/52/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE5.2SSESurface MountSingleProportional48 – 5.24 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE3.3SSESurface MountSingleProportional48 – 3.33.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE28SSESurface MountSingleProportional48 – 287 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE28DSESurface MountDualProportional48 – – – 28/283.5/3.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE24SSESurface MountSingleProportional48 – 247 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE24DSESurface MountDualProportional48 – – – 24/243.5/3.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE15SSESurface MountSingleProportional48 – 156.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE15DSESurface MountDualProportional48 – – – 15/153.25/3.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE12SSESurface MountSingleProportional48 – 126.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SE12DSESurface MountDualProportional48 – – – 12/123.25/3.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC9SSCSurface MountSingleProportional48 – 93 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC9DSCSurface MountDualProportional48 – – – 9/91.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC5SSCSurface MountSingleProportional48 – 52.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC5DSCSurface MountDualProportional48 – – – 5/51.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC5.2SSCSurface MountSingleProportional48 – 5.22.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC3.3SSCSurface MountSingleProportional48 – 3.32.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC28SSCSurface MountSingleProportional48 – 284 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC28DSCSurface MountDualProportional48 – – – 28/282/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC24SSCSurface MountSingleProportional48 – 244 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC24DSCSurface MountDualProportional48 – – – 24/242/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC15SSCSurface MountSingleProportional48 – 153.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC15DSCSurface MountDualProportional48 – – – 15/151.75/1.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC12SSCSurface MountSingleProportional48 – 123.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SC12DSCSurface MountDualProportional48 – – – 12/121.75/1.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB9SSBSurface MountSingleProportional48 – 92 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB9DSBSurface MountDualProportional48 – – – 9/91/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB5SSBSurface MountSingleProportional48 – 51.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB5DSBSurface MountDualProportional48 – – – 5/50.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB5.2SSBSurface MountSingleProportional48 – 5.21.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB3.3SSBSurface MountSingleProportional48 – 3.31.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB28SSBSurface MountSingleProportional48 – 282.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB28DSBSurface MountDualProportional48 – – – 28/281.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB24SSBSurface MountSingleProportional48 – 242.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB24DSBSurface MountDualProportional48 – – – 24/241.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB15SSBSurface MountSingleProportional48 – 152 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB15DSBSurface MountDualProportional48 – – – 15/151/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB12SSBSurface MountSingleProportional48 – 122 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
48SB12DSBSurface MountDualProportional48 – – – 12/121/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
48E9SEThrough HoleSingleProportional48 – 96 – – – –
DatasheetMechanical Drawing3D Model
48E9DEThrough HoleDualProportional48 – – – 9/93/3 – –
DatasheetMechanical Drawing3D Model
48E5SEThrough HoleSingleProportional48 – 54 – – – –
DatasheetMechanical Drawing3D Model
48E5DEThrough HoleDualProportional48 – – – 5/52/2 – –
DatasheetMechanical Drawing3D Model
48E5.2SEThrough HoleSingleProportional48 – 5.24 – – – –
DatasheetMechanical Drawing3D Model
48E3.3SEThrough HoleSingleProportional48 – 3.33.5 – – – –
DatasheetMechanical Drawing3D Model
48E28SEThrough HoleSingleProportional48 – 287 – – – –
DatasheetMechanical Drawing3D Model
48E28DEThrough HoleDualProportional48 – – – 28/283.5/3.5 – –
DatasheetMechanical Drawing3D Model
48E24SEThrough HoleSingleProportional48 – 247 – – – –
DatasheetMechanical Drawing3D Model
48E24DEThrough HoleDualProportional48 – – – 24/243.5/3.5 – –
DatasheetMechanical Drawing3D Model
48E15SEThrough HoleSingleProportional48 – 156.5 – – – –
DatasheetMechanical Drawing3D Model
48E15DEThrough HoleDualProportional48 – – – 15/153.25/3.25 – –
DatasheetMechanical Drawing3D Model
48E12SEThrough HoleSingleProportional48 – 126.5 – – – –
DatasheetMechanical Drawing3D Model
48E12DEThrough HoleDualProportional48 – – – 12/123.25/3.25 – –
DatasheetMechanical Drawing3D Model
48C9SCThrough HoleSingleProportional48 – 93 – – – –
DatasheetMechanical Drawing3D Model
48C9DCThrough HoleDualProportional48 – – – 9/91.5/1.5 – –
DatasheetMechanical Drawing3D Model
48C5SCThrough HoleSingleProportional48 – 52.5 – – – –
DatasheetMechanical Drawing3D Model
48C5DCThrough HoleDualProportional48 – – – 5/51.25/1.25 – –
DatasheetMechanical Drawing3D Model
48C5.2SCThrough HoleSingleProportional48 – 5.22.5 – – – –
DatasheetMechanical Drawing3D Model
48C3.3SCThrough HoleSingleProportional48 – 3.32.5 – – – –
DatasheetMechanical Drawing3D Model
48C28SCThrough HoleSingleProportional48 – 284 – – – –
DatasheetMechanical Drawing3D Model
48C28DCThrough HoleDualProportional48 – – – 28/282/2 – –
DatasheetMechanical Drawing3D Model
48C24SCThrough HoleSingleProportional48 – 244 – – – –
DatasheetMechanical Drawing3D Model
48C24DCThrough HoleDualProportional48 – – – 24/242/2 – –
DatasheetMechanical Drawing3D Model
48C15SCThrough HoleSingleProportional48 – 153.5 – – – –
DatasheetMechanical Drawing3D Model
48C15DCThrough HoleDualProportional48 – – – 15/151.75/1.75 – –
DatasheetMechanical Drawing3D Model
48C12SCThrough HoleSingleProportional48 – 123.5 – – – –
DatasheetMechanical Drawing3D Model
48C12DCThrough HoleDualProportional48 – – – 12/121.75/1.75 – –
DatasheetMechanical Drawing3D Model
48B9SBThrough HoleSingleProportional48 – 92 – – – –
DatasheetMechanical Drawing3D Model
48B9DBThrough HoleDualProportional48 – – – 9/91/1 – –
DatasheetMechanical Drawing3D Model
48B5SBThrough HoleSingleProportional48 – 51.5 – – – –
DatasheetMechanical Drawing3D Model
48B5DBThrough HoleDualProportional48 – – – 5/50.75/0.75 – –
DatasheetMechanical Drawing3D Model
48B5.2SBThrough HoleSingleProportional48 – 5.21.5 – – – –
DatasheetMechanical Drawing3D Model
48B3.3SBThrough HoleSingleProportional48 – 3.31.5 – – – –
DatasheetMechanical Drawing3D Model
48B28SBThrough HoleSingleProportional48 – 282.5 – – – –
DatasheetMechanical Drawing3D Model
48B28DBThrough HoleDualProportional48 – – – 28/281.25/1.25 – –
DatasheetMechanical Drawing3D Model
48B24SBThrough HoleSingleProportional48 – 242.5 – – – –
DatasheetMechanical Drawing3D Model
48B24DBThrough HoleDualProportional48 – – – 24/241.25/1.25 – –
DatasheetMechanical Drawing3D Model
48B15SBThrough HoleSingleProportional48 – 152 – – – –
DatasheetMechanical Drawing3D Model
48B15DBThrough HoleDualProportional48 – – – 15/151/1 – –
DatasheetMechanical Drawing3D Model
48B12SBThrough HoleSingleProportional48 – 122 – – – –
DatasheetMechanical Drawing3D Model
48B12DBThrough HoleDualProportional48 – – – 12/121/1 – –
DatasheetMechanical Drawing3D Model
48AV5000-PAV (1500-10kV)Through HoleSingleProportional48 – +50001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV5000-NAV (1500-10kV)Through HoleSingleProportional48 – -50001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV5000AV (1500-10kV)Through HoleSingleProportional48 – 50001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV4500-PAV (1500-10kV)Through HoleSingleProportional48 – +45001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV4500-NAV (1500-10kV)Through HoleSingleProportional48 – -45001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV4500AV (1500-10kV)Through HoleSingleProportional48 – 45001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV4000-PAV (1500-10kV)Through HoleSingleProportional48 – +40001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV4000-NAV (1500-10kV)Through HoleSingleProportional48 – -40001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV4000AV (1500-10kV)Through HoleSingleProportional48 – 40001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV3500-PAV (1500-10kV)Through HoleSingleProportional48 – +35001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV3500-NAV (1500-10kV)Through HoleSingleProportional48 – -35001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV3500AV (1500-10kV)Through HoleSingleProportional48 – 35001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV3000-PAV (1500-10kV)Through HoleSingleProportional48 – +30001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV3000-NAV (1500-10kV)Through HoleSingleProportional48 – -30001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV3000AV (1500-10kV)Through HoleSingleProportional48 – 30001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV2500-PAV (1500-10kV)Through HoleSingleProportional48 – +25001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV2500-NAV (1500-10kV)Through HoleSingleProportional48 – -25001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV2500AV (1500-10kV)Through HoleSingleProportional48 – 25001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV2000-PAV (1500-10kV)Through HoleSingleProportional48 – +20001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV2000-NAV (1500-10kV)Through HoleSingleProportional48 – -20001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV2000AV (1500-10kV)Through HoleSingleProportional48 – 20001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV1500-PAV (1500-10kV)Through HoleSingleProportional48 – +15001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV1500-NAV (1500-10kV)Through HoleSingleProportional48 – -15001.25 – – – –
DatasheetMechanical Drawing3D Model
48AV1500AV (1500-10kV)Through HoleSingleProportional48 – 15001.25 – – – –
DatasheetMechanical Drawing3D Model
48A9SAThrough HoleSingleProportional48 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
48A9DAThrough HoleDualProportional48 – – – ±9±0.625 – –
DatasheetMechanical Drawing3D Model
48A5SAThrough HoleSingleProportional48 – 51 – – – –
DatasheetMechanical Drawing3D Model
48A5DAThrough HoleDualProportional48 – – – ±5±0.5 – –
DatasheetMechanical Drawing3D Model
48A5.2SAThrough HoleSingleProportional48 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
48A3.3SAThrough HoleSingleProportional48 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
48A28SAThrough HoleSingleProportional48 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
48A28DAThrough HoleDualProportional48 – – – ±28±0.625 – –
DatasheetMechanical Drawing3D Model
48A24SAThrough HoleSingleProportional48 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
48A24DAThrough HoleDualProportional48 – – – ±24±0.625 – –
DatasheetMechanical Drawing3D Model
48A15SAThrough HoleSingleProportional48 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
48A15DAThrough HoleDualProportional48 – – – ±15±0.625 – –
DatasheetMechanical Drawing3D Model
48A12SAThrough HoleSingleProportional48 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
48A12DAThrough HoleDualProportional48 – – – ±12±0.625 – –
DatasheetMechanical Drawing3D Model
3SDT9SSDTSurface MountSingleProportional3 – 90.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SDT9DDTThrough HoleDualProportional3 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
3SDT5SSDTSurface MountSingleProportional3 – 50.65 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SDT5DDTThrough HoleDualProportional3 – – – ±5±0.325 – –
DatasheetMechanical Drawing3D Model
3SDT5.2SSDTSurface MountSingleProportional3 – 5.20.65 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SDT3.3SSDTSurface MountSingleProportional3 – 3.30.65 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SDT15SSDTSurface MountSingleProportional3 – 150.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SDT15DDTThrough HoleDualProportional3 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
3SDT12SSDTSurface MountSingleProportional3 – 120.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SDT12DDTThrough HoleDualProportional3 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
3SAT9SSATSurface MountSingleProportional3 – 90.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SAT9DSATSurface MountDualProportional3 – – – ±9±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
3SAT5SSATSurface MountSingleProportional3 – 50.65 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SAT5DSATSurface MountDualProportional3 – – – ±5±0.325 – –
DatasheetMechanical DrawingLand Pattern3D Model
3SAT5.2SSATSurface MountSingleProportional3 – 5.20.65 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SAT3.3SSATSurface MountSingleProportional3 – 3.30.65 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SAT15SSATSurface MountSingleProportional3 – 150.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SAT15DSATSurface MountDualProportional3 – – – ±15±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
3SAT12SSATSurface MountSingleProportional3 – 120.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
3SAT12DSATSurface MountDualProportional3 – – – ±12±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
3DT9SDTThrough HoleSingleProportional3 – 90.75 – – – –
DatasheetMechanical Drawing3D Model
3DT9DDTThrough HoleDualProportional3 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
3DT5SDTThrough HoleSingleProportional3 – 50.65 – – – –
DatasheetMechanical Drawing3D Model
3DT5DDTThrough HoleDualProportional3 – – – ±5±0.325 – –
DatasheetMechanical Drawing3D Model
3DT5.2SDTThrough HoleSingleProportional3 – 5.20.65 – – – –
DatasheetMechanical Drawing3D Model
3DT3.3SDTThrough HoleSingleProportional3 – 3.30.65 – – – –
DatasheetMechanical Drawing3D Model
3DT15SDTThrough HoleSingleProportional3 – 150.75 – – – –
DatasheetMechanical Drawing3D Model
3DT15DDTThrough HoleDualProportional3 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
3DT12SDTThrough HoleSingleProportional3 – 120.75 – – – –
DatasheetMechanical Drawing3D Model
3DT12DDTThrough HoleDualProportional3 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
3AT9SATThrough HoleSingleProportional3 – 90.75 – – – –
DatasheetMechanical Drawing3D Model
3AT9DATThrough HoleDualProportional3 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
3AT5SATThrough HoleSingleProportional3 – 50.65 – – – –
DatasheetMechanical Drawing3D Model
3AT5DATThrough HoleDualProportional3 – – – ±5±0.325 – –
DatasheetMechanical Drawing3D Model
3AT5.2SATThrough HoleSingleProportional3 – 5.20.65 – – – –
DatasheetMechanical Drawing3D Model
3AT3.3SATThrough HoleSingleProportional3 – 3.30.65 – – – –
DatasheetMechanical Drawing3D Model
3AT15SATThrough HoleSingleProportional3 – 150.75 – – – –
DatasheetMechanical Drawing3D Model
3AT15DATThrough HoleDualProportional3 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
3AT12SATThrough HoleSingleProportional3 – 120.75 – – – –
DatasheetMechanical Drawing3D Model
3AT12DATThrough HoleDualProportional3 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
28XSGR9SXSGRSurface MountSingleRegulated2825.2 – 30.893.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28XSGR9DXSGRSurface MountDualRegulated2825.2 – 30.8 – – 9/91.75/1.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
28XSGR5SXSGRSurface MountSingleRegulated2825.2 – 30.853 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28XSGR5DXSGRSurface MountDualRegulated2825.2 – 30.8 – – 5/51.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
28XSGR3.3SXSGRSurface MountSingleRegulated2825.2 – 30.83.32 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28XSGR2SXSGRSurface MountSingleRegulated2825.2 – 30.821.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28XSGR15SXSGRSurface MountSingleRegulated2825.2 – 30.8154.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28XSGR15DXSGRSurface MountDualRegulated2825.2 – 30.8 – – 15/152.25/2.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
28XSGR12SXSGRSurface MountSingleRegulated2825.2 – 30.8124.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28XSGR12DXSGRSurface MountDualRegulated2825.2 – 30.8 – – 12/122.25/2.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
28XGR9SXGRThrough HoleSingleRegulated2825.2 – 30.893.5 – – – –
DatasheetMechanical Drawing3D Model
28XGR9DXGRThrough HoleDualRegulated2825.2 – 30.8 – – 9/91.75/1.75 – –
DatasheetMechanical Drawing3D Model
28XGR5SXGRThrough HoleSingleRegulated2825.2 – 30.853 – – – –
DatasheetMechanical Drawing3D Model
28XGR5DXGRThrough HoleDualRegulated2825.2 – 30.8 – – 5/51.5/1.5 – –
DatasheetMechanical Drawing3D Model
28XGR3.3SXGRThrough HoleSingleRegulated2825.2 – 30.83.32 – – – –
DatasheetMechanical Drawing3D Model
28XGR2SXGRThrough HoleSingleRegulated2825.2 – 30.821.5 – – – –
DatasheetMechanical Drawing3D Model
28XGR15SXGRThrough HoleSingleRegulated2825.2 – 30.8154.5 – – – –
DatasheetMechanical Drawing3D Model
28XGR15DXGRThrough HoleDualRegulated2825.2 – 30.8 – – 15/152.25/2.25 – –
DatasheetMechanical Drawing3D Model
28XGR12SXGRThrough HoleSingleRegulated2825.2 – 30.8124.5 – – – –
DatasheetMechanical Drawing3D Model
28XGR12DXGRThrough HoleDualRegulated2825.2 – 30.8 – – 12/122.25/2.25 – –
DatasheetMechanical Drawing3D Model
28VV9-PVV (100-10kV)Through HoleSingleProportional28 – +90006 – – – –
DatasheetMechanical Drawing3D Model
28VV9-NVV (100-10kV)Through HoleSingleProportional28 – -90006 – – – –
DatasheetMechanical Drawing3D Model
28VV9VV (100-10kV)Through HoleSingleProportional28 – 90006 – – – –
DatasheetMechanical Drawing3D Model
28VV8-PVV (100-10kV)Through HoleSingleProportional28 – +80006 – – – –
DatasheetMechanical Drawing3D Model
28VV8-NVV (100-10kV)Through HoleSingleProportional28 – -80006 – – – –
DatasheetMechanical Drawing3D Model
28VV8VV (100-10kV)Through HoleSingleProportional28 – 80006 – – – –
DatasheetMechanical Drawing3D Model
28VV7-PVV (100-10kV)Through HoleSingleProportional28 – +70006 – – – –
DatasheetMechanical Drawing3D Model
28VV7-NVV (100-10kV)Through HoleSingleProportional28 – -70006 – – – –
DatasheetMechanical Drawing3D Model
28VV7VV (100-10kV)Through HoleSingleProportional28 – 70006 – – – –
DatasheetMechanical Drawing3D Model
28VV6-PVV (100-10kV)Through HoleSingleProportional28 – +60006 – – – –
DatasheetMechanical Drawing3D Model
28VV6-NVV (100-10kV)Through HoleSingleProportional28 – -60006 – – – –
DatasheetMechanical Drawing3D Model
28VV6VV (100-10kV)Through HoleSingleProportional28 – 60006 – – – –
DatasheetMechanical Drawing3D Model
28VV500SVV (100-500V)Through HoleSingleProportional28 – 5004 – – – –
DatasheetMechanical Drawing3D Model
28VV5VV (100-10kV)Through HoleSingleProportional28 – 50006 – – – –
DatasheetMechanical Drawing3D Model
28VV400SVV (100-500V)Through HoleSingleProportional28 – 4004 – – – –
DatasheetMechanical Drawing3D Model
28VV4VV (100-10kV)Through HoleSingleProportional28 – 40008 – – – –
DatasheetMechanical Drawing3D Model
28VV300SVV (100-500V)Through HoleSingleProportional28 – 3004 – – – –
DatasheetMechanical Drawing3D Model
28VV3VV (100-10kV)Through HoleSingleProportional28 – 300010 – – – –
DatasheetMechanical Drawing3D Model
28VV200SVV (100-500V)Through HoleSingleProportional28 – 2004 – – – –
DatasheetMechanical Drawing3D Model
28VV2VV (100-10kV)Through HoleSingleProportional28 – 200010 – – – –
DatasheetMechanical Drawing3D Model
28VV100SVV (100-500V)Through HoleSingleProportional28 – 1004 – – – –
DatasheetMechanical Drawing3D Model
28VV10-PVV (100-10kV)Through HoleSingleProportional28 – +100006 – – – –
DatasheetMechanical Drawing3D Model
28VV10-NVV (100-10kV)Through HoleSingleProportional28 – -100006 – – – –
DatasheetMechanical Drawing3D Model
28VV10VV (100-10kV)Through HoleSingleProportional28 – 100006 – – – –
DatasheetMechanical Drawing3D Model
28VV1VV (100-10kV)Through HoleSingleProportional28 – 100010 – – – –
DatasheetMechanical Drawing3D Model
28VV0.9VV (100-10kV)Through HoleSingleProportional28 – 90010 – – – –
DatasheetMechanical Drawing3D Model
28VV0.8VV (100-10kV)Through HoleSingleProportional28 – 80010 – – – –
DatasheetMechanical Drawing3D Model
28VV0.7VV (100-10kV)Through HoleSingleProportional28 – 70010 – – – –
DatasheetMechanical Drawing3D Model
28VV0.6VV (100-10kV)Through HoleSingleProportional28 – 60010 – – – –
DatasheetMechanical Drawing3D Model
28VV0.5VV (100-10kV)Through HoleSingleProportional28 – 50010 – – – –
DatasheetMechanical Drawing3D Model
28VV0.4VV (100-10kV)Through HoleSingleProportional28 – 40010 – – – –
DatasheetMechanical Drawing3D Model
28VV0.3VV (100-10kV)Through HoleSingleProportional28 – 30010 – – – –
DatasheetMechanical Drawing3D Model
28VV0.2VV (100-10kV)Through HoleSingleProportional28 – 20010 – – – –
DatasheetMechanical Drawing3D Model
28VV0.1VV (100-10kV)Through HoleSingleProportional28 – 10010 – – – –
DatasheetMechanical Drawing3D Model
28SVV500SSVVSurface MountSingleProportional28 – 5004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SVV400SSVVSurface MountSingleProportional28 – 4004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SVV300SSVVSurface MountSingleProportional28 – 3004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SVV200SSVVSurface MountSingleProportional28 – 2004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SVV100SSVVSurface MountSingleProportional28 – 1004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV900SMVSurface MountSingleProportional28 – 9001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV800SMVSurface MountSingleProportional28 – 8001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV700SMVSurface MountSingleProportional28 – 7001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV600SMVSurface MountSingleProportional28 – 6001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV500SMVSurface MountSingleProportional28 – 5001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV450SMVSurface MountSingleProportional28 – 4501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV400SMVSurface MountSingleProportional28 – 4001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV350SMVSurface MountSingleProportional28 – 3501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV300SMVSurface MountSingleProportional28 – 3001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV250DSMVSurface MountDualProportional28 – – – ±250±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV250SMVSurface MountSingleProportional28 – 2501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV200DSMVSurface MountDualProportional28 – – – ±200±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV200SMVSurface MountSingleProportional28 – 2001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV150DSMVSurface MountDualProportional28 – – – ±150±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV150SMVSurface MountSingleProportional28 – 1501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV100DSMVSurface MountDualProportional28 – – – ±100±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV1000SMVSurface MountSingleProportional28 – 10001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SMV100SMVSurface MountSingleProportional28 – 1001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM9SSMSurface MountSingleProportional28 – 91.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM9DSMSurface MountDualProportional28 – – – ±9±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM5SSMSurface MountSingleProportional28 – 51 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM5DSMSurface MountDualProportional28 – – – ±5±0.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM5.2SSMSurface MountSingleProportional28 – 5.21 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM48SSMSurface MountSingleProportional28 – 481.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM48DSMSurface MountDualProportional28 – – – ±48±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM3.3SSMSurface MountSingleProportional28 – 3.31 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM28SSMSurface MountSingleProportional28 – 281.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM28DSMSurface MountDualProportional28 – – – ±28±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM250SSMSurface MountSingleProportional28 – 2501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM24SSMSurface MountSingleProportional28 – 241.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM24DSMSurface MountDualProportional28 – – – ±24±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM200SSMSurface MountSingleProportional28 – 2001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM15SSMSurface MountSingleProportional28 – 151.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM15DSMSurface MountDualProportional28 – – – ±15±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM150SSMSurface MountSingleProportional28 – 1501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM12SSMSurface MountSingleProportional28 – 121.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM12DSMSurface MountDualProportional28 – – – ±12±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SM100SSMSurface MountSingleProportional28 – 1001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SFR5SSFRSurface MountSingleRegulated2825.2 – 30.850.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SFR5DSFRSurface MountDualRegulated2825.2 – 30.8 – – 5/50.25/0.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SFR15SSFRSurface MountSingleRegulated2825.2 – 30.8151 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SFR15DSFRSurface MountDualRegulated2825.2 – 30.8 – – 15/150.35/0.35 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SFR12SSFRSurface MountSingleRegulated2825.2 – 30.8121 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SFR12DSFRSurface MountDualRegulated2825.2 – 30.8 – – 12/120.35/0.35 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE9SSESurface MountSingleProportional28 – 96 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE9DSESurface MountDualProportional28 – – – 9/93/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE5SSESurface MountSingleProportional28 – 54 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE5DSESurface MountDualProportional28 – – – 5/52/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE5.2SSESurface MountSingleProportional28 – 5.24 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE48SSESurface MountSingleProportional28 – 487 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE48DSESurface MountDualProportional28 – – – 48/483.5/3.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE3.3SSESurface MountSingleProportional28 – 3.33.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE28SSESurface MountSingleProportional28 – 287 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE28DSESurface MountDualProportional28 – – – 28/283.5/3.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE24SSESurface MountSingleProportional28 – 247 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE24DSESurface MountDualProportional28 – – – 24/243.5/3.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE15SSESurface MountSingleProportional28 – 156.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE15DSESurface MountDualProportional28 – – – 15/153.25/3.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE12SSESurface MountSingleProportional28 – 126.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SE12DSESurface MountDualProportional28 – – – 12/123.25/3.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC9SSCSurface MountSingleProportional28 – 93 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC9DSCSurface MountDualProportional28 – – – 9/91.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC5SSCSurface MountSingleProportional28 – 52.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC5DSCSurface MountDualProportional28 – – – 5/51.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC5.2SSCSurface MountSingleProportional28 – 5.22.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC48SSCSurface MountSingleProportional28 – 484 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC48DSCSurface MountDualProportional28 – – – 48/482/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC3.3SSCSurface MountSingleProportional28 – 3.32.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC28SSCSurface MountSingleProportional28 – 284 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC28DSCSurface MountDualProportional28 – – – 28/282/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC24SSCSurface MountSingleProportional28 – 244 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC24DSCSurface MountDualProportional28 – – – 24/242/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC15SSCSurface MountSingleProportional28 – 153.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC15DSCSurface MountDualProportional28 – – – 15/151.75/1.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC12SSCSurface MountSingleProportional28 – 123.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SC12DSCSurface MountDualProportional28 – – – 12/121.75/1.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB9SSBSurface MountSingleProportional28 – 92 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB9DSBSurface MountDualProportional28 – – – 9/91/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB5SSBSurface MountSingleProportional28 – 51.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB5DSBSurface MountDualProportional28 – – – 5/50.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB5.2SSBSurface MountSingleProportional28 – 5.21.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB48SSBSurface MountSingleProportional28 – 482.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB48DSBSurface MountDualProportional28 – – – 48/481.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB3.3SSBSurface MountSingleProportional28 – 3.31.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB28SSBSurface MountSingleProportional28 – 282.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB28DSBSurface MountDualProportional28 – – – 28/281.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB24SSBSurface MountSingleProportional28 – 242.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB24DSBSurface MountDualProportional28 – – – 24/241.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB15SSBSurface MountSingleProportional28 – 152 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB15DSBSurface MountDualProportional28 – – – 15/151/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB12SSBSurface MountSingleProportional28 – 122 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SB12DSBSurface MountDualProportional28 – – – 12/121/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA900SMSA-SMSurface MountSingleProportional28 – 9003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA900SAThrough HoleSingleProportional28 – 9003 – – – –
DatasheetMechanical Drawing3D Model
28SA800SMSA-SMSurface MountSingleProportional28 – 8003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA800SAThrough HoleSingleProportional28 – 8003 – – – –
DatasheetMechanical Drawing3D Model
28SA700SMSA-SMSurface MountSingleProportional28 – 7003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA700SAThrough HoleSingleProportional28 – 7003 – – – –
DatasheetMechanical Drawing3D Model
28SA600SMSA-SMSurface MountSingleProportional28 – 6003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA600SAThrough HoleSingleProportional28 – 6003 – – – –
DatasheetMechanical Drawing3D Model
28SA500SMSA-SMSurface MountSingleProportional28 – 5003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA500SAThrough HoleSingleProportional28 – 5003 – – – –
DatasheetMechanical Drawing3D Model
28SA450SMSA-SMSurface MountSingleProportional28 – 4503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA450SAThrough HoleSingleProportional28 – 4503 – – – –
DatasheetMechanical Drawing3D Model
28SA400SMSA-SMSurface MountSingleProportional28 – 4003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA400SAThrough HoleSingleProportional28 – 4003 – – – –
DatasheetMechanical Drawing3D Model
28SA350SMSA-SMSurface MountSingleProportional28 – 3503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA350SAThrough HoleSingleProportional28 – 3503 – – – –
DatasheetMechanical Drawing3D Model
28SA300SMSA-SMSurface MountSingleProportional28 – 3003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA300SAThrough HoleSingleProportional28 – 3003 – – – –
DatasheetMechanical Drawing3D Model
28SA250SMSA-SMSurface MountSingleProportional28 – 2503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA250SAThrough HoleSingleProportional28 – 2503 – – – –
DatasheetMechanical Drawing3D Model
28SA200SMSA-SMSurface MountSingleProportional28 – 2003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA200SAThrough HoleSingleProportional28 – 2003 – – – –
DatasheetMechanical Drawing3D Model
28SA150SMSA-SMSurface MountSingleProportional28 – 1503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA150SAThrough HoleSingleProportional28 – 1503 – – – –
DatasheetMechanical Drawing3D Model
28SA100SMSA-SMSurface MountSingleProportional28 – 1003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA1000SMSA-SMSurface MountSingleProportional28 – 10003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
28SA1000SAThrough HoleSingleProportional28 – 10003 – – – –
DatasheetMechanical Drawing3D Model
28SA100SAThrough HoleSingleProportional28 – 1003 – – – –
DatasheetMechanical Drawing3D Model
28MV500MVThrough HoleSingleProportional28 – 5001.25 – – – –
DatasheetMechanical Drawing3D Model
28MV450MVThrough HoleSingleProportional28 – 4501.25 – – – –
DatasheetMechanical Drawing3D Model
28MV400MVThrough HoleSingleProportional28 – 4001.25 – – – –
DatasheetMechanical Drawing3D Model
28MV350MVThrough HoleSingleProportional28 – 3501.25 – – – –
DatasheetMechanical Drawing3D Model
28MV300MVThrough HoleSingleProportional28 – 3001.25 – – – –
DatasheetMechanical Drawing3D Model
28MV250MVThrough HoleSingleProportional28 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
28MV200MVThrough HoleSingleProportional28 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
28MV150MVThrough HoleSingleProportional28 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
28MV100MVThrough HoleSingleProportional28 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
28M9SMThrough HoleSingleProportional28 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
28M9DMThrough HoleDualProportional28 – – – 9/90.625/0.625 – –
DatasheetMechanical Drawing3D Model
28M5SMThrough HoleSingleProportional28 – 51 – – – –
DatasheetMechanical Drawing3D Model
28M5DMThrough HoleDualProportional28 – – – 5/50.5/0.5 – –
DatasheetMechanical Drawing3D Model
28M5.2SMThrough HoleSingleProportional28 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
28M48SMThrough HoleSingleProportional28 – 481.25 – – – –
DatasheetMechanical Drawing3D Model
28M48DMThrough HoleDualProportional28 – – – 48/480.625/0.625 – –
DatasheetMechanical Drawing3D Model
28M3.3SMThrough HoleSingleProportional28 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
28M28SMThrough HoleSingleProportional28 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
28M28DMThrough HoleDualProportional28 – – – 28/280.625/0.625 – –
DatasheetMechanical Drawing3D Model
28M24SMThrough HoleSingleProportional28 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
28M24DMThrough HoleDualProportional28 – – – 24/240.625/0.625 – –
DatasheetMechanical Drawing3D Model
28M15SMThrough HoleSingleProportional28 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
28M15DMThrough HoleDualProportional28 – – – 15/150.625/0.625 – –
DatasheetMechanical Drawing3D Model
28M12SMThrough HoleSingleProportional28 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
28M12DMThrough HoleDualProportional28 – – – 12/120.625/0.625 – –
DatasheetMechanical Drawing3D Model
28FR5SFRThrough HoleSingleRegulated2825.2 – 30.850.75 – – – –
DatasheetMechanical Drawing3D Model
28FR5DFRThrough HoleDualRegulated2825.2 – 30.8 – – 5/50.25/0.25 – –
DatasheetMechanical Drawing3D Model
28FR15SFRThrough HoleSingleRegulated2825.2 – 30.8151 – – – –
DatasheetMechanical Drawing3D Model
28FR15DFRThrough HoleDualRegulated2825.2 – 30.8 – – 15/150.35/0.35 – –
DatasheetMechanical Drawing3D Model
28FR12SFRThrough HoleSingleRegulated2825.2 – 30.8121 – – – –
DatasheetMechanical Drawing3D Model
28FR12DFRThrough HoleDualRegulated2825.2 – 30.8 – – 12/120.35/0.35 – –
DatasheetMechanical Drawing3D Model
28E9SEThrough HoleSingleProportional28 – 96 – – – –
DatasheetMechanical Drawing3D Model
28E9DEThrough HoleDualProportional28 – – – 9/93/3 – –
DatasheetMechanical Drawing3D Model
28E5SEThrough HoleSingleProportional28 – 54 – – – –
DatasheetMechanical Drawing3D Model
28E5DEThrough HoleDualProportional28 – – – 5/52/2 – –
DatasheetMechanical Drawing3D Model
28E5.2SEThrough HoleSingleProportional28 – 5.24 – – – –
DatasheetMechanical Drawing3D Model
28E48SEThrough HoleSingleProportional28 – 487 – – – –
DatasheetMechanical Drawing3D Model
28E48DEThrough HoleDualProportional28 – – – 48/483.5/3.5 – –
DatasheetMechanical Drawing3D Model
28E3.3SEThrough HoleSingleProportional28 – 3.33.5 – – – –
DatasheetMechanical Drawing3D Model
28E28SEThrough HoleSingleProportional28 – 287 – – – –
DatasheetMechanical Drawing3D Model
28E28DEThrough HoleDualProportional28 – – – 28/283.5/3.5 – –
DatasheetMechanical Drawing3D Model
28E24SEThrough HoleSingleProportional28 – 247 – – – –
DatasheetMechanical Drawing3D Model
28E24DEThrough HoleDualProportional28 – – – 24/243.5/3.5 – –
DatasheetMechanical Drawing3D Model
28E15SEThrough HoleSingleProportional28 – 156.5 – – – –
DatasheetMechanical Drawing3D Model
28E15DEThrough HoleDualProportional28 – – – 15/153.25/3.25 – –
DatasheetMechanical Drawing3D Model
28E12SEThrough HoleSingleProportional28 – 126.5 – – – –
DatasheetMechanical Drawing3D Model
28E12DEThrough HoleDualProportional28 – – – 12/123.25/3.25 – –
DatasheetMechanical Drawing3D Model
28C9SCThrough HoleSingleProportional28 – 93 – – – –
DatasheetMechanical Drawing3D Model
28C9DCThrough HoleDualProportional28 – – – 9/91.5/1.5 – –
DatasheetMechanical Drawing3D Model
28C5SCThrough HoleSingleProportional28 – 52.5 – – – –
DatasheetMechanical Drawing3D Model
28C5DCThrough HoleDualProportional28 – – – 5/51.25/1.25 – –
DatasheetMechanical Drawing3D Model
28C5.2SCThrough HoleSingleProportional28 – 5.22.5 – – – –
DatasheetMechanical Drawing3D Model
28C48SCThrough HoleSingleProportional28 – 484 – – – –
DatasheetMechanical Drawing3D Model
28C48DCThrough HoleDualProportional28 – – – 48/482/2 – –
DatasheetMechanical Drawing3D Model
28C3.3SCThrough HoleSingleProportional28 – 3.32.5 – – – –
DatasheetMechanical Drawing3D Model
28C28SCThrough HoleSingleProportional28 – 284 – – – –
DatasheetMechanical Drawing3D Model
28C28DCThrough HoleDualProportional28 – – – 28/282/2 – –
DatasheetMechanical Drawing3D Model
28C24SCThrough HoleSingleProportional28 – 244 – – – –
DatasheetMechanical Drawing3D Model
28C24DCThrough HoleDualProportional28 – – – 24/242/2 – –
DatasheetMechanical Drawing3D Model
28C15SCThrough HoleSingleProportional28 – 153.5 – – – –
DatasheetMechanical Drawing3D Model
28C15DCThrough HoleDualProportional28 – – – 15/151.75/1.75 – –
DatasheetMechanical Drawing3D Model
28C12SCThrough HoleSingleProportional28 – 123.5 – – – –
DatasheetMechanical Drawing3D Model
28C12DCThrough HoleDualProportional28 – – – 12/121.75/1.75 – –
DatasheetMechanical Drawing3D Model
28B9SBThrough HoleSingleProportional28 – 92 – – – –
DatasheetMechanical Drawing3D Model
28B9DBThrough HoleDualProportional28 – – – 9/91/1 – –
DatasheetMechanical Drawing3D Model
28B5SBThrough HoleSingleProportional28 – 51.5 – – – –
DatasheetMechanical Drawing3D Model
28B5DBThrough HoleDualProportional28 – – – 5/50.75/0.75 – –
DatasheetMechanical Drawing3D Model
28B5.2SBThrough HoleSingleProportional28 – 5.21.5 – – – –
DatasheetMechanical Drawing3D Model
28B48SBThrough HoleSingleProportional28 – 482.5 – – – –
DatasheetMechanical Drawing3D Model
28B48DBThrough HoleDualProportional28 – – – 48/481.25/1.25 – –
DatasheetMechanical Drawing3D Model
28B3.3SBThrough HoleSingleProportional28 – 3.31.5 – – – –
DatasheetMechanical Drawing3D Model
28B28SBThrough HoleSingleProportional28 – 282.5 – – – –
DatasheetMechanical Drawing3D Model
28B28DBThrough HoleDualProportional28 – – – 28/281.25/1.25 – –
DatasheetMechanical Drawing3D Model
28B24SBThrough HoleSingleProportional28 – 242.5 – – – –
DatasheetMechanical Drawing3D Model
28B24DBThrough HoleDualProportional28 – – – 24/241.25/1.25 – –
DatasheetMechanical Drawing3D Model
28B15SBThrough HoleSingleProportional28 – 152 – – – –
DatasheetMechanical Drawing3D Model
28B15DBThrough HoleDualProportional28 – – – 15/151/1 – –
DatasheetMechanical Drawing3D Model
28B12SBThrough HoleSingleProportional28 – 122 – – – –
DatasheetMechanical Drawing3D Model
28B12DBThrough HoleDualProportional28 – – – 12/121/1 – –
DatasheetMechanical Drawing3D Model
28AVR900AVRThrough HoleSingleRegulated2825 – 329001 – – – –
DatasheetMechanical Drawing3D Model
28AVR800AVRThrough HoleSingleRegulated2825 – 328001 – – – –
DatasheetMechanical Drawing3D Model
28AVR700AVRThrough HoleSingleRegulated2825 – 327001 – – – –
DatasheetMechanical Drawing3D Model
28AVR600AVRThrough HoleSingleRegulated2825 – 326001 – – – –
DatasheetMechanical Drawing3D Model
28AVR500AVRThrough HoleSingleRegulated2825 – 325001 – – – –
DatasheetMechanical Drawing3D Model
28AVR400AVRThrough HoleSingleRegulated2825 – 324001 – – – –
DatasheetMechanical Drawing3D Model
28AVR300AVRThrough HoleSingleRegulated2825 – 323001 – – – –
DatasheetMechanical Drawing3D Model
28AVR200AVRThrough HoleSingleRegulated2825 – 322001 – – – –
DatasheetMechanical Drawing3D Model
28AVR1000AVRThrough HoleSingleRegulated2825 – 3210001 – – – –
DatasheetMechanical Drawing3D Model
28AVR100AVRThrough HoleSingleRegulated2825 – 321001 – – – –
DatasheetMechanical Drawing3D Model
28AVP9KAV (1500-10kV)Through HoleSingleProportional28 – +90001.25 – – – –
DatasheetMechanical Drawing3D Model
28AVP8KAV (1500-10kV)Through HoleSingleProportional28 – +80001.25 – – – –
DatasheetMechanical Drawing3D Model
28AVP7KAV (1500-10kV)Through HoleSingleProportional28 – +70001.25 – – – –
DatasheetMechanical Drawing3D Model
28AVP6KAV (1500-10kV)Through HoleSingleProportional28 – +60001.25 – – – –
DatasheetMechanical Drawing3D Model
28AVP10KAV (1500-10kV)Through HoleSingleProportional28 – +100001.25 – – – –
DatasheetMechanical Drawing3D Model
28AVN9KAV (1500-10kV)Through HoleSingleProportional28 – -90001.25 – – – –
DatasheetMechanical Drawing3D Model
28AVN8KAV (1500-10kV)Through HoleSingleProportional28 – -80001.25 – – – –
DatasheetMechanical Drawing3D Model
28AVN7KAV (1500-10kV)Through HoleSingleProportional28 – -70001.25 – – – –
DatasheetMechanical Drawing3D Model
28AVN6KAV (1500-10kV)Through HoleSingleProportional28 – -60001.25 – – – –
DatasheetMechanical Drawing3D Model
28AVN10KAV (1500-10kV)Through HoleSingleProportional28 – -100001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV900AV (100-1kV)Through HoleSingleProportional28 – 9001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV800AV (100-1kV)Through HoleSingleProportional28 – 8001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV700AV (100-1kV)Through HoleSingleProportional28 – 7001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV600AV (100-1kV)Through HoleSingleProportional28 – 6001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV5000-PAV (1500-10kV)Through HoleSingleProportional28 – +50001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV5000-NAV (1500-10kV)Through HoleSingleProportional28 – -50001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV5000AV (1500-10kV)Through HoleSingleProportional28 – 50001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV500AV (100-1kV)Through HoleSingleProportional28 – 5001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV4500-PAV (1500-10kV)Through HoleSingleProportional28 – +45001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV4500-NAV (1500-10kV)Through HoleSingleProportional28 – -45001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV4500AV (1500-10kV)Through HoleSingleProportional28 – 45001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV450AV (100-1kV)Through HoleSingleProportional28 – 4501.25 – – – –
DatasheetMechanical Drawing3D Model
28AV4000-PAV (1500-10kV)Through HoleSingleProportional28 – +40001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV4000-NAV (1500-10kV)Through HoleSingleProportional28 – -40001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV4000AV (1500-10kV)Through HoleSingleProportional28 – 40001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV400AV (100-1kV)Through HoleSingleProportional28 – 4001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV3500-PAV (1500-10kV)Through HoleSingleProportional28 – +35001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV3500-NAV (1500-10kV)Through HoleSingleProportional28 – -35001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV3500AV (1500-10kV)Through HoleSingleProportional28 – 35001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV350AV (100-1kV)Through HoleSingleProportional28 – 3501.25 – – – –
DatasheetMechanical Drawing3D Model
28AV3000-PAV (1500-10kV)Through HoleSingleProportional28 – +30001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV3000-NAV (1500-10kV)Through HoleSingleProportional28 – -30001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV3000AV (1500-10kV)Through HoleSingleProportional28 – 30001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV300AV (100-1kV)Through HoleSingleProportional28 – 3001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV250DAV (100-1kV)Through HoleDualProportional28 – – – ±250±0.625 – –
DatasheetMechanical Drawing3D Model
28AV2500-PAV (1500-10kV)Through HoleSingleProportional28 – +25001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV2500-NAV (1500-10kV)Through HoleSingleProportional28 – -25001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV2500AV (1500-10kV)Through HoleSingleProportional28 – 25001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV250AV (100-1kV)Through HoleSingleProportional28 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
28AV200DAV (100-1kV)Through HoleDualProportional28 – – – ±200±0.625 – –
DatasheetMechanical Drawing3D Model
28AV2000-PAV (1500-10kV)Through HoleSingleProportional28 – +20001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV2000-NAV (1500-10kV)Through HoleSingleProportional28 – -20001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV2000AV (1500-10kV)Through HoleSingleProportional28 – 20001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV200AV (100-1kV)Through HoleSingleProportional28 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV150DAV (100-1kV)Through HoleDualProportional28 – – – ±150±0.625 – –
DatasheetMechanical Drawing3D Model
28AV1500-PAV (1500-10kV)Through HoleSingleProportional28 – +15001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV1500-NAV (1500-10kV)Through HoleSingleProportional28 – -15001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV1500AV (1500-10kV)Through HoleSingleProportional28 – 15001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV150AV (100-1kV)Through HoleSingleProportional28 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
28AV100DAV (100-1kV)Through HoleDualProportional28 – – – ±100±0.625 – –
DatasheetMechanical Drawing3D Model
28AV1000AV (100-1kV)Through HoleSingleProportional28 – 10001.25 – – – –
DatasheetMechanical Drawing3D Model
28AV100AV (100-1kV)Through HoleSingleProportional28 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
28A9SAThrough HoleSingleProportional28 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
28A9DAThrough HoleDualProportional28 – – – ±9±0.625 – –
DatasheetMechanical Drawing3D Model
28A5SAThrough HoleSingleProportional28 – 51 – – – –
DatasheetMechanical Drawing3D Model
28A5DAThrough HoleDualProportional28 – – – ±5±0.5 – –
DatasheetMechanical Drawing3D Model
28A5.2SAThrough HoleSingleProportional28 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
28A48SAThrough HoleSingleProportional28 – 481.25 – – – –
DatasheetMechanical Drawing3D Model
28A48DAThrough HoleDualProportional28 – – – ±48±0.625 – –
DatasheetMechanical Drawing3D Model
28A3.3SAThrough HoleSingleProportional28 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
28A28SAThrough HoleSingleProportional28 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
28A28DAThrough HoleDualProportional28 – – – ±28±0.625 – –
DatasheetMechanical Drawing3D Model
28A250SAThrough HoleSingleProportional28 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
28A24SAThrough HoleSingleProportional28 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
28A24DAThrough HoleDualProportional28 – – – ±24±0.625 – –
DatasheetMechanical Drawing3D Model
28A200SAThrough HoleSingleProportional28 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
28A15SAThrough HoleSingleProportional28 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
28A15DAThrough HoleDualProportional28 – – – ±15±0.625 – –
DatasheetMechanical Drawing3D Model
28A150SAThrough HoleSingleProportional28 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
28A12SAThrough HoleSingleProportional28 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
28A12DAThrough HoleDualProportional28 – – – ±12±0.625 – –
DatasheetMechanical Drawing3D Model
28A100SAThrough HoleSingleProportional28 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
24XSGR9SXSGRSurface MountSingleRegulated2421.6 – 26.493 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24XSGR9DXSGRSurface MountDualRegulated2421.6 – 26.4 – – 9/91.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24XSGR5SXSGRSurface MountSingleRegulated2421.6 – 26.452.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24XSGR5DXSGRSurface MountDualRegulated2421.6 – 26.4 – – 5/51.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
24XSGR3.3SXSGRSurface MountSingleRegulated2421.6 – 26.43.32 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24XSGR2SXSGRSurface MountSingleRegulated2421.6 – 26.421.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24XSGR15SXSGRSurface MountSingleRegulated2421.6 – 26.4154 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24XSGR15DXSGRSurface MountDualRegulated2421.6 – 26.4 – – 15/152/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
24XSGR12SXSGRSurface MountSingleRegulated2421.6 – 26.4124 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24XSGR12DXSGRSurface MountDualRegulated2421.6 – 26.4 – – 12/122/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
24XGR9SXGRThrough HoleSingleRegulated2421.6 – 26.493 – – – –
DatasheetMechanical Drawing3D Model
24XGR9DXGRThrough HoleDualRegulated2421.6 – 26.4 – – 9/91.5/1.5 – –
DatasheetMechanical Drawing3D Model
24XGR5SXGRThrough HoleSingleRegulated2421.6 – 26.452.5 – – – –
DatasheetMechanical Drawing3D Model
24XGR5DXGRThrough HoleDualRegulated2421.6 – 26.4 – – 5/51.25/1.25 – –
DatasheetMechanical Drawing3D Model
24XGR3.3SXGRThrough HoleSingleRegulated2421.6 – 26.43.32 – – – –
DatasheetMechanical Drawing3D Model
24XGR2SXGRThrough HoleSingleRegulated2421.6 – 26.421.5 – – – –
DatasheetMechanical Drawing3D Model
24XGR15SXGRThrough HoleSingleRegulated2421.6 – 26.4154 – – – –
DatasheetMechanical Drawing3D Model
24XGR15DXGRThrough HoleDualRegulated2421.6 – 26.4 – – 15/152/2 – –
DatasheetMechanical Drawing3D Model
24XGR12SXGRThrough HoleSingleRegulated2421.6 – 26.4124 – – – –
DatasheetMechanical Drawing3D Model
24XGR12DXGRThrough HoleDualRegulated2421.6 – 26.4 – – 12/122/2 – –
DatasheetMechanical Drawing3D Model
24VV9-PVV (100-10kV)Through HoleSingleProportional24 – +90006 – – – –
DatasheetMechanical Drawing3D Model
24VV9-NVV (100-10kV)Through HoleSingleProportional24 – -90006 – – – –
DatasheetMechanical Drawing3D Model
24VV9VV (100-10kV)Through HoleSingleProportional24 – 90006 – – – –
DatasheetMechanical Drawing3D Model
24VV8-PVV (100-10kV)Through HoleSingleProportional24 – +80006 – – – –
DatasheetMechanical Drawing3D Model
24VV8-NVV (100-10kV)Through HoleSingleProportional24 – -80006 – – – –
DatasheetMechanical Drawing3D Model
24VV8VV (100-10kV)Through HoleSingleProportional24 – 80006 – – – –
DatasheetMechanical Drawing3D Model
24VV7-PVV (100-10kV)Through HoleSingleProportional24 – +70006 – – – –
DatasheetMechanical Drawing3D Model
24VV7-NVV (100-10kV)Through HoleSingleProportional24 – -70006 – – – –
DatasheetMechanical Drawing3D Model
24VV7VV (100-10kV)Through HoleSingleProportional24 – 70006 – – – –
DatasheetMechanical Drawing3D Model
24VV6-PVV (100-10kV)Through HoleSingleProportional24 – +60006 – – – –
DatasheetMechanical Drawing3D Model
24VV6-NVV (100-10kV)Through HoleSingleProportional24 – -60006 – – – –
DatasheetMechanical Drawing3D Model
24VV6VV (100-10kV)Through HoleSingleProportional24 – 60006 – – – –
DatasheetMechanical Drawing3D Model
24VV500SVV (100-500V)Through HoleSingleProportional24 – 5004 – – – –
DatasheetMechanical Drawing3D Model
24VV5VV (100-10kV)Through HoleSingleProportional24 – 50006 – – – –
DatasheetMechanical Drawing3D Model
24VV400SVV (100-500V)Through HoleSingleProportional24 – 4004 – – – –
DatasheetMechanical Drawing3D Model
24VV4VV (100-10kV)Through HoleSingleProportional24 – 40008 – – – –
DatasheetMechanical Drawing3D Model
24VV300SVV (100-500V)Through HoleSingleProportional24 – 3004 – – – –
DatasheetMechanical Drawing3D Model
24VV3VV (100-10kV)Through HoleSingleProportional24 – 30009 – – – –
DatasheetMechanical Drawing3D Model
24VV200SVV (100-500V)Through HoleSingleProportional24 – 2004 – – – –
DatasheetMechanical Drawing3D Model
24VV2VV (100-10kV)Through HoleSingleProportional24 – 20009 – – – –
DatasheetMechanical Drawing3D Model
24VV100SVV (100-500V)Through HoleSingleProportional24 – 1004 – – – –
DatasheetMechanical Drawing3D Model
24VV10-PVV (100-10kV)Through HoleSingleProportional24 – +100006 – – – –
DatasheetMechanical Drawing3D Model
24VV10-NVV (100-10kV)Through HoleSingleProportional24 – -100006 – – – –
DatasheetMechanical Drawing3D Model
24VV10VV (100-10kV)Through HoleSingleProportional24 – 100006 – – – –
DatasheetMechanical Drawing3D Model
24VV1VV (100-10kV)Through HoleSingleProportional24 – 10009 – – – –
DatasheetMechanical Drawing3D Model
24VV0.9VV (100-10kV)Through HoleSingleProportional24 – 9009 – – – –
DatasheetMechanical Drawing3D Model
24VV0.8VV (100-10kV)Through HoleSingleProportional24 – 8009 – – – –
DatasheetMechanical Drawing3D Model
24VV0.7VV (100-10kV)Through HoleSingleProportional24 – 7009 – – – –
DatasheetMechanical Drawing3D Model
24VV0.6VV (100-10kV)Through HoleSingleProportional24 – 6009 – – – –
DatasheetMechanical Drawing3D Model
24VV0.5VV (100-10kV)Through HoleSingleProportional24 – 5009 – – – –
DatasheetMechanical Drawing3D Model
24VV0.4VV (100-10kV)Through HoleSingleProportional24 – 4009 – – – –
DatasheetMechanical Drawing3D Model
24VV0.3VV (100-10kV)Through HoleSingleProportional24 – 3009 – – – –
DatasheetMechanical Drawing3D Model
24VV0.2VV (100-10kV)Through HoleSingleProportional24 – 2009 – – – –
DatasheetMechanical Drawing3D Model
24VV0.1VV (100-10kV)Through HoleSingleProportional24 – 1009 – – – –
DatasheetMechanical Drawing3D Model
24SVV500SSVVSurface MountSingleProportional24 – 5004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SVV400SSVVSurface MountSingleProportional24 – 4004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SVV300SSVVSurface MountSingleProportional24 – 3004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SVV200SSVVSurface MountSingleProportional24 – 2004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SVV100SSVVSurface MountSingleProportional24 – 1004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV900SMVSurface MountSingleProportional24 – 9001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV800SMVSurface MountSingleProportional24 – 8001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV700SMVSurface MountSingleProportional24 – 7001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV600SMVSurface MountSingleProportional24 – 6001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV500SMVSurface MountSingleProportional24 – 5001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV450SMVSurface MountSingleProportional24 – 4501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV400SMVSurface MountSingleProportional24 – 4001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV350SMVSurface MountSingleProportional24 – 3501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV300SMVSurface MountSingleProportional24 – 3001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV250DSMVSurface MountDualProportional24 – – – ±250±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV250SMVSurface MountSingleProportional24 – 2501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV200DSMVSurface MountDualProportional24 – – – ±200±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV200SMVSurface MountSingleProportional24 – 2001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV150DSMVSurface MountDualProportional24 – – – ±150±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV150SMVSurface MountSingleProportional24 – 1501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV100DSMVSurface MountDualProportional24 – – – ±100±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV1000SMVSurface MountSingleProportional24 – 10001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SMV100SMVSurface MountSingleProportional24 – 1001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM9SSMSurface MountSingleProportional24 – 91.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM9DSMSurface MountDualProportional24 – – – ±9±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM5SSMSurface MountSingleProportional24 – 51 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM5DSMSurface MountDualProportional24 – – – ±5±0.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM5.2SSMSurface MountSingleProportional24 – 5.21 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM48SSMSurface MountSingleProportional24 – 481.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM48DSMSurface MountDualProportional24 – – – ±48±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM3.3SSMSurface MountSingleProportional24 – 3.31 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM28SSMSurface MountSingleProportional24 – 281.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM28DSMSurface MountDualProportional24 – – – ±28±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM250SSMSurface MountSingleProportional24 – 2501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM24SSMSurface MountSingleProportional24 – 241.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM24DSMSurface MountDualProportional24 – – – ±24±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM200SSMSurface MountSingleProportional24 – 2001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM15SSMSurface MountSingleProportional24 – 151.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM15DSMSurface MountDualProportional24 – – – ±15±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM150SSMSurface MountSingleProportional24 – 1501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM12SSMSurface MountSingleProportional24 – 121.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM12DSMSurface MountDualProportional24 – – – ±12±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SM100SSMSurface MountSingleProportional24 – 1001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SFR5SSFRSurface MountSingleRegulated2421.6 – 26.450.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SFR5DSFRSurface MountDualRegulated2421.6 – 26.4 – – 5/50.25/0.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SFR15SSFRSurface MountSingleRegulated2421.6 – 26.4151 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SFR15DSFRSurface MountDualRegulated2421.6 – 26.4 – – 15/150.35/0.35 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SFR12SSFRSurface MountSingleRegulated2421.6 – 26.4121 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SFR12DSFRSurface MountDualRegulated2421.6 – 26.4 – – 12/120.35/0.35 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE9SSESurface MountSingleProportional24 – 96 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE9DSESurface MountDualProportional24 – – – 9/93/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE5SSESurface MountSingleProportional24 – 54 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE5DSESurface MountDualProportional24 – – – 5/52/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE5.2SSESurface MountSingleProportional24 – 5.24 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE48SSESurface MountSingleProportional24 – 487 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE48DSESurface MountDualProportional24 – – – 48/483.5/3.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE3.3SSESurface MountSingleProportional24 – 3.33.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE28SSESurface MountSingleProportional24 – 287 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE28DSESurface MountDualProportional24 – – – 28/283.5/3.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE24SSESurface MountSingleProportional24 – 247 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE24DSESurface MountDualProportional24 – – – 24/243.5/3.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE15SSESurface MountSingleProportional24 – 156.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE15DSESurface MountDualProportional24 – – – 15/153.25/3.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE12SSESurface MountSingleProportional24 – 126.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SE12DSESurface MountDualProportional24 – – – 12/123.25/3.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC9SSCSurface MountSingleProportional24 – 93 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC9DSCSurface MountDualProportional24 – – – 9/91.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC5SSCSurface MountSingleProportional24 – 52.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC5DSCSurface MountDualProportional24 – – – 5/51.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC5.2SSCSurface MountSingleProportional24 – 5.22.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC48SSCSurface MountSingleProportional24 – 484 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC48DSCSurface MountDualProportional24 – – – 48/482/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC3.3SSCSurface MountSingleProportional24 – 3.32.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC28SSCSurface MountSingleProportional24 – 284 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC28DSCSurface MountDualProportional24 – – – 28/282/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC24SSCSurface MountSingleProportional24 – 244 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC24DSCSurface MountDualProportional24 – – – 24/242/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC15SSCSurface MountSingleProportional24 – 153.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC15DSCSurface MountDualProportional24 – – – 15/151.75/1.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC12SSCSurface MountSingleProportional24 – 123.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SC12DSCSurface MountDualProportional24 – – – 12/121.75/1.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB9SSBSurface MountSingleProportional24 – 92 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB9DSBSurface MountDualProportional24 – – – 9/91/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB5SSBSurface MountSingleProportional24 – 51.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB5DSBSurface MountDualProportional24 – – – 5/50.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB5.2SSBSurface MountSingleProportional24 – 5.21.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB48SSBSurface MountSingleProportional24 – 482.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB48DSBSurface MountDualProportional24 – – – 48/481.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB3.3SSBSurface MountSingleProportional24 – 3.31.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB28SSBSurface MountSingleProportional24 – 282.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB28DSBSurface MountDualProportional24 – – – 28/281.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB24SSBSurface MountSingleProportional24 – 242.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB24DSBSurface MountDualProportional24 – – – 24/241.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB15SSBSurface MountSingleProportional24 – 152 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB15DSBSurface MountDualProportional24 – – – 15/151/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB12SSBSurface MountSingleProportional24 – 122 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SB12DSBSurface MountDualProportional24 – – – 12/121/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SAR500SMSAR-SMSurface MountSingleRegulated Programmable2418 – 365003±250±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SAR500SARThrough HoleSingleRegulated Programmable2418 – 365003±250±1.5 – –
DatasheetMechanical Drawing3D Model
24SAR250SMSAR-SMSurface MountSingleRegulated Programmable2418 – 362503±125±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SAR250SARThrough HoleSingleRegulated Programmable2418 – 362503±125±1.5 – –
DatasheetMechanical Drawing3D Model
24SAR1500SMSAR-SMSurface MountSingleRegulated Programmable2418 – 3615003±750±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SAR1500SARThrough HoleSingleRegulated Programmable2418 – 3615003±750±1.5 – –
DatasheetMechanical Drawing3D Model
24SAR100SMSAR-SMSurface MountSingleRegulated Programmable2418 – 361003±50±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SAR1000SMSAR-SMSurface MountSingleRegulated Programmable2418 – 3610003±500±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
24SAR1000SARThrough HoleSingleRegulated Programmable2418 – 3610003±500±1.5 – –
DatasheetMechanical Drawing3D Model
24SAR100SARThrough HoleSingleRegulated Programmable2418 – 361003±50±1.5 – –
DatasheetMechanical Drawing3D Model
24SA900SMSA-SMSurface MountSingleProportional24 – 9003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA900SAThrough HoleSingleProportional24 – 9003 – – – –
DatasheetMechanical Drawing3D Model
24SA800SMSA-SMSurface MountSingleProportional24 – 8003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA800SAThrough HoleSingleProportional24 – 8003 – – – –
DatasheetMechanical Drawing3D Model
24SA700SMSA-SMSurface MountSingleProportional24 – 7003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA700SAThrough HoleSingleProportional24 – 7003 – – – –
DatasheetMechanical Drawing3D Model
24SA600SMSA-SMSurface MountSingleProportional24 – 6003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA600SAThrough HoleSingleProportional24 – 6003 – – – –
DatasheetMechanical Drawing3D Model
24SA500SMSA-SMSurface MountSingleProportional24 – 5003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA500SAThrough HoleSingleProportional24 – 5003 – – – –
DatasheetMechanical Drawing3D Model
24SA450SMSA-SMSurface MountSingleProportional24 – 4503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA450SAThrough HoleSingleProportional24 – 4503 – – – –
DatasheetMechanical Drawing3D Model
24SA400SMSA-SMSurface MountSingleProportional24 – 4003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA400SAThrough HoleSingleProportional24 – 4003 – – – –
DatasheetMechanical Drawing3D Model
24SA350SMSA-SMSurface MountSingleProportional24 – 3503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA350SAThrough HoleSingleProportional24 – 3503 – – – –
DatasheetMechanical Drawing3D Model
24SA300SMSA-SMSurface MountSingleProportional24 – 3003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA300SAThrough HoleSingleProportional24 – 3003 – – – –
DatasheetMechanical Drawing3D Model
24SA250SMSA-SMSurface MountSingleProportional24 – 2503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA250SAThrough HoleSingleProportional24 – 2503 – – – –
DatasheetMechanical Drawing3D Model
24SA200SMSA-SMSurface MountSingleProportional24 – 2003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA200SAThrough HoleSingleProportional24 – 2003 – – – –
DatasheetMechanical Drawing3D Model
24SA150SMSA-SMSurface MountSingleProportional24 – 1503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA150SAThrough HoleSingleProportional24 – 1503 – – – –
DatasheetMechanical Drawing3D Model
24SA100SMSA-SMSurface MountSingleProportional24 – 1003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA1000SMSA-SMSurface MountSingleProportional24 – 10003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
24SA1000SAThrough HoleSingleProportional24 – 10003 – – – –
DatasheetMechanical Drawing3D Model
24SA100SAThrough HoleSingleProportional24 – 1003 – – – –
DatasheetMechanical Drawing3D Model
24MV500MVThrough HoleSingleProportional24 – 5001.25 – – – –
DatasheetMechanical Drawing3D Model
24MV450MVThrough HoleSingleProportional24 – 4501.25 – – – –
DatasheetMechanical Drawing3D Model
24MV400MVThrough HoleSingleProportional24 – 4001.25 – – – –
DatasheetMechanical Drawing3D Model
24MV350MVThrough HoleSingleProportional24 – 3501.25 – – – –
DatasheetMechanical Drawing3D Model
24MV300MVThrough HoleSingleProportional24 – 3001.25 – – – –
DatasheetMechanical Drawing3D Model
24MV250MVThrough HoleSingleProportional24 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
24MV200MVThrough HoleSingleProportional24 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
24MV150MVThrough HoleSingleProportional24 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
24MV100MVThrough HoleSingleProportional24 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
24M9SMThrough HoleSingleProportional24 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
24M9DMThrough HoleDualProportional24 – – – 9/90.625/0.625 – –
DatasheetMechanical Drawing3D Model
24M5SMThrough HoleSingleProportional24 – 51 – – – –
DatasheetMechanical Drawing3D Model
24M5DMThrough HoleDualProportional24 – – – 5/50.5/0.5 – –
DatasheetMechanical Drawing3D Model
24M5.2SMThrough HoleSingleProportional24 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
24M48SMThrough HoleSingleProportional24 – 481.25 – – – –
DatasheetMechanical Drawing3D Model
24M48DMThrough HoleDualProportional24 – – – 48/480.625/0.625 – –
DatasheetMechanical Drawing3D Model
24M3.3SMThrough HoleSingleProportional24 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
24M28SMThrough HoleSingleProportional24 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
24M28DMThrough HoleDualProportional24 – – – 28/280.625/0.625 – –
DatasheetMechanical Drawing3D Model
24M24SMThrough HoleSingleProportional24 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
24M24DMThrough HoleDualProportional24 – – – 24/240.625/0.625 – –
DatasheetMechanical Drawing3D Model
24M15SMThrough HoleSingleProportional24 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
24M15DMThrough HoleDualProportional24 – – – 15/150.625/0.625 – –
DatasheetMechanical Drawing3D Model
24M12SMThrough HoleSingleProportional24 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
24M12DMThrough HoleDualProportional24 – – – 12/120.625/0.625 – –
DatasheetMechanical Drawing3D Model
24FR5SFRThrough HoleSingleRegulated2421.6 – 26.450.75 – – – –
DatasheetMechanical Drawing3D Model
24FR5DFRThrough HoleDualRegulated2421.6 – 26.4 – – 5/50.25/0.25 – –
DatasheetMechanical Drawing3D Model
24FR15SFRThrough HoleSingleRegulated2421.6 – 26.4151 – – – –
DatasheetMechanical Drawing3D Model
24FR15DFRThrough HoleDualRegulated2421.6 – 26.4 – – 15/150.35/0.35 – –
DatasheetMechanical Drawing3D Model
24FR12SFRThrough HoleSingleRegulated2421.6 – 26.4121 – – – –
DatasheetMechanical Drawing3D Model
24FR12DFRThrough HoleDualRegulated2421.6 – 26.4 – – 12/120.35/0.35 – –
DatasheetMechanical Drawing3D Model
24E9SEThrough HoleSingleProportional24 – 96 – – – –
DatasheetMechanical Drawing3D Model
24E9DEThrough HoleDualProportional24 – – – 9/93/3 – –
DatasheetMechanical Drawing3D Model
24E5SEThrough HoleSingleProportional24 – 54 – – – –
DatasheetMechanical Drawing3D Model
24E5DEThrough HoleDualProportional24 – – – 5/52/2 – –
DatasheetMechanical Drawing3D Model
24E5.2SEThrough HoleSingleProportional24 – 5.24 – – – –
DatasheetMechanical Drawing3D Model
24E48SEThrough HoleSingleProportional24 – 487 – – – –
DatasheetMechanical Drawing3D Model
24E48DEThrough HoleDualProportional24 – – – 48/483.5/3.5 – –
DatasheetMechanical Drawing3D Model
24E3.3SEThrough HoleSingleProportional24 – 3.33.5 – – – –
DatasheetMechanical Drawing3D Model
24E28SEThrough HoleSingleProportional24 – 287 – – – –
DatasheetMechanical Drawing3D Model
24E28DEThrough HoleDualProportional24 – – – 28/283.5/3.5 – –
DatasheetMechanical Drawing3D Model
24E24SEThrough HoleSingleProportional24 – 247 – – – –
DatasheetMechanical Drawing3D Model
24E24DEThrough HoleDualProportional24 – – – 24/243.5/3.5 – –
DatasheetMechanical Drawing3D Model
24E15SEThrough HoleSingleProportional24 – 156.5 – – – –
DatasheetMechanical Drawing3D Model
24E15DEThrough HoleDualProportional24 – – – 15/153.25/3.25 – –
DatasheetMechanical Drawing3D Model
24E12SEThrough HoleSingleProportional24 – 126.5 – – – –
DatasheetMechanical Drawing3D Model
24E12DEThrough HoleDualProportional24 – – – 12/123.25/3.25 – –
DatasheetMechanical Drawing3D Model
24C9SCThrough HoleSingleProportional24 – 93 – – – –
DatasheetMechanical Drawing3D Model
24C9DCThrough HoleDualProportional24 – – – 9/91.5/1.5 – –
DatasheetMechanical Drawing3D Model
24C5SCThrough HoleSingleProportional24 – 52.5 – – – –
DatasheetMechanical Drawing3D Model
24C5DCThrough HoleDualProportional24 – – – 5/51.25/1.25 – –
DatasheetMechanical Drawing3D Model
24C5.2SCThrough HoleSingleProportional24 – 5.22.5 – – – –
DatasheetMechanical Drawing3D Model
24C48SCThrough HoleSingleProportional24 – 484 – – – –
DatasheetMechanical Drawing3D Model
24C48DCThrough HoleDualProportional24 – – – 48/482/2 – –
DatasheetMechanical Drawing3D Model
24C3.3SCThrough HoleSingleProportional24 – 3.32.5 – – – –
DatasheetMechanical Drawing3D Model
24C28SCThrough HoleSingleProportional24 – 284 – – – –
DatasheetMechanical Drawing3D Model
24C28DCThrough HoleDualProportional24 – – – 28/282/2 – –
DatasheetMechanical Drawing3D Model
24C24SCThrough HoleSingleProportional24 – 244 – – – –
DatasheetMechanical Drawing3D Model
24C24DCThrough HoleDualProportional24 – – – 24/242/2 – –
DatasheetMechanical Drawing3D Model
24C15SCThrough HoleSingleProportional24 – 153.5 – – – –
DatasheetMechanical Drawing3D Model
24C15DCThrough HoleDualProportional24 – – – 15/151.75/1.75 – –
DatasheetMechanical Drawing3D Model
24C12SCThrough HoleSingleProportional24 – 123.5 – – – –
DatasheetMechanical Drawing3D Model
24C12DCThrough HoleDualProportional24 – – – 12/121.75/1.75 – –
DatasheetMechanical Drawing3D Model
24B9SBThrough HoleSingleProportional24 – 92 – – – –
DatasheetMechanical Drawing3D Model
24B9DBThrough HoleDualProportional24 – – – 9/91/1 – –
DatasheetMechanical Drawing3D Model
24B5SBThrough HoleSingleProportional24 – 51.5 – – – –
DatasheetMechanical Drawing3D Model
24B5DBThrough HoleDualProportional24 – – – 5/50.75/0.75 – –
DatasheetMechanical Drawing3D Model
24B5.2SBThrough HoleSingleProportional24 – 5.21.5 – – – –
DatasheetMechanical Drawing3D Model
24B48SBThrough HoleSingleProportional24 – 482.5 – – – –
DatasheetMechanical Drawing3D Model
24B48DBThrough HoleDualProportional24 – – – 48/481.25/1.25 – –
DatasheetMechanical Drawing3D Model
24B3.3SBThrough HoleSingleProportional24 – 3.31.5 – – – –
DatasheetMechanical Drawing3D Model
24B28SBThrough HoleSingleProportional24 – 282.5 – – – –
DatasheetMechanical Drawing3D Model
24B28DBThrough HoleDualProportional24 – – – 28/281.25/1.25 – –
DatasheetMechanical Drawing3D Model
24B24SBThrough HoleSingleProportional24 – 242.5 – – – –
DatasheetMechanical Drawing3D Model
24B24DBThrough HoleDualProportional24 – – – 24/241.25/1.25 – –
DatasheetMechanical Drawing3D Model
24B15SBThrough HoleSingleProportional24 – 152 – – – –
DatasheetMechanical Drawing3D Model
24B15DBThrough HoleDualProportional24 – – – 15/151/1 – –
DatasheetMechanical Drawing3D Model
24B12SBThrough HoleSingleProportional24 – 122 – – – –
DatasheetMechanical Drawing3D Model
24B12DBThrough HoleDualProportional24 – – – 12/121/1 – –
DatasheetMechanical Drawing3D Model
24AVR900AVRThrough HoleSingleRegulated2421 – 279001 – – – –
DatasheetMechanical Drawing3D Model
24AVR800AVRThrough HoleSingleRegulated2421 – 278001 – – – –
DatasheetMechanical Drawing3D Model
24AVR700AVRThrough HoleSingleRegulated2421 – 277001 – – – –
DatasheetMechanical Drawing3D Model
24AVR600AVRThrough HoleSingleRegulated2421 – 276001 – – – –
DatasheetMechanical Drawing3D Model
24AVR500AVRThrough HoleSingleRegulated2421 – 275001 – – – –
DatasheetMechanical Drawing3D Model
24AVR400AVRThrough HoleSingleRegulated2421 – 274001 – – – –
DatasheetMechanical Drawing3D Model
24AVR300AVRThrough HoleSingleRegulated2421 – 273001 – – – –
DatasheetMechanical Drawing3D Model
24AVR200AVRThrough HoleSingleRegulated2421 – 272001 – – – –
DatasheetMechanical Drawing3D Model
24AVR1000AVRThrough HoleSingleRegulated2421 – 2710001 – – – –
DatasheetMechanical Drawing3D Model
24AVR100AVRThrough HoleSingleRegulated2421 – 271001 – – – –
DatasheetMechanical Drawing3D Model
24AVP9KAV (1500-10kV)Through HoleSingleProportional24 – +90001.25 – – – –
DatasheetMechanical Drawing3D Model
24AVP8KAV (1500-10kV)Through HoleSingleProportional24 – +80001.25 – – – –
DatasheetMechanical Drawing3D Model
24AVP7KAV (1500-10kV)Through HoleSingleProportional24 – +70001.25 – – – –
DatasheetMechanical Drawing3D Model
24AVP6KAV (1500-10kV)Through HoleSingleProportional24 – +60001.25 – – – –
DatasheetMechanical Drawing3D Model
24AVP10KAV (1500-10kV)Through HoleSingleProportional24 – +100001.25 – – – –
DatasheetMechanical Drawing3D Model
24AVN9KAV (1500-10kV)Through HoleSingleProportional24 – -90001.25 – – – –
DatasheetMechanical Drawing3D Model
24AVN8KAV (1500-10kV)Through HoleSingleProportional24 – -80001.25 – – – –
DatasheetMechanical Drawing3D Model
24AVN7KAV (1500-10kV)Through HoleSingleProportional24 – -70001.25 – – – –
DatasheetMechanical Drawing3D Model
24AVN6KAV (1500-10kV)Through HoleSingleProportional24 – -60001.25 – – – –
DatasheetMechanical Drawing3D Model
24AVN10KAV (1500-10kV)Through HoleSingleProportional24 – -100001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV900AV (100-1kV)Through HoleSingleProportional24 – 9001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV800AV (100-1kV)Through HoleSingleProportional24 – 8001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV700AV (100-1kV)Through HoleSingleProportional24 – 7001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV600AV (100-1kV)Through HoleSingleProportional24 – 6001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV5000-PAV (1500-10kV)Through HoleSingleProportional24 – +50001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV5000-NAV (1500-10kV)Through HoleSingleProportional24 – -50001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV5000AV (1500-10kV)Through HoleSingleProportional24 – 50001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV500AV (100-1kV)Through HoleSingleProportional24 – 5001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV4500-PAV (1500-10kV)Through HoleSingleProportional24 – +45001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV4500-NAV (1500-10kV)Through HoleSingleProportional24 – -45001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV4500AV (1500-10kV)Through HoleSingleProportional24 – 45001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV450AV (100-1kV)Through HoleSingleProportional24 – 4501.25 – – – –
DatasheetMechanical Drawing3D Model
24AV4000-PAV (1500-10kV)Through HoleSingleProportional24 – +40001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV4000-NAV (1500-10kV)Through HoleSingleProportional24 – -40001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV4000AV (1500-10kV)Through HoleSingleProportional24 – 40001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV400AV (100-1kV)Through HoleSingleProportional24 – 4001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV3500-PAV (1500-10kV)Through HoleSingleProportional24 – +35001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV3500-NAV (1500-10kV)Through HoleSingleProportional24 – -35001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV3500AV (1500-10kV)Through HoleSingleProportional24 – 35001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV350AV (100-1kV)Through HoleSingleProportional24 – 3501.25 – – – –
DatasheetMechanical Drawing3D Model
24AV3000-PAV (1500-10kV)Through HoleSingleProportional24 – +30001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV3000-NAV (1500-10kV)Through HoleSingleProportional24 – -30001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV3000AV (1500-10kV)Through HoleSingleProportional24 – 30001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV300AV (100-1kV)Through HoleSingleProportional24 – 3001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV250DAV (100-1kV)Through HoleDualProportional24 – – – ±250±0.625 – –
DatasheetMechanical Drawing3D Model
24AV2500-PAV (1500-10kV)Through HoleSingleProportional24 – +25001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV2500-NAV (1500-10kV)Through HoleSingleProportional24 – -25001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV2500AV (1500-10kV)Through HoleSingleProportional24 – 25001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV250AV (100-1kV)Through HoleSingleProportional24 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
24AV200DAV (100-1kV)Through HoleDualProportional24 – – – ±200±0.625 – –
DatasheetMechanical Drawing3D Model
24AV2000-PAV (1500-10kV)Through HoleSingleProportional24 – +20001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV2000-NAV (1500-10kV)Through HoleSingleProportional24 – -20001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV2000AV (1500-10kV)Through HoleSingleProportional24 – 20001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV200AV (100-1kV)Through HoleSingleProportional24 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV150DAV (100-1kV)Through HoleDualProportional24 – – – ±150±0.625 – –
DatasheetMechanical Drawing3D Model
24AV1500-PAV (1500-10kV)Through HoleSingleProportional24 – +15001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV1500-NAV (1500-10kV)Through HoleSingleProportional24 – -15001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV1500AV (1500-10kV)Through HoleSingleProportional24 – 15001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV150AV (100-1kV)Through HoleSingleProportional24 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
24AV100DAV (100-1kV)Through HoleDualProportional24 – – – ±100±0.625 – –
DatasheetMechanical Drawing3D Model
24AV1000AV (100-1kV)Through HoleSingleProportional24 – 10001.25 – – – –
DatasheetMechanical Drawing3D Model
24AV100AV (100-1kV)Through HoleSingleProportional24 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
24A9SAThrough HoleSingleProportional24 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
24A9DAThrough HoleDualProportional24 – – – ±9±0.625 – –
DatasheetMechanical Drawing3D Model
24A5SAThrough HoleSingleProportional24 – 51 – – – –
DatasheetMechanical Drawing3D Model
24A5DAThrough HoleDualProportional24 – – – ±5±0.5 – –
DatasheetMechanical Drawing3D Model
24A5.2SAThrough HoleSingleProportional24 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
24A48SAThrough HoleSingleProportional24 – 481.25 – – – –
DatasheetMechanical Drawing3D Model
24A48DAThrough HoleDualProportional24 – – – ±48±0.625 – –
DatasheetMechanical Drawing3D Model
24A3.3SAThrough HoleSingleProportional24 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
24A28SAThrough HoleSingleProportional24 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
24A28DAThrough HoleDualProportional24 – – – ±28±0.625 – –
DatasheetMechanical Drawing3D Model
24A250SAThrough HoleSingleProportional24 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
24A24SAThrough HoleSingleProportional24 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
24A24DAThrough HoleDualProportional24 – – – ±24±0.625 – –
DatasheetMechanical Drawing3D Model
24A200SAThrough HoleSingleProportional24 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
24A15SAThrough HoleSingleProportional24 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
24A15DAThrough HoleDualProportional24 – – – ±15±0.625 – –
DatasheetMechanical Drawing3D Model
24A150SAThrough HoleSingleProportional24 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
24A12SAThrough HoleSingleProportional24 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
24A12DAThrough HoleDualProportional24 – – – ±12±0.625 – –
DatasheetMechanical Drawing3D Model
24A100SAThrough HoleSingleProportional24 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
15XSGR9SXSGRSurface MountSingleRegulated1513.5 – 16.593 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15XSGR9DXSGRSurface MountDualRegulated1513.5 – 16.5 – – 9/91.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
15XSGR5SXSGRSurface MountSingleRegulated1513.5 – 16.552 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15XSGR5DXSGRSurface MountDualRegulated1513.5 – 16.5 – – 5/51/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
15XSGR3.3SXSGRSurface MountSingleRegulated1513.5 – 16.53.32 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15XSGR2SXSGRSurface MountSingleRegulated1513.5 – 16.521.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15XSGR15SXSGRSurface MountSingleRegulated1513.5 – 16.5154 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15XSGR15DXSGRSurface MountDualRegulated1513.5 – 16.5 – – 15/152/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
15XSGR12SXSGRSurface MountSingleRegulated1513.5 – 16.5124 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15XSGR12DXSGRSurface MountDualRegulated1513.5 – 16.5 – – 12/122/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
15XGR9SXGRThrough HoleSingleRegulated1513.5 – 16.593 – – – –
DatasheetMechanical Drawing3D Model
15XGR9DXGRThrough HoleDualRegulated1513.5 – 16.5 – – 9/91.5/1.5 – –
DatasheetMechanical Drawing3D Model
15XGR5SXGRThrough HoleSingleRegulated1513.5 – 16.552 – – – –
DatasheetMechanical Drawing3D Model
15XGR5DXGRThrough HoleDualRegulated1513.5 – 16.5 – – 5/51/1 – –
DatasheetMechanical Drawing3D Model
15XGR3.3SXGRThrough HoleSingleRegulated1513.5 – 16.53.32 – – – –
DatasheetMechanical Drawing3D Model
15XGR2SXGRThrough HoleSingleRegulated1513.5 – 16.521.5 – – – –
DatasheetMechanical Drawing3D Model
15XGR15SXGRThrough HoleSingleRegulated1513.5 – 16.5154 – – – –
DatasheetMechanical Drawing3D Model
15XGR15DXGRThrough HoleDualRegulated1513.5 – 16.5 – – 15/152/2 – –
DatasheetMechanical Drawing3D Model
15XGR12SXGRThrough HoleSingleRegulated1513.5 – 16.5124 – – – –
DatasheetMechanical Drawing3D Model
15XGR12DXGRThrough HoleDualRegulated1513.5 – 16.5 – – 12/122/2 – –
DatasheetMechanical Drawing3D Model
15VV9-PVV (100-10kV)Through HoleSingleProportional15 – +90006 – – – –
DatasheetMechanical Drawing3D Model
15VV9-NVV (100-10kV)Through HoleSingleProportional15 – -90006 – – – –
DatasheetMechanical Drawing3D Model
15VV9VV (100-10kV)Through HoleSingleProportional15 – 90006 – – – –
DatasheetMechanical Drawing3D Model
15VV8-PVV (100-10kV)Through HoleSingleProportional15 – +80006 – – – –
DatasheetMechanical Drawing3D Model
15VV8-NVV (100-10kV)Through HoleSingleProportional15 – -80006 – – – –
DatasheetMechanical Drawing3D Model
15VV8VV (100-10kV)Through HoleSingleProportional15 – 80006 – – – –
DatasheetMechanical Drawing3D Model
15VV7-PVV (100-10kV)Through HoleSingleProportional15 – +70006 – – – –
DatasheetMechanical Drawing3D Model
15VV7-NVV (100-10kV)Through HoleSingleProportional15 – -70006 – – – –
DatasheetMechanical Drawing3D Model
15VV7VV (100-10kV)Through HoleSingleProportional15 – 70006 – – – –
DatasheetMechanical Drawing3D Model
15VV6-PVV (100-10kV)Through HoleSingleProportional15 – +60006 – – – –
DatasheetMechanical Drawing3D Model
15VV6-NVV (100-10kV)Through HoleSingleProportional15 – -60006 – – – –
DatasheetMechanical Drawing3D Model
15VV6VV (100-10kV)Through HoleSingleProportional15 – 60006 – – – –
DatasheetMechanical Drawing3D Model
15VV5VV (100-10kV)Through HoleSingleProportional15 – 50006 – – – –
DatasheetMechanical Drawing3D Model
15VV4VV (100-10kV)Through HoleSingleProportional15 – 40007 – – – –
DatasheetMechanical Drawing3D Model
15VV3VV (100-10kV)Through HoleSingleProportional15 – 30008 – – – –
DatasheetMechanical Drawing3D Model
15VV2VV (100-10kV)Through HoleSingleProportional15 – 20008.5 – – – –
DatasheetMechanical Drawing3D Model
15VV10-PVV (100-10kV)Through HoleSingleProportional15 – +100006 – – – –
DatasheetMechanical Drawing3D Model
15VV10-NVV (100-10kV)Through HoleSingleProportional15 – -100006 – – – –
DatasheetMechanical Drawing3D Model
15VV10VV (100-10kV)Through HoleSingleProportional15 – 100006 – – – –
DatasheetMechanical Drawing3D Model
15VV1VV (100-10kV)Through HoleSingleProportional15 – 10008.5 – – – –
DatasheetMechanical Drawing3D Model
15VV0.9VV (100-10kV)Through HoleSingleProportional15 – 9008.5 – – – –
DatasheetMechanical Drawing3D Model
15VV0.8VV (100-10kV)Through HoleSingleProportional15 – 8008.5 – – – –
DatasheetMechanical Drawing3D Model
15VV0.7VV (100-10kV)Through HoleSingleProportional15 – 7008.5 – – – –
DatasheetMechanical Drawing3D Model
15VV0.6VV (100-10kV)Through HoleSingleProportional15 – 6008.5 – – – –
DatasheetMechanical Drawing3D Model
15VV0.5VV (100-10kV)Through HoleSingleProportional15 – 5008.5 – – – –
DatasheetMechanical Drawing3D Model
15VV0.4VV (100-10kV)Through HoleSingleProportional15 – 4008.5 – – – –
DatasheetMechanical Drawing3D Model
15VV0.3VV (100-10kV)Through HoleSingleProportional15 – 3008.5 – – – –
DatasheetMechanical Drawing3D Model
15VV0.2VV (100-10kV)Through HoleSingleProportional15 – 2008.5 – – – –
DatasheetMechanical Drawing3D Model
15VV0.1VV (100-10kV)Through HoleSingleProportional15 – 1008.5 – – – –
DatasheetMechanical Drawing3D Model
15SMV900SMVSurface MountSingleProportional15 – 9001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV800SMVSurface MountSingleProportional15 – 8001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV700SMVSurface MountSingleProportional15 – 7001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV600SMVSurface MountSingleProportional15 – 6001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV500SMVSurface MountSingleProportional15 – 5001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV450SMVSurface MountSingleProportional15 – 4501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV400SMVSurface MountSingleProportional15 – 4001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV350SMVSurface MountSingleProportional15 – 3501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV300SMVSurface MountSingleProportional15 – 3001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV250DSMVSurface MountDualProportional15 – – – ±250±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV250SMVSurface MountSingleProportional15 – 2501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV200DSMVSurface MountDualProportional15 – – – ±200±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV200SMVSurface MountSingleProportional15 – 2001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV150DSMVSurface MountDualProportional15 – – – ±150±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV150SMVSurface MountSingleProportional15 – 1501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV100DSMVSurface MountDualProportional15 – – – ±100±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV1000SMVSurface MountSingleProportional15 – 10001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SMV100SMVSurface MountSingleProportional15 – 1001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM9SSMSurface MountSingleProportional15 – 91.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM9DSMSurface MountDualProportional15 – – – ±9±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM5SSMSurface MountSingleProportional15 – 51 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM5DSMSurface MountDualProportional15 – – – ±5±0.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM5.2SSMSurface MountSingleProportional15 – 5.21 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM48SSMSurface MountSingleProportional15 – 481.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM48DSMSurface MountDualProportional15 – – – ±48±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM3.3SSMSurface MountSingleProportional15 – 3.31 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM28SSMSurface MountSingleProportional15 – 281.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM28DSMSurface MountDualProportional15 – – – ±28±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM250SSMThrough HoleSingleProportional15 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
15SM24SSMSurface MountSingleProportional15 – 241.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM24DSMSurface MountDualProportional15 – – – ±24±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM200SSMThrough HoleSingleProportional15 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
15SM15SSMSurface MountSingleProportional15 – 151.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM15DSMSurface MountDualProportional15 – – – ±15±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM150SSMThrough HoleSingleProportional15 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
15SM12SSMSurface MountSingleProportional15 – 121.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM12DSMSurface MountDualProportional15 – – – ±12±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SM100SSMThrough HoleSingleProportional15 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
15SFR5SSFRSurface MountSingleRegulated1513.5 – 16.550.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SFR5DSFRSurface MountDualRegulated1513.5 – 16.5 – – 5/50.25/0.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SFR15SSFRSurface MountSingleRegulated1513.5 – 16.5151 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SFR15DSFRSurface MountDualRegulated1513.5 – 16.5 – – 15/150.35/0.35 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SFR12SSFRSurface MountSingleRegulated1513.5 – 16.5121 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SFR12DSFRSurface MountDualRegulated1513.5 – 16.5 – – 12/120.35/0.35 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE9SSESurface MountSingleProportional15 – 96 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE9DSESurface MountDualProportional15 – – – 9/93/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE5SSESurface MountSingleProportional15 – 54 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE5DSESurface MountDualProportional15 – – – 5/52/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE5.2SSESurface MountSingleProportional15 – 5.24 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE48SSESurface MountSingleProportional15 – 486.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE48DSESurface MountDualProportional15 – – – 48/483.375/3.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE3.3SSESurface MountSingleProportional15 – 3.33.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE28SSESurface MountSingleProportional15 – 286.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE28DSESurface MountDualProportional15 – – – 28/283.375/3.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE24SSESurface MountSingleProportional15 – 246.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE24DSESurface MountDualProportional15 – – – 24/243.375/3.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE15SSESurface MountSingleProportional15 – 156.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE15DSESurface MountDualProportional15 – – – 15/153.25/3.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE12SSESurface MountSingleProportional15 – 126.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SE12DSESurface MountDualProportional15 – – – 15/153.25/3.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC9SSCSurface MountSingleProportional15 – 93 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC9DSCSurface MountDualProportional15 – – – 9/91.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC5SSCSurface MountSingleProportional15 – 52.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC5DSCSurface MountDualProportional15 – – – 5/51.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC5.2SSCSurface MountSingleProportional15 – 5.22.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC48SSCSurface MountSingleProportional15 – 484 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC48DSCSurface MountDualProportional15 – – – 48/482/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC3.3SSCSurface MountSingleProportional15 – 3.32.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC28SSCSurface MountSingleProportional15 – 284 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC28DSCSurface MountDualProportional15 – – – 28/282/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC24SSCSurface MountSingleProportional15 – 244 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC24DSCSurface MountDualProportional15 – – – 24/242/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC15SSCSurface MountSingleProportional15 – 154 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC15DSCSurface MountDualProportional15 – – – 15/152/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC12SSCSurface MountSingleProportional15 – 123.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SC12DSCSurface MountDualProportional15 – – – 12/121.75/1.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB9SSBSurface MountSingleProportional15 – 92 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB9DSBSurface MountDualProportional15 – – – 9/91/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB5SSBSurface MountSingleProportional15 – 51.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB5DSBSurface MountDualProportional15 – – – 5/50.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB5.2SSBSurface MountSingleProportional15 – 5.21.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB48SSBSurface MountSingleProportional15 – 482 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB48DSBSurface MountDualProportional15 – – – 48/481/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB3.3SSBSurface MountSingleProportional15 – 3.31.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB28SSBSurface MountSingleProportional15 – 282 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB28DSBSurface MountDualProportional15 – – – 28/281/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB24DSBSurface MountDualProportional15 – – – 24/241/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB15SSBSurface MountSingleProportional15 – 152 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB15SSBSurface MountSingleProportional15 – 242 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB15DSBSurface MountDualProportional15 – – – 15/151/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB12SSBSurface MountSingleProportional15 – 122 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
15SB12DSBSurface MountDualProportional15 – – – 12/121/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
15MV500MVThrough HoleSingleProportional15 – 5001.25 – – – –
DatasheetMechanical Drawing3D Model
15MV450MVThrough HoleSingleProportional15 – 4501.25 – – – –
DatasheetMechanical Drawing3D Model
15MV400MVThrough HoleSingleProportional15 – 4001.25 – – – –
DatasheetMechanical Drawing3D Model
15MV350MVThrough HoleSingleProportional15 – 3501.25 – – – –
DatasheetMechanical Drawing3D Model
15MV300MVThrough HoleSingleProportional15 – 3001.25 – – – –
DatasheetMechanical Drawing3D Model
15MV250MVThrough HoleSingleProportional15 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
15MV200MVThrough HoleSingleProportional15 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
15MV150MVThrough HoleSingleProportional15 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
15MV100MVThrough HoleSingleProportional15 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
15M9SMThrough HoleSingleProportional15 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
15M9DMThrough HoleDualProportional15 – – – 9/90.625/0.625 – –
DatasheetMechanical Drawing3D Model
15M5SMThrough HoleSingleProportional15 – 51 – – – –
DatasheetMechanical Drawing3D Model
15M5DMThrough HoleDualProportional15 – – – 5/50.5/0.5 – –
DatasheetMechanical Drawing3D Model
15M5.2SMThrough HoleSingleProportional15 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
15M48SMThrough HoleSingleProportional15 – 481.25 – – – –
DatasheetMechanical Drawing3D Model
15M48DMThrough HoleDualProportional15 – – – 48/480.625/0.625 – –
DatasheetMechanical Drawing3D Model
15M3.3SMThrough HoleSingleProportional15 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
15M28SMThrough HoleSingleProportional15 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
15M28DMThrough HoleDualProportional15 – – – 28/280.625/0.625 – –
DatasheetMechanical Drawing3D Model
15M24SMThrough HoleSingleProportional15 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
15M24DMThrough HoleDualProportional15 – – – 24/240.625/0.625 – –
DatasheetMechanical Drawing3D Model
15M15SMThrough HoleSingleProportional15 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
15M15DMThrough HoleDualProportional15 – – – 15/150.625/0.625 – –
DatasheetMechanical Drawing3D Model
15M12SMThrough HoleSingleProportional15 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
15M12DMThrough HoleDualProportional15 – – – 12/120.625/0.625 – –
DatasheetMechanical Drawing3D Model
15FR5SFRThrough HoleSingleRegulated1513.5 – 16.550.75 – – – –
DatasheetMechanical Drawing3D Model
15FR5DFRThrough HoleDualRegulated1513.5 – 16.5 – – 5/50.25/0.25 – –
DatasheetMechanical Drawing3D Model
15FR15SFRThrough HoleSingleRegulated1513.5 – 16.5151 – – – –
DatasheetMechanical Drawing3D Model
15FR15DFRThrough HoleDualRegulated1513.5 – 16.5 – – 15/150.35/0.35 – –
DatasheetMechanical Drawing3D Model
15FR12SFRThrough HoleSingleRegulated1513.5 – 16.5121 – – – –
DatasheetMechanical Drawing3D Model
15FR12DFRThrough HoleDualRegulated1513.5 – 16.5 – – 12/120.35/0.35 – –
DatasheetMechanical Drawing3D Model
15E9SEThrough HoleSingleProportional15 – 96 – – – –
DatasheetMechanical Drawing3D Model
15E9DEThrough HoleDualProportional15 – – – 9/93/3 – –
DatasheetMechanical Drawing3D Model
15E5SEThrough HoleSingleProportional15 – 54 – – – –
DatasheetMechanical Drawing3D Model
15E5DEThrough HoleDualProportional15 – – – 5/52/2 – –
DatasheetMechanical Drawing3D Model
15E5.2SEThrough HoleSingleProportional15 – 5.24 – – – –
DatasheetMechanical Drawing3D Model
15E48SEThrough HoleSingleProportional15 – 486.75 – – – –
DatasheetMechanical Drawing3D Model
15E48DEThrough HoleDualProportional15 – – – 48/483.375/3.375 – –
DatasheetMechanical Drawing3D Model
15E3.3SEThrough HoleSingleProportional15 – 3.33.5 – – – –
DatasheetMechanical Drawing3D Model
15E28SEThrough HoleSingleProportional15 – 286.75 – – – –
DatasheetMechanical Drawing3D Model
15E28DEThrough HoleDualProportional15 – – – 28/283.375/3.375 – –
DatasheetMechanical Drawing3D Model
15E24SEThrough HoleSingleProportional15 – 246.75 – – – –
DatasheetMechanical Drawing3D Model
15E24DEThrough HoleDualProportional15 – – – 24/243.375/3.375 – –
DatasheetMechanical Drawing3D Model
15E15SEThrough HoleSingleProportional15 – 156.5 – – – –
DatasheetMechanical Drawing3D Model
15E15DEThrough HoleDualProportional15 – – – 15/153.25/3.25 – –
DatasheetMechanical Drawing3D Model
15E12SEThrough HoleSingleProportional15 – 126.5 – – – –
DatasheetMechanical Drawing3D Model
15E12DEThrough HoleDualProportional15 – – – 15/153.25/3.25 – –
DatasheetMechanical Drawing3D Model
15C9SCThrough HoleSingleProportional15 – 93 – – – –
DatasheetMechanical Drawing3D Model
15C9DCThrough HoleDualProportional15 – – – 9/91.5/1.5 – –
DatasheetMechanical Drawing3D Model
15C5SCThrough HoleSingleProportional15 – 52.5 – – – –
DatasheetMechanical Drawing3D Model
15C5DCThrough HoleDualProportional15 – – – 5/51.25/1.25 – –
DatasheetMechanical Drawing3D Model
15C5.2SCThrough HoleSingleProportional15 – 5.22.5 – – – –
DatasheetMechanical Drawing3D Model
15C48SCThrough HoleSingleProportional15 – 484 – – – –
DatasheetMechanical Drawing3D Model
15C48DCThrough HoleDualProportional15 – – – 48/482/2 – –
DatasheetMechanical Drawing3D Model
15C3.3SCThrough HoleSingleProportional15 – 3.32.5 – – – –
DatasheetMechanical Drawing3D Model
15C28SCThrough HoleSingleProportional15 – 284 – – – –
DatasheetMechanical Drawing3D Model
15C28DCThrough HoleDualProportional15 – – – 28/282/2 – –
DatasheetMechanical Drawing3D Model
15C24SCThrough HoleSingleProportional15 – 244 – – – –
DatasheetMechanical Drawing3D Model
15C24DCThrough HoleDualProportional15 – – – 24/242/2 – –
DatasheetMechanical Drawing3D Model
15C15SCThrough HoleSingleProportional15 – 154 – – – –
DatasheetMechanical Drawing3D Model
15C15DCThrough HoleDualProportional15 – – – 15/152/2 – –
DatasheetMechanical Drawing3D Model
15C12SCThrough HoleSingleProportional15 – 123.5 – – – –
DatasheetMechanical Drawing3D Model
15C12DCThrough HoleDualProportional15 – – – 12/121.75/1.75 – –
DatasheetMechanical Drawing3D Model
15B9SBThrough HoleSingleProportional15 – 92 – – – –
DatasheetMechanical Drawing3D Model
15B9DBThrough HoleDualProportional15 – – – 9/91/1 – –
DatasheetMechanical Drawing3D Model
15B5SBThrough HoleSingleProportional15 – 51.5 – – – –
DatasheetMechanical Drawing3D Model
15B5DBThrough HoleDualProportional15 – – – 5/50.75/0.75 – –
DatasheetMechanical Drawing3D Model
15B5.2SBThrough HoleSingleProportional15 – 5.21.5 – – – –
DatasheetMechanical Drawing3D Model
15B48SBThrough HoleSingleProportional15 – 482 – – – –
DatasheetMechanical Drawing3D Model
15B48DBThrough HoleDualProportional15 – – – 48/481/1 – –
DatasheetMechanical Drawing3D Model
15B3.3SBThrough HoleSingleProportional15 – 3.31.5 – – – –
DatasheetMechanical Drawing3D Model
15B28SBThrough HoleSingleProportional15 – 282 – – – –
DatasheetMechanical Drawing3D Model
15B28DBThrough HoleDualProportional15 – – – 28/281/1 – –
DatasheetMechanical Drawing3D Model
15B24DBThrough HoleDualProportional15 – – – 24/241/1 – –
DatasheetMechanical Drawing3D Model
15B15SBThrough HoleSingleProportional15 – 152 – – – –
DatasheetMechanical Drawing3D Model
15B15SBThrough HoleSingleProportional15 – 242 – – – –
DatasheetMechanical Drawing3D Model
15B15DBThrough HoleDualProportional15 – – – 15/151/1 – –
DatasheetMechanical Drawing3D Model
15B12SBThrough HoleSingleProportional15 – 122 – – – –
DatasheetMechanical Drawing3D Model
15B12DBThrough HoleDualProportional15 – – – 12/121/1 – –
DatasheetMechanical Drawing3D Model
15AVP9KAV (1500-10kV)Through HoleSingleProportional15 – +90001.25 – – – –
DatasheetMechanical Drawing3D Model
15AVP8KAV (1500-10kV)Through HoleSingleProportional15 – +80001.25 – – – –
DatasheetMechanical Drawing3D Model
15AVP7KAV (1500-10kV)Through HoleSingleProportional15 – +70001.25 – – – –
DatasheetMechanical Drawing3D Model
15AVP6KAV (1500-10kV)Through HoleSingleProportional15 – +60001.25 – – – –
DatasheetMechanical Drawing3D Model
15AVP10KAV (1500-10kV)Through HoleSingleProportional15 – +100001.25 – – – –
DatasheetMechanical Drawing3D Model
15AVN9KAV (1500-10kV)Through HoleSingleProportional15 – -90001.25 – – – –
DatasheetMechanical Drawing3D Model
15AVN8KAV (1500-10kV)Through HoleSingleProportional15 – -80001.25 – – – –
DatasheetMechanical Drawing3D Model
15AVN7KAV (1500-10kV)Through HoleSingleProportional15 – -70001.25 – – – –
DatasheetMechanical Drawing3D Model
15AVN6KAV (1500-10kV)Through HoleSingleProportional15 – -60001.25 – – – –
DatasheetMechanical Drawing3D Model
15AVN10KAV (1500-10kV)Through HoleSingleProportional15 – -100001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV900AV (100-1kV)Through HoleSingleProportional15 – 9001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV800AV (100-1kV)Through HoleSingleProportional15 – 8001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV700AV (100-1kV)Through HoleSingleProportional15 – 7001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV600AV (100-1kV)Through HoleSingleProportional15 – 6001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV5000-PAV (1500-10kV)Through HoleSingleProportional15 – +50001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV5000-NAV (1500-10kV)Through HoleSingleProportional15 – -50001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV5000AV (1500-10kV)Through HoleSingleProportional15 – 50001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV500AV (100-1kV)Through HoleSingleProportional15 – 5001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV4500-PAV (1500-10kV)Through HoleSingleProportional15 – +45001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV4500-NAV (1500-10kV)Through HoleSingleProportional15 – -45001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV4500AV (1500-10kV)Through HoleSingleProportional15 – 45001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV450AV (100-1kV)Through HoleSingleProportional15 – 4501.25 – – – –
DatasheetMechanical Drawing3D Model
15AV4000-PAV (1500-10kV)Through HoleSingleProportional15 – +40001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV4000-NAV (1500-10kV)Through HoleSingleProportional15 – -40001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV4000AV (1500-10kV)Through HoleSingleProportional15 – 40001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV400AV (100-1kV)Through HoleSingleProportional15 – 4001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV3500-PAV (1500-10kV)Through HoleSingleProportional15 – +35001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV3500-NAV (1500-10kV)Through HoleSingleProportional15 – -35001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV3500AV (1500-10kV)Through HoleSingleProportional15 – 35001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV350AV (100-1kV)Through HoleSingleProportional15 – 3501.25 – – – –
DatasheetMechanical Drawing3D Model
15AV3000-PAV (1500-10kV)Through HoleSingleProportional15 – +30001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV3000-NAV (1500-10kV)Through HoleSingleProportional15 – -30001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV3000AV (1500-10kV)Through HoleSingleProportional15 – 30001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV300AV (100-1kV)Through HoleSingleProportional15 – 3001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV250DAV (100-1kV)Through HoleDualProportional15 – – – ±250±0.625 – –
DatasheetMechanical Drawing3D Model
15AV2500-PAV (1500-10kV)Through HoleSingleProportional15 – +25001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV2500-NAV (1500-10kV)Through HoleSingleProportional15 – -25001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV2500AV (1500-10kV)Through HoleSingleProportional15 – 25001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV250AV (100-1kV)Through HoleSingleProportional15 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
15AV200DAV (100-1kV)Through HoleDualProportional15 – – – ±200±0.625 – –
DatasheetMechanical Drawing3D Model
15AV2000-PAV (1500-10kV)Through HoleSingleProportional15 – +20001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV2000-NAV (1500-10kV)Through HoleSingleProportional15 – -20001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV2000AV (1500-10kV)Through HoleSingleProportional15 – 20001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV200AV (100-1kV)Through HoleSingleProportional15 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV150DAV (100-1kV)Through HoleDualProportional15 – – – ±150±0.625 – –
DatasheetMechanical Drawing3D Model
15AV1500-PAV (1500-10kV)Through HoleSingleProportional15 – +15001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV1500-NAV (1500-10kV)Through HoleSingleProportional15 – -15001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV1500AV (1500-10kV)Through HoleSingleProportional15 – 15001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV150AV (100-1kV)Through HoleSingleProportional15 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
15AV100DAV (100-1kV)Through HoleDualProportional15 – – – ±100±0.625 – –
DatasheetMechanical Drawing3D Model
15AV1000AV (100-1kV)Through HoleSingleProportional15 – 10001.25 – – – –
DatasheetMechanical Drawing3D Model
15AV100AV (100-1kV)Through HoleSingleProportional15 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
15A9SAThrough HoleSingleProportional15 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
15A9DAThrough HoleDualProportional15 – – – ±9±0.625 – –
DatasheetMechanical Drawing3D Model
15A5SAThrough HoleSingleProportional15 – 51 – – – –
DatasheetMechanical Drawing3D Model
15A5DAThrough HoleDualProportional15 – – – ±5±0.5 – –
DatasheetMechanical Drawing3D Model
15A5.2SAThrough HoleSingleProportional15 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
15A48SAThrough HoleSingleProportional15 – 481.25 – – – –
DatasheetMechanical Drawing3D Model
15A48DAThrough HoleDualProportional15 – – – ±48±0.625 – –
DatasheetMechanical Drawing3D Model
15A3.3SAThrough HoleSingleProportional15 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
15A28SAThrough HoleSingleProportional15 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
15A28DAThrough HoleDualProportional15 – – – ±28±0.625 – –
DatasheetMechanical Drawing3D Model
15A250SAThrough HoleSingleProportional15 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
15A24SAThrough HoleSingleProportional15 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
15A24DAThrough HoleDualProportional15 – – – ±24±0.625 – –
DatasheetMechanical Drawing3D Model
15A200SAThrough HoleSingleProportional15 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
15A15SAThrough HoleSingleProportional15 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
15A15DAThrough HoleDualProportional15 – – – ±15±0.625 – –
DatasheetMechanical Drawing3D Model
15A150SAThrough HoleSingleProportional15 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
15A12SAThrough HoleSingleProportional15 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
15A12DAThrough HoleDualProportional15 – – – ±12±0.625 – –
DatasheetMechanical Drawing3D Model
15A100SAThrough HoleSingleProportional15 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
12XSGR9SXSGRSurface MountSingleRegulated1210.8 – 13.293 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12XSGR9DXSGRSurface MountDualRegulated1210.8 – 13.2 – – 9/91.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
12XSGR5SXSGRSurface MountSingleRegulated1210.8 – 13.252 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12XSGR5DXSGRSurface MountDualRegulated1210.8 – 13.2 – – 5/51/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
12XSGR3.3SXSGRSurface MountSingleRegulated1210.8 – 13.23.32 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12XSGR2SXSGRSurface MountSingleRegulated1210.8 – 13.221.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12XSGR15SXSGRSurface MountSingleRegulated1210.8 – 13.2154 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12XSGR15DXSGRSurface MountDualRegulated1210.8 – 13.2 – – 15/152/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
12XSGR12SXSGRSurface MountSingleRegulated1210.8 – 13.2124 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12XSGR12DXSGRSurface MountDualRegulated1210.8 – 13.2 – – 12/122/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
12XGR9SXGRThrough HoleSingleRegulated1210.8 – 13.293 – – – –
DatasheetMechanical Drawing3D Model
12XGR9DXGRThrough HoleDualRegulated1210.8 – 13.2 – – 9/91.5/1.5 – –
DatasheetMechanical Drawing3D Model
12XGR5SXGRThrough HoleSingleRegulated1210.8 – 13.252 – – – –
DatasheetMechanical Drawing3D Model
12XGR5DXGRThrough HoleDualRegulated1210.8 – 13.2 – – 5/51/1 – –
DatasheetMechanical Drawing3D Model
12XGR3.3SXGRThrough HoleSingleRegulated1210.8 – 13.23.32 – – – –
DatasheetMechanical Drawing3D Model
12XGR2SXGRThrough HoleSingleRegulated1210.8 – 13.221.5 – – – –
DatasheetMechanical Drawing3D Model
12XGR15SXGRThrough HoleSingleRegulated1210.8 – 13.2154 – – – –
DatasheetMechanical Drawing3D Model
12XGR15DXGRThrough HoleDualRegulated1210.8 – 13.2 – – 15/152/2 – –
DatasheetMechanical Drawing3D Model
12XGR12SXGRThrough HoleSingleRegulated1210.8 – 13.2124 – – – –
DatasheetMechanical Drawing3D Model
12XGR12DXGRThrough HoleDualRegulated1210.8 – 13.2 – – 12/122/2 – –
DatasheetMechanical Drawing3D Model
12VV9-PVV (100-10kV)Through HoleSingleProportional12 – +90006 – – – –
DatasheetMechanical Drawing3D Model
12VV9-NVV (100-10kV)Through HoleSingleProportional12 – -90006 – – – –
DatasheetMechanical Drawing3D Model
12VV9VV (100-10kV)Through HoleSingleProportional12 – 90006 – – – –
DatasheetMechanical Drawing3D Model
12VV8-PVV (100-10kV)Through HoleSingleProportional12 – +80006 – – – –
DatasheetMechanical Drawing3D Model
12VV8-NVV (100-10kV)Through HoleSingleProportional12 – -80006 – – – –
DatasheetMechanical Drawing3D Model
12VV8VV (100-10kV)Through HoleSingleProportional12 – 80006 – – – –
DatasheetMechanical Drawing3D Model
12VV7-PVV (100-10kV)Through HoleSingleProportional12 – +70006 – – – –
DatasheetMechanical Drawing3D Model
12VV7-NVV (100-10kV)Through HoleSingleProportional12 – -70006 – – – –
DatasheetMechanical Drawing3D Model
12VV7VV (100-10kV)Through HoleSingleProportional12 – 70006 – – – –
DatasheetMechanical Drawing3D Model
12VV6-PVV (100-10kV)Through HoleSingleProportional12 – +60006 – – – –
DatasheetMechanical Drawing3D Model
12VV6-NVV (100-10kV)Through HoleSingleProportional12 – -60006 – – – –
DatasheetMechanical Drawing3D Model
12VV6VV (100-10kV)Through HoleSingleProportional12 – 60006 – – – –
DatasheetMechanical Drawing3D Model
12VV500SVV (100-500V)Through HoleSingleProportional12 – 5004 – – – –
DatasheetMechanical Drawing3D Model
12VV5VV (100-10kV)Through HoleSingleProportional12 – 50006 – – – –
DatasheetMechanical Drawing3D Model
12VV400SVV (100-500V)Through HoleSingleProportional12 – 4004 – – – –
DatasheetMechanical Drawing3D Model
12VV4VV (100-10kV)Through HoleSingleProportional12 – 40007 – – – –
DatasheetMechanical Drawing3D Model
12VV300SVV (100-500V)Through HoleSingleProportional12 – 3004 – – – –
DatasheetMechanical Drawing3D Model
12VV3VV (100-10kV)Through HoleSingleProportional12 – 30008 – – – –
DatasheetMechanical Drawing3D Model
12VV200SVV (100-500V)Through HoleSingleProportional12 – 2004 – – – –
DatasheetMechanical Drawing3D Model
12VV2VV (100-10kV)Through HoleSingleProportional12 – 20008 – – – –
DatasheetMechanical Drawing3D Model
12VV100SVV (100-500V)Through HoleSingleProportional12 – 1004 – – – –
DatasheetMechanical Drawing3D Model
12VV10-PVV (100-10kV)Through HoleSingleProportional12 – +100006 – – – –
DatasheetMechanical Drawing3D Model
12VV10-NVV (100-10kV)Through HoleSingleProportional12 – -100006 – – – –
DatasheetMechanical Drawing3D Model
12VV10VV (100-10kV)Through HoleSingleProportional12 – 100006 – – – –
DatasheetMechanical Drawing3D Model
12VV1VV (100-10kV)Through HoleSingleProportional12 – 10008 – – – –
DatasheetMechanical Drawing3D Model
12VV0.9VV (100-10kV)Through HoleSingleProportional12 – 9008 – – – –
DatasheetMechanical Drawing3D Model
12VV0.8VV (100-10kV)Through HoleSingleProportional12 – 8008 – – – –
DatasheetMechanical Drawing3D Model
12VV0.7VV (100-10kV)Through HoleSingleProportional12 – 7008 – – – –
DatasheetMechanical Drawing3D Model
12VV0.6VV (100-10kV)Through HoleSingleProportional12 – 6008 – – – –
DatasheetMechanical Drawing3D Model
12VV0.5VV (100-10kV)Through HoleSingleProportional12 – 5008 – – – –
DatasheetMechanical Drawing3D Model
12VV0.4VV (100-10kV)Through HoleSingleProportional12 – 4008 – – – –
DatasheetMechanical Drawing3D Model
12VV0.3VV (100-10kV)Through HoleSingleProportional12 – 3008 – – – –
DatasheetMechanical Drawing3D Model
12VV0.2VV (100-10kV)Through HoleSingleProportional12 – 2008 – – – –
DatasheetMechanical Drawing3D Model
12VV0.1VV (100-10kV)Through HoleSingleProportional12 – 1008 – – – –
DatasheetMechanical Drawing3D Model
12SVV500SSVVSurface MountSingleProportional12 – 5004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SVV400SSVVSurface MountSingleProportional12 – 4004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SVV300SSVVSurface MountSingleProportional12 – 3004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SVV200SSVVSurface MountSingleProportional12 – 2004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SVV100SSVVSurface MountSingleProportional12 – 1004 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV900SMVSurface MountSingleProportional12 – 9001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV800SMVSurface MountSingleProportional12 – 8001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV700SMVSurface MountSingleProportional12 – 7001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV600SMVSurface MountSingleProportional12 – 6001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV500SMVSurface MountSingleProportional12 – 5001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV450SMVSurface MountSingleProportional12 – 4501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV400SMVSurface MountSingleProportional12 – 4001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV350SMVSurface MountSingleProportional12 – 3501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV300SMVSurface MountSingleProportional12 – 3001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV250DSMVSurface MountDualProportional12 – – – ±250±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV250SMVSurface MountSingleProportional12 – 2501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV200DSMVSurface MountDualProportional12 – – – ±200±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV200SMVSurface MountSingleProportional12 – 2001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV150DSMVSurface MountDualProportional12 – – – ±150±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV150SMVSurface MountSingleProportional12 – 1501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV100DSMVSurface MountDualProportional12 – – – ±100±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV1000SMVSurface MountSingleProportional12 – 10001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SMV100SMVSurface MountSingleProportional12 – 1001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM9SSMSurface MountSingleProportional12 – 91.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM9DSMSurface MountDualProportional12 – – – ±9±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM5SSMSurface MountSingleProportional12 – 51 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM5DSMSurface MountDualProportional12 – – – ±5±0.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM5.2SSMSurface MountSingleProportional12 – 5.21 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM48SSMSurface MountSingleProportional12 – 481.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM48DSMSurface MountDualProportional12 – – – ±48±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM3.3SSMSurface MountSingleProportional12 – 3.31 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM28SSMSurface MountSingleProportional12 – 281.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM28DSMSurface MountDualProportional12 – – – ±28±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM250SSMSurface MountSingleProportional12 – 2501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM24SSMSurface MountSingleProportional12 – 241.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM24DSMSurface MountDualProportional12 – – – ±24±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM200SSMSurface MountSingleProportional12 – 2001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM15SSMSurface MountSingleProportional12 – 151.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM15DSMSurface MountDualProportional12 – – – ±15±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM150SSMSurface MountSingleProportional12 – 1501.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM12SSMSurface MountSingleProportional12 – 121.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM12DSMSurface MountDualProportional12 – – – ±12±0.625 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SM100SSMSurface MountSingleProportional12 – 1001.25 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SFR5SSFRSurface MountSingleRegulated1210.8 – 13.250.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SFR5DSFRSurface MountDualRegulated1210.8 – 13.2 – – 5/50.25/0.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SFR15SSFRSurface MountSingleRegulated1210.8 – 13.2151 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SFR15DSFRSurface MountDualRegulated1210.8 – 13.2 – – 15/150.35/0.35 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SFR12SSFRSurface MountSingleRegulated1210.8 – 13.2121 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SFR12DSFRSurface MountDualRegulated1210.8 – 13.2 – – 12/120.35/0.35 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE9SSESurface MountSingleProportional12 – 96 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE9DSESurface MountDualProportional12 – – – 9/93/3 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE5SSESurface MountSingleProportional12 – 54 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE5DSESurface MountDualProportional12 – – – 5/52/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE5.2SSESurface MountSingleProportional12 – 5.24 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE48SSESurface MountSingleProportional12 – 486.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE48DSESurface MountDualProportional12 – – – 48/483.375/3.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE3.3SSESurface MountSingleProportional12 – 3.33.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE28SSESurface MountSingleProportional12 – 286.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE28DSESurface MountDualProportional12 – – – 28/283.375/3.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE24SSESurface MountSingleProportional12 – 246.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE24DSESurface MountDualProportional12 – – – 24/243.375/3.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE15SSESurface MountSingleProportional12 – 156.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE15DSESurface MountDualProportional12 – – – 15/153.25/3.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE12SSESurface MountSingleProportional12 – 126.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SE12DSESurface MountDualProportional12 – – – 12/123.25/3.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SDT9SSDTSurface MountSingleProportional12 – 90.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SDT9DDTThrough HoleDualProportional12 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
12SDT5SSDTSurface MountSingleProportional12 – 50.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SDT5DDTThrough HoleDualProportional12 – – – ±5±0.375 – –
DatasheetMechanical Drawing3D Model
12SDT5.2SSDTSurface MountSingleProportional12 – 5.20.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SDT3.3SSDTSurface MountSingleProportional12 – 3.30.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SDT15SSDTSurface MountSingleProportional12 – 150.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SDT15DDTThrough HoleDualProportional12 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
12SDT12SSDTSurface MountSingleProportional12 – 120.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SDT12DDTThrough HoleDualProportional12 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
12SC9SSCSurface MountSingleProportional12 – 93 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC9DSCSurface MountDualProportional12 – – – 9/91.5/1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC5SSCSurface MountSingleProportional12 – 52.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC5DSCSurface MountDualProportional12 – – – 5/51.25/1.25 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC5.2SSCSurface MountSingleProportional12 – 5.22.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC48SSCSurface MountSingleProportional12 – 484 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC48DSCSurface MountDualProportional12 – – – 48/482/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC3.3SSCSurface MountSingleProportional12 – 3.32.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC28SSCSurface MountSingleProportional12 – 284 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC28DSCSurface MountDualProportional12 – – – 28/282/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC24SSCSurface MountSingleProportional12 – 244 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC24DSCSurface MountDualProportional12 – – – 24/242/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC15SSCSurface MountSingleProportional12 – 154 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC15DSCSurface MountDualProportional12 – – – 15/152/2 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC12SSCSurface MountSingleProportional12 – 123.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SC12DSCSurface MountDualProportional12 – – – 12/121.75/1.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB9SSBSurface MountSingleProportional12 – 92 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB9DSBSurface MountDualProportional12 – – – 9/91/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB5SSBSurface MountSingleProportional12 – 51.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB5DSBSurface MountDualProportional12 – – – 5/50.75/0.75 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB5.2SSBSurface MountSingleProportional12 – 5.21.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB48SSBSurface MountSingleProportional12 – 482 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB48DSBSurface MountDualProportional12 – – – 48/481/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB3.3SSBSurface MountSingleProportional12 – 3.31.5 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB28SSBSurface MountSingleProportional12 – 282 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB28DSBSurface MountDualProportional12 – – – 28/281/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB24SSBSurface MountSingleProportional12 – 242 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB24DSBSurface MountDualProportional12 – – – 24/241/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB15SSBSurface MountSingleProportional12 – 152 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB15DSBSurface MountDualProportional12 – – – 15/151/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB12SSBSurface MountSingleProportional12 – 122 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SB12DSBSurface MountDualProportional12 – – – 12/121/1 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAT9SSATSurface MountSingleProportional12 – 90.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAT9DSATSurface MountDualProportional12 – – – ±9±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAT5SSATSurface MountSingleProportional12 – 50.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAT5DSATSurface MountDualProportional12 – – – ±5±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAT5.2SSATSurface MountSingleProportional12 – 5.20.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAT3.3SSATSurface MountSingleProportional12 – 3.30.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAT15SSATSurface MountSingleProportional12 – 150.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAT15DSATSurface MountDualProportional12 – – – ±15±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAT12SSATSurface MountSingleProportional12 – 120.75 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAT12DSATSurface MountDualProportional12 – – – ±12±0.375 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAR500SMSAR-SMSurface MountSingleRegulated Programmable127.5 – 155003±250±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAR500SARThrough HoleSingleRegulated Programmable127.5 – 155003±250±1.5 – –
DatasheetMechanical Drawing3D Model
12SAR250SMSAR-SMSurface MountSingleRegulated Programmable127.5 – 152503±125±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAR250SARThrough HoleSingleRegulated Programmable127.5 – 152503±125±1.5 – –
DatasheetMechanical Drawing3D Model
12SAR1500SMSAR-SMSurface MountSingleRegulated Programmable127.5 – 1515003±750±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAR1500SARThrough HoleSingleRegulated Programmable127.5 – 1515003±750±1.5 – –
DatasheetMechanical Drawing3D Model
12SAR100SMSAR-SMSurface MountSingleRegulated Programmable127.5 – 151003±50±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAR1000SMSAR-SMSurface MountSingleRegulated Programmable127.5 – 1510003±500±1.5 – –
DatasheetMechanical DrawingLand Pattern3D Model
12SAR1000SARThrough HoleSingleRegulated Programmable127.5 – 1510003±500±1.5 – –
DatasheetMechanical Drawing3D Model
12SAR100SARThrough HoleSingleRegulated Programmable127.5 – 151003±50±1.5 – –
DatasheetMechanical Drawing3D Model
12SA900SMSA-SMSurface MountSingleProportional12 – 9003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA900SAThrough HoleSingleProportional12 – 9003 – – – –
DatasheetMechanical Drawing3D Model
12SA800SMSA-SMSurface MountSingleProportional12 – 8003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA800SAThrough HoleSingleProportional12 – 8003 – – – –
DatasheetMechanical Drawing3D Model
12SA700SMSA-SMSurface MountSingleProportional12 – 7003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA700SAThrough HoleSingleProportional12 – 7003 – – – –
DatasheetMechanical Drawing3D Model
12SA600SMSA-SMSurface MountSingleProportional12 – 6003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA600SAThrough HoleSingleProportional12 – 6003 – – – –
DatasheetMechanical Drawing3D Model
12SA500SMSA-SMSurface MountSingleProportional12 – 5003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA500SAThrough HoleSingleProportional12 – 5003 – – – –
DatasheetMechanical Drawing3D Model
12SA450SMSA-SMSurface MountSingleProportional12 – 4503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA450SAThrough HoleSingleProportional12 – 4503 – – – –
DatasheetMechanical Drawing3D Model
12SA400SMSA-SMSurface MountSingleProportional12 – 4003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA400SAThrough HoleSingleProportional12 – 4003 – – – –
DatasheetMechanical Drawing3D Model
12SA350SMSA-SMSurface MountSingleProportional12 – 3503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA350SAThrough HoleSingleProportional12 – 3503 – – – –
DatasheetMechanical Drawing3D Model
12SA300SMSA-SMSurface MountSingleProportional12 – 3003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA300SAThrough HoleSingleProportional12 – 3003 – – – –
DatasheetMechanical Drawing3D Model
12SA250SMSA-SMSurface MountSingleProportional12 – 2503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA250SAThrough HoleSingleProportional12 – 2503 – – – –
DatasheetMechanical Drawing3D Model
12SA200SMSA-SMSurface MountSingleProportional12 – 2003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA200SAThrough HoleSingleProportional12 – 2003 – – – –
DatasheetMechanical Drawing3D Model
12SA150SMSA-SMSurface MountSingleProportional12 – 1503 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA150SAThrough HoleSingleProportional12 – 1503 – – – –
DatasheetMechanical Drawing3D Model
12SA100SMSA-SMSurface MountSingleProportional12 – 1003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA1000SMSA-SMSurface MountSingleProportional12 – 10003 – – – –
DatasheetMechanical DrawingLand Pattern3D Model
12SA1000SAThrough HoleSingleProportional12 – 10003 – – – –
DatasheetMechanical Drawing3D Model
12SA100SAThrough HoleSingleProportional12 – 1003 – – – –
DatasheetMechanical Drawing3D Model
12MV500MVThrough HoleSingleProportional12 – 5001.25 – – – –
DatasheetMechanical Drawing3D Model
12MV450MVThrough HoleSingleProportional12 – 4501.25 – – – –
DatasheetMechanical Drawing3D Model
12MV400MVThrough HoleSingleProportional12 – 4001.25 – – – –
DatasheetMechanical Drawing3D Model
12MV350MVThrough HoleSingleProportional12 – 3501.25 – – – –
DatasheetMechanical Drawing3D Model
12MV300MVThrough HoleSingleProportional12 – 3001.25 – – – –
DatasheetMechanical Drawing3D Model
12MV250MVThrough HoleSingleProportional12 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
12MV200MVThrough HoleSingleProportional12 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
12MV150MVThrough HoleSingleProportional12 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
12MV100MVThrough HoleSingleProportional12 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
12M9SMThrough HoleSingleProportional12 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
12M9DMThrough HoleDualProportional12 – – – 9/90.625/0.625 – –
DatasheetMechanical Drawing3D Model
12M5SMThrough HoleSingleProportional12 – 51 – – – –
DatasheetMechanical Drawing3D Model
12M5DMThrough HoleDualProportional12 – – – 5/50.5/0.5 – –
DatasheetMechanical Drawing3D Model
12M5.2SMThrough HoleSingleProportional12 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
12M48SMThrough HoleSingleProportional12 – 481.25 – – – –
DatasheetMechanical Drawing3D Model
12M48DMThrough HoleDualProportional12 – – – 48/480.625/0.625 – –
DatasheetMechanical Drawing3D Model
12M3.3SMThrough HoleSingleProportional12 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
12M28SMThrough HoleSingleProportional12 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
12M28DMThrough HoleDualProportional12 – – – 28/280.625/0.625 – –
DatasheetMechanical Drawing3D Model
12M24SMThrough HoleSingleProportional12 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
12M24DMThrough HoleDualProportional12 – – – 24/240.625/0.625 – –
DatasheetMechanical Drawing3D Model
12M15SMThrough HoleSingleProportional12 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
12M15DMThrough HoleDualProportional12 – – – 15/150.625/0.625 – –
DatasheetMechanical Drawing3D Model
12M12SMThrough HoleSingleProportional12 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
12M12DMThrough HoleDualProportional12 – – – 12/120.625/0.625 – –
DatasheetMechanical Drawing3D Model
12FR5SFRThrough HoleSingleRegulated1210.8 – 13.250.75 – – – –
DatasheetMechanical Drawing3D Model
12FR5DFRThrough HoleDualRegulated1210.8 – 13.2 – – 5/50.25/0.25 – –
DatasheetMechanical Drawing3D Model
12FR15SFRThrough HoleSingleRegulated1210.8 – 13.2151 – – – –
DatasheetMechanical Drawing3D Model
12FR15DFRThrough HoleDualRegulated1210.8 – 13.2 – – 15/150.35/0.35 – –
DatasheetMechanical Drawing3D Model
12FR12SFRThrough HoleSingleRegulated1210.8 – 13.2121 – – – –
DatasheetMechanical Drawing3D Model
12FR12DFRThrough HoleDualRegulated1210.8 – 13.2 – – 12/120.35/0.35 – –
DatasheetMechanical Drawing3D Model
12E9SEThrough HoleSingleProportional12 – 96 – – – –
DatasheetMechanical Drawing3D Model
12E9DEThrough HoleDualProportional12 – – – 9/93/3 – –
DatasheetMechanical Drawing3D Model
12E5SEThrough HoleSingleProportional12 – 54 – – – –
DatasheetMechanical Drawing3D Model
12E5DEThrough HoleDualProportional12 – – – 5/52/2 – –
DatasheetMechanical Drawing3D Model
12E5.2SEThrough HoleSingleProportional12 – 5.24 – – – –
DatasheetMechanical Drawing3D Model
12E48SEThrough HoleSingleProportional12 – 486.75 – – – –
DatasheetMechanical Drawing3D Model
12E48DEThrough HoleDualProportional12 – – – 48/483.375/3.375 – –
DatasheetMechanical Drawing3D Model
12E3.3SEThrough HoleSingleProportional12 – 3.33.5 – – – –
DatasheetMechanical Drawing3D Model
12E28SEThrough HoleSingleProportional12 – 286.75 – – – –
DatasheetMechanical Drawing3D Model
12E28DEThrough HoleDualProportional12 – – – 28/283.375/3.375 – –
DatasheetMechanical Drawing3D Model
12E24SEThrough HoleSingleProportional12 – 246.75 – – – –
DatasheetMechanical Drawing3D Model
12E24DEThrough HoleDualProportional12 – – – 24/243.375/3.375 – –
DatasheetMechanical Drawing3D Model
12E15SEThrough HoleSingleProportional12 – 156.5 – – – –
DatasheetMechanical Drawing3D Model
12E15DEThrough HoleDualProportional12 – – – 15/153.25/3.25 – –
DatasheetMechanical Drawing3D Model
12E12SEThrough HoleSingleProportional12 – 126.5 – – – –
DatasheetMechanical Drawing3D Model
12E12DEThrough HoleDualProportional12 – – – 12/123.25/3.25 – –
DatasheetMechanical Drawing3D Model
12DT9SDTThrough HoleSingleProportional12 – 90.75 – – – –
DatasheetMechanical Drawing3D Model
12DT9DDTThrough HoleDualProportional12 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
12DT5SDTThrough HoleSingleProportional12 – 50.75 – – – –
DatasheetMechanical Drawing3D Model
12DT5DDTThrough HoleDualProportional12 – – – ±5±0.375 – –
DatasheetMechanical Drawing3D Model
12DT5.2SDTThrough HoleSingleProportional12 – 5.20.75 – – – –
DatasheetMechanical Drawing3D Model
12DT3.3SDTThrough HoleSingleProportional12 – 3.30.75 – – – –
DatasheetMechanical Drawing3D Model
12DT15SDTThrough HoleSingleProportional12 – 150.75 – – – –
DatasheetMechanical Drawing3D Model
12DT15DDTThrough HoleDualProportional12 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
12DT12SDTThrough HoleSingleProportional12 – 120.75 – – – –
DatasheetMechanical Drawing3D Model
12DT12DDTThrough HoleDualProportional12 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
12C9SCThrough HoleSingleProportional12 – 93 – – – –
DatasheetMechanical Drawing3D Model
12C9DCThrough HoleDualProportional12 – – – 9/91.5/1.5 – –
DatasheetMechanical Drawing3D Model
12C5SCThrough HoleSingleProportional12 – 52.5 – – – –
DatasheetMechanical Drawing3D Model
12C5DCThrough HoleDualProportional12 – – – 5/51.25/1.25 – –
DatasheetMechanical Drawing3D Model
12C5.2SCThrough HoleSingleProportional12 – 5.22.5 – – – –
DatasheetMechanical Drawing3D Model
12C48SCThrough HoleSingleProportional12 – 484 – – – –
DatasheetMechanical Drawing3D Model
12C48DCThrough HoleDualProportional12 – – – 48/482/2 – –
DatasheetMechanical Drawing3D Model
12C3.3SCThrough HoleSingleProportional12 – 3.32.5 – – – –
DatasheetMechanical Drawing3D Model
12C28SCThrough HoleSingleProportional12 – 284 – – – –
DatasheetMechanical Drawing3D Model
12C28DCThrough HoleDualProportional12 – – – 28/282/2 – –
DatasheetMechanical Drawing3D Model
12C24SCThrough HoleSingleProportional12 – 244 – – – –
DatasheetMechanical Drawing3D Model
12C24DCThrough HoleDualProportional12 – – – 24/242/2 – –
DatasheetMechanical Drawing3D Model
12C15SCThrough HoleSingleProportional12 – 154 – – – –
DatasheetMechanical Drawing3D Model
12C15DCThrough HoleDualProportional12 – – – 15/152/2 – –
DatasheetMechanical Drawing3D Model
12C12SCThrough HoleSingleProportional12 – 123.5 – – – –
DatasheetMechanical Drawing3D Model
12C12DCThrough HoleDualProportional12 – – – 12/121.75/1.75 – –
DatasheetMechanical Drawing3D Model
12B9SBThrough HoleSingleProportional12 – 92 – – – –
DatasheetMechanical Drawing3D Model
12B9DBThrough HoleDualProportional12 – – – 9/91/1 – –
DatasheetMechanical Drawing3D Model
12B5SBThrough HoleSingleProportional12 – 51.5 – – – –
DatasheetMechanical Drawing3D Model
12B5DBThrough HoleDualProportional12 – – – 5/50.75/0.75 – –
DatasheetMechanical Drawing3D Model
12B5.2SBThrough HoleSingleProportional12 – 5.21.5 – – – –
DatasheetMechanical Drawing3D Model
12B48SBThrough HoleSingleProportional12 – 482 – – – –
DatasheetMechanical Drawing3D Model
12B48DBThrough HoleDualProportional12 – – – 48/481/1 – –
DatasheetMechanical Drawing3D Model
12B3.3SBThrough HoleSingleProportional12 – 3.31.5 – – – –
DatasheetMechanical Drawing3D Model
12B28SBThrough HoleSingleProportional12 – 282 – – – –
DatasheetMechanical Drawing3D Model
12B28DBThrough HoleDualProportional12 – – – 28/281/1 – –
DatasheetMechanical Drawing3D Model
12B24SBThrough HoleSingleProportional12 – 242 – – – –
DatasheetMechanical Drawing3D Model
12B24DBThrough HoleDualProportional12 – – – 24/241/1 – –
DatasheetMechanical Drawing3D Model
12B15SBThrough HoleSingleProportional12 – 152 – – – –
DatasheetMechanical Drawing3D Model
12B15DBThrough HoleDualProportional12 – – – 15/151/1 – –
DatasheetMechanical Drawing3D Model
12B12SBThrough HoleSingleProportional12 – 122 – – – –
DatasheetMechanical Drawing3D Model
12B12DBThrough HoleDualProportional12 – – – 12/121/1 – –
DatasheetMechanical Drawing3D Model
12AVR900AVRThrough HoleSingleRegulated1210.5 – 13.59001 – – – –
DatasheetMechanical Drawing3D Model
12AVR800AVRThrough HoleSingleRegulated1210.5 – 13.58001 – – – –
DatasheetMechanical Drawing3D Model
12AVR700AVRThrough HoleSingleRegulated1210.5 – 13.57001 – – – –
DatasheetMechanical Drawing3D Model
12AVR600AVRThrough HoleSingleRegulated1210.5 – 13.56001 – – – –
DatasheetMechanical Drawing3D Model
12AVR500AVRThrough HoleSingleRegulated1210.5 – 13.55001 – – – –
DatasheetMechanical Drawing3D Model
12AVR400AVRThrough HoleSingleRegulated1210.5 – 13.54001 – – – –
DatasheetMechanical Drawing3D Model
12AVR300AVRThrough HoleSingleRegulated1210.5 – 13.53001 – – – –
DatasheetMechanical Drawing3D Model
12AVR200AVRThrough HoleSingleRegulated1210.5 – 13.52001 – – – –
DatasheetMechanical Drawing3D Model
12AVR1000AVRThrough HoleSingleRegulated1210.5 – 13.510001 – – – –
DatasheetMechanical Drawing3D Model
12AVR100AVRThrough HoleSingleRegulated1210.5 – 13.51001 – – – –
DatasheetMechanical Drawing3D Model
12AVP9KAV (1500-10kV)Through HoleSingleProportional12 – +90001.25 – – – –
DatasheetMechanical Drawing3D Model
12AVP8KAV (1500-10kV)Through HoleSingleProportional12 – +80001.25 – – – –
DatasheetMechanical Drawing3D Model
12AVP7KAV (1500-10kV)Through HoleSingleProportional12 – +70001.25 – – – –
DatasheetMechanical Drawing3D Model
12AVP6KAV (1500-10kV)Through HoleSingleProportional12 – +60001.25 – – – –
DatasheetMechanical Drawing3D Model
12AVP10KAV (1500-10kV)Through HoleSingleProportional12 – +100001.25 – – – –
DatasheetMechanical Drawing3D Model
12AVN9KAV (1500-10kV)Through HoleSingleProportional12 – -90001.25 – – – –
DatasheetMechanical Drawing3D Model
12AVN8KAV (1500-10kV)Through HoleSingleProportional12 – -80001.25 – – – –
DatasheetMechanical Drawing3D Model
12AVN7KAV (1500-10kV)Through HoleSingleProportional12 – -70001.25 – – – –
DatasheetMechanical Drawing3D Model
12AVN6KAV (1500-10kV)Through HoleSingleProportional12 – -60001.25 – – – –
DatasheetMechanical Drawing3D Model
12AVN10KAV (1500-10kV)Through HoleSingleProportional12 – -100001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV900AV (100-1kV)Through HoleSingleProportional12 – 9001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV800AV (100-1kV)Through HoleSingleProportional12 – 8001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV700AV (100-1kV)Through HoleSingleProportional12 – 7001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV600AV (100-1kV)Through HoleSingleProportional12 – 6001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV5000-PAV (1500-10kV)Through HoleSingleProportional12 – +50001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV5000-NAV (1500-10kV)Through HoleSingleProportional12 – -50001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV5000AV (1500-10kV)Through HoleSingleProportional12 – 50001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV500AV (100-1kV)Through HoleSingleProportional12 – 5001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV4500-PAV (1500-10kV)Through HoleSingleProportional12 – +45001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV4500-NAV (1500-10kV)Through HoleSingleProportional12 – -45001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV4500AV (1500-10kV)Through HoleSingleProportional12 – 45001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV450AV (100-1kV)Through HoleSingleProportional12 – 4501.25 – – – –
DatasheetMechanical Drawing3D Model
12AV4000-PAV (1500-10kV)Through HoleSingleProportional12 – +40001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV4000-NAV (1500-10kV)Through HoleSingleProportional12 – -40001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV4000AV (1500-10kV)Through HoleSingleProportional12 – 40001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV400AV (100-1kV)Through HoleSingleProportional12 – 4001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV3500-PAV (1500-10kV)Through HoleSingleProportional12 – +35001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV3500-NAV (1500-10kV)Through HoleSingleProportional12 – -35001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV3500AV (1500-10kV)Through HoleSingleProportional12 – 35001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV350AV (100-1kV)Through HoleSingleProportional12 – 3501.25 – – – –
DatasheetMechanical Drawing3D Model
12AV3000-PAV (1500-10kV)Through HoleSingleProportional12 – +30001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV3000-NAV (1500-10kV)Through HoleSingleProportional12 – -30001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV3000AV (1500-10kV)Through HoleSingleProportional12 – 30001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV300AV (100-1kV)Through HoleSingleProportional12 – 3001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV250DAV (100-1kV)Through HoleDualProportional12 – – – ±250±0.625 – –
DatasheetMechanical Drawing3D Model
12AV2500-PAV (1500-10kV)Through HoleSingleProportional12 – +25001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV2500-NAV (1500-10kV)Through HoleSingleProportional12 – -25001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV2500AV (1500-10kV)Through HoleSingleProportional12 – 25001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV250AV (100-1kV)Through HoleSingleProportional12 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
12AV200DAV (100-1kV)Through HoleDualProportional12 – – – ±200±0.625 – –
DatasheetMechanical Drawing3D Model
12AV2000-PAV (1500-10kV)Through HoleSingleProportional12 – +20001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV2000-NAV (1500-10kV)Through HoleSingleProportional12 – -20001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV2000AV (1500-10kV)Through HoleSingleProportional12 – 20001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV200AV (100-1kV)Through HoleSingleProportional12 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV150DAV (100-1kV)Through HoleDualProportional12 – – – ±150±0.625 – –
DatasheetMechanical Drawing3D Model
12AV1500-PAV (1500-10kV)Through HoleSingleProportional12 – +15001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV1500-NAV (1500-10kV)Through HoleSingleProportional12 – -15001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV1500AV (1500-10kV)Through HoleSingleProportional12 – 15001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV150AV (100-1kV)Through HoleSingleProportional12 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
12AV100DAV (100-1kV)Through HoleDualProportional12 – – – ±100±0.625 – –
DatasheetMechanical Drawing3D Model
12AV1000AV (100-1kV)Through HoleSingleProportional12 – 10001.25 – – – –
DatasheetMechanical Drawing3D Model
12AV100AV (100-1kV)Through HoleSingleProportional12 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model
12AT9SATThrough HoleSingleProportional12 – 90.75 – – – –
DatasheetMechanical Drawing3D Model
12AT9DATThrough HoleDualProportional12 – – – ±9±0.375 – –
DatasheetMechanical Drawing3D Model
12AT5SATThrough HoleSingleProportional12 – 50.75 – – – –
DatasheetMechanical Drawing3D Model
12AT5DATThrough HoleDualProportional12 – – – ±5±0.375 – –
DatasheetMechanical Drawing3D Model
12AT5.2SATThrough HoleSingleProportional12 – 5.20.75 – – – –
DatasheetMechanical Drawing3D Model
12AT3.3SATThrough HoleSingleProportional12 – 3.30.75 – – – –
DatasheetMechanical Drawing3D Model
12AT15SATThrough HoleSingleProportional12 – 150.75 – – – –
DatasheetMechanical Drawing3D Model
12AT15DATThrough HoleDualProportional12 – – – ±15±0.375 – –
DatasheetMechanical Drawing3D Model
12AT12SATThrough HoleSingleProportional12 – 120.75 – – – –
DatasheetMechanical Drawing3D Model
12AT12DATThrough HoleDualProportional12 – – – ±12±0.375 – –
DatasheetMechanical Drawing3D Model
12A9SAThrough HoleSingleProportional12 – 91.25 – – – –
DatasheetMechanical Drawing3D Model
12A9DAThrough HoleDualProportional12 – – – ±9±0.625 – –
DatasheetMechanical Drawing3D Model
12A5SAThrough HoleSingleProportional12 – 51 – – – –
DatasheetMechanical Drawing3D Model
12A5DAThrough HoleDualProportional12 – – – ±5±0.5 – –
DatasheetMechanical Drawing3D Model
12A5.2SAThrough HoleSingleProportional12 – 5.21 – – – –
DatasheetMechanical Drawing3D Model
12A48SAThrough HoleSingleProportional12 – 481.25 – – – –
DatasheetMechanical Drawing3D Model
12A48DAThrough HoleDualProportional12 – – – ±48±0.625 – –
DatasheetMechanical Drawing3D Model
12A3.3SAThrough HoleSingleProportional12 – 3.31 – – – –
DatasheetMechanical Drawing3D Model
12A28SAThrough HoleSingleProportional12 – 281.25 – – – –
DatasheetMechanical Drawing3D Model
12A28DAThrough HoleDualProportional12 – – – ±28±0.625 – –
DatasheetMechanical Drawing3D Model
12A250SAThrough HoleSingleProportional12 – 2501.25 – – – –
DatasheetMechanical Drawing3D Model
12A24SAThrough HoleSingleProportional12 – 241.25 – – – –
DatasheetMechanical Drawing3D Model
12A24DAThrough HoleDualProportional12 – – – ±24±0.625 – –
DatasheetMechanical Drawing3D Model
12A200SAThrough HoleSingleProportional12 – 2001.25 – – – –
DatasheetMechanical Drawing3D Model
12A15SAThrough HoleSingleProportional12 – 151.25 – – – –
DatasheetMechanical Drawing3D Model
12A15DAThrough HoleDualProportional12 – – – ±15±0.625 – –
DatasheetMechanical Drawing3D Model
12A150SAThrough HoleSingleProportional12 – 1501.25 – – – –
DatasheetMechanical Drawing3D Model
12A12SAThrough HoleSingleProportional12 – 121.25 – – – –
DatasheetMechanical Drawing3D Model
12A12DAThrough HoleDualProportional12 – – – ±12±0.625 – –
DatasheetMechanical Drawing3D Model
12A100SAThrough HoleSingleProportional12 – 1001.25 – – – –
DatasheetMechanical Drawing3D Model

Series Listing

Proportional Converters

Four black electronic components labeled "PICO SERIES SAT," "PICO SERIES AT," "PICO SERIES DT," and "PICO SERIES SDT," are arranged against a plain white background.

AT, SAT, DT & SDT

Power: 0.75W, VIN: 3-12 VDC, VOUT: 3.3-15 VDC
Two electronic components labeled "Series SM PICO" and "Series A PICO," showing different pin configurations, manufactured in the USA.

A & SM

Power: 1.25W, VIN: 5-48 VDC, VOUT: 3.3-250 VDC
Four black electrical components labeled "Pico Series SMV" and "Pico Series AV" are arranged with protruding metal pins.

AV & SMV (100-1kV)

Power: 1.25W, VIN: 5-28 VDC,  VOUT: 100-1,000 VDC
Two black rectangular electronic components with white labeling. One is labeled "Pico Series AVN," and the other is "Pico Series AV-P." Both have caution labels for high voltage.

AV (1500-10kV)

Power: 1.25W, VIN: 5-48 VDC, VOUT: 1500-10,000 VDC
Two black electronic components labeled "Pico Series M N" and "Pico Series M V" with "OUT" and "IN" and plus and minus signs.

M & MV

Power: 1.25W, VIN: 5-28 VDC, VOUT: 3.3-500 VDC
Two black electronic components labeled "PICO SERIES B," shown in different orientations with visible input and output pins.

B & SB

Power: 2.5W, VIN: 5-48 VDC, VOUT: 3.3-48 VDC
Two rectangular electronic components labeled "Pico Series SA" with pins for electrical connections are shown against a white background.

SA & SA-SM

Power: 3W, VIN: 5-28 VDC, VOUT: 100-1,000 VDC
Two black rectangular electronic components with labels "PICO SERIES SC" and "PICO SERIES C," featuring input and output pins, against a white background.

C & SC

Power: 4W, VIN: 5-48 VDC, VOUT: 3.3-48 VDC
Two black rectangular electronic components labeled "Pico Series" with visible pins, branded with "Caution: High Voltage.

VV & SVV (100-500V)

Power: 4W, VIN: 2.5-48 VDC, VOUT: 100-500 VDC
Three black rectangular electronic components labeled "Pico Series E" and "Pico Series SE" with input and output markings, displayed on a white background.

E & SE

Power: 7W, VIN: 5-48 VDC, VOUT: 3.3-48 VDC
A black electronic component, labeled "Pico Series Out - Caution: High Voltage," with metal pins protruding from the bottom, is placed on a white reflective surface.

VV (100-10kV)

Power: 10W, VIN: 2-48 VDC, VOUT: 100-10,000 VDC

Regulated Converters

A rectangular electronic component with metal pins labeled "PICO SERIES AVR" and "CAUTION: HIGH VOLTAGE.

AVR

Power: 1W, VIN: 4.5-32 VDC, VOUT: 100-1,000 VDC
Two black electronic components with printed labels "Pico Series SFR" and "Pico Series FR" featuring multiple connectors and pins for circuit integration.

FR & SFR

Power: 1W, VIN: 5-28 VDC, VOUT: 5-15 VDC
A rectangular electronic component labeled "PICO SERIES MR" with multiple pins on the bottom and markings for inputs and outputs.

MR

Power: 2.5W, VIN: 5-36 VDC, VOUT: 3.3-28 VDC
Two black rectangular electronic components labeled "PICO SERIES OR" with metal pins on the bottom side.

OR & SOR

Power: 2.5W, VIN: 5-36 VDC, VOUT: 3.3-28 VDC
Two rectangular electronic components labeled "Pico Series SAR," featuring various pins and connection labels, are positioned on a white surface.

SAR & SAR-SM

Power: 3W, VIN: 5-36 VDC, VOUT: 100-1,500 VDC
Two black rectangular electronic components labeled "PICO SERIES XGR," showing input (-IN) and output (+OUT) terminals.

XGR & XSGR

Power: 4.5W, VIN: 5-28 VDC, VOUT: 2-15 VDC
A black electronic component with multiple pins, labeled "Pico Series" and "Caution High Voltage.

HILR

Power: 5W, VIN: 125-475 VDC, VOUT: 3.3-100 VDC
Rectangular electronic component labeled "PICO Series HVP" with ports "COM IN," "COM OUT," "PROG," "REF," "MON," "+IN," and "OUT." Caution label reads "HIGH VOLTAGE.

HVP

Power: 5W, VIN: 11-16 VDC, VOUT: 100-6,000 VDC
A black electronic component labeled "Pico Series LR" with input and output pins displayed on a reflective surface.

LR

Power: 5W, VIN: 5-60 VDC, VOUT: 2-100 VDC
A rectangular electronic component labeled "Pico Series PLR" with pins on the bottom.

PLR

Power: 5W, VIN: 5-60 VDC, VOUT: 3.3-100 VDC
Two black electronic components labeled "PICO SERIES SIR" and "PICO SERIES IR," showing various pins for connectivity.

IR & SIR

Power: 10W, VIN: 5-30 VDC, VOUT: 2-100 VDC
Six black electronic components labeled "PICO Series" with various series codes, displaying input and output pins, arranged on a white surface.

LV & TLV

Power: 3-10W, VIN: 36-80 VDC, VOUT: 3.3-48 VDC
A black electronic component labeled "PICO SERIES JR" with visible input and output pins.

JR

Power: 15W, VIN: 18-60 VDC, VOUT: 3.3-100 VDC
Seven black electronic components labeled "Pico Series" with various model numbers, featuring multiple connection pins, arranged on a white background.

HV & THV

Power: 3-15W, VIN: 70-170 VDC, VOUT: 3.3-48 VDC
Image of a black electronic component labeled "PICO SERIES KR" with pins on the lower side, displaying connections labeled "out+" and "out-" on the top.

KR

Power: 20W, VIN: 18-60 VDC, VOUT: 3.3-100 VDC
Black electronic component labeled "Pico Series NR" with four connectors labeled "OUT" and "CM" on a white background.

NR

Power: 30W, VIN: 10-60 VDC, VOUT: 3.3-28 VDC
